lV-PEcl 7x5mm 3.3V Oscillator

F4600 sERiEs

Page 1 of 2

RoHs compliant / Pb Free

OPTiOns

•

2.5V Version (F4620)

Rev. 2/14/2008

http://www.foxonline.com/need_a_sample.htm

FEATuREs

•

3.3V Operation

•

LV-PECL Output

Complementary Outputs

Standby Function

Tape and Reel

(2,000 pcs. STD)

• Pin 2 E/D (A Series)

• PART nuMbER sElEcTiOn

Learn More - Internet Required

Part Number

535-Frequency-xxxxx

536-Frequency-xxxxx

537-Frequency-xxxxx

538-Frequency-xxxxx

539-Frequency-xxxxx

540-Frequency-xxxxx

541-Frequency-xxxxx

Model

Number

F4600

F4600R

F4605

F4605R

F4606

F4606R

F4608

Operating

Frequency

Stability

Temperature (ºC)

-10 ~ +70

±100PPM

-40 ~ +85

±100PPM

-10 ~ +70

±50PPM

-40 ~ +85

±50PPM

-10 ~ +70

±25PPM

-40 ~ +85

±25PPM

-10 ~ +70

±20PPM

Frequency

Range (MHz)

41.660 ~ 280.000

41.660 ~ 170.000

41.660 ~ 280.000

41.660 ~ 170.000

41.660 ~ 210.000

41.660 ~ 170.000

• ElEcTRicAl cHARAcTERisTics

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

stg

)

Supply Voltage

)

Input Current

)

41.660 Mhz ~ 250.000 MHz

250.000+ Mhz ~ 280.000 MHz

Output Symmetry (50% Vp-p Level)

41.660 MHz ~ 170.000 MHz

170.000 Mhz ~ 280.000 MHz

Rise Time (T

) (20% ~ 80% Vp-p)

Fall Time (T

)(80% ~ 20% Vp-p)

Output Voltage

)

Standby Current

Output Load

Start-up Time

)

Output Disable Time

Output Enable Time

Jitter

12kHz ~ 20MHz

RMS Period

Cycle-to-Cycle

MAX

(unless otherwise noted)

41.660 ~ 280.000 MHz

-55ºC ~ +125ºC

3.3V ± 5%

60mA

88mA

45% ~ 55%

40% ~ 60%

1nS

1.7V

2.2V Min

30µA

See Recommended Circuit

10mS

100nS

10mS

0.3pS Typ.

2.5pS Typ.

20pS Typ.

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,

shock, and vibration.

An internal pullup resistor from pin 1 to pin 6 allows active output if pin 1 is left open.

Note: A 0.01µF bypass capacitor should be placed between

(Pin 6) and GND (Pin 3) to

minimize power supply line noise.

All specifications subject to change without notice.

All dimensions are in millimeters.

• EnAblE / DisAblE FuncTiOn

OUTPUT (Pin 4)

(Pin 1)

ACTIVE

OPEN

'1' Level V

≥

70% V

ACTIVE

'0' Level V

≤

30% V

High Z

OUTPUT (Pin 5)

ACTIVE

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

http://www.foxonline.com

EMEA

Tel/Fax: +44 .1767.312632 |

Asia

Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |

Taiwan

Tel: +886.2.22073427 Fax +886.2.22073486

Japan

Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
