VAWQ6-Q24-S12 Overview

DC/DC converter

rev.
page
date
1 of 3
08/2007
PART NUMBER:
VAWQ6 series
DESCRIPTION:
DC/DC converter
features
·5-6W isolated output
·efficiency to 80%
·24-Pin DIP package
·4:1 input range
·regulated outputs
·continuous short circuit protection
·Pi input filter
model
number
VAWQ6-Q24-S3R3
VAWQ6-Q24-S5
VAWQ6-Q24-S12
VAWQ6-Q24-S15
VAWQ6-Q24-D5
VAWQ6-Q24-D12
VAWQ6-Q24-D15
VAWQ6-Q48-S3R3
VAWQ6-Q48-S5
VAWQ6-Q48-S12
VAWQ6-Q48-S15
VAWQ6-Q48-D5
VAWQ6-Q48-D12
VAWQ6-Q48-D15
NOTES:
input
voltage
9-36VDC
9-36VDC
9-36VDC
9-36VDC
9-36VDC
9-36VDC
9-36VDC
18-72VDC
18-72VDC
18-72VDC
18-72VDC
18-72VDC
18-72VDC
18-72VDC
output
voltage
3.3VDC
5VDC
12VDC
15VDC
±5VDC
±12VDC
±15VDC
3.3VDC
5VDC
12VDC
15VDC
±5VDC
±12VDC
±15VDC
output
current
1000mA
1000mA
470mA
400mA
±500mA
±230mA
±190mA
1000mA
1000mA
470mA
400mA
±500mA
±230mA
±190mA
input current
no load
15mA
15mA
15mA
15mA
25mA
25mA
25mA
7.5mA
7.5mA
7.5mA
7.5mA
12mA
12mA
12mA
full load
191mA
267mA
294mA
313mA
288mA
297mA
267mA
100mA
134mA
149mA
157mA
146mA
149mA
135mA
efficiency
72%
78%
80%
80%
80%
80%
78%
70%
78%
79%
80%
79%
80%
77%
1. suffix “HM” for 1.5K Vdc isolation
2. suffix “H” for 3K Vdc isolation
3. suffix “-SMT” for SMT case style
20050
SW
112
th
Ave. Tualatin, Oregon
97062
phone
503.612.2300
fax
503.612.2382
