EH11

EH11

Series

• RoHS Compliant (Pb-free)

• HCMOS/TTL output

• 5.0V supply voltage

• 14 pin DIP package

• Stability to 20ppm

• Custom lead length,

gull wing options available

EH11

H 5.08

W 20.8

L 13.2

OSCILLATOR

ELECTRICAL SPECIFICATIONS

Frequency Range

Operating Temperature Range

Storage Temperature Range

Supply Voltage (V

DD

)

Input Current

Frequency Tolerance / Stability

Inclusive of all conditions: Calibration Tolerance at 25°C,

Frequency Stability over the Operating Temperature Range,

Supply Voltage Change, Output Load Change, First Year

Aging at 25°C, Shock, and Vibration

Output Voltage Logic High (V

OH

)

w/TTL Load

w/HCMOS Load

Output Voltage Logic Low (V

OL

)

Duty Cycle (V

DD

=5.0V

DC

)

w/TTL Load

w/HCMOS Load

at 1.4V

DC

w/TTL Load; at 50% of waveform w/HCMOS

Load (≤70.000MHz)

at 50% of waveform w/ TTL Load or w/HCMOS

Load (>70.000MHz)

at 50% of waveform w/TTL Load or w/HCMOS Load

Rise Time / Fall Time

0.8V

DC

to 2.0V

DC

w/TTL Load or 20% to 80%

of Waveform w/HCMOS Load (≤70.000MHz)

0.8V

DC

to 2.0V

DC

w/TTL Load or 20% to 80%

of Waveform w/HCMOS Load (>70.000MHz)

Tri-State Input Voltage

V

IH

:No Connection

V

IH

:≥2.2V

DC

V

IL

:≤0.8V

DC

Aging (at 25°C)

Start Up Time

Load Drive Capability

Period Jitter: Absolute

Period Jitter: One Sigma

MANUFACTURER

CATEGORY

SERIES

PACKAGE

VOLTAGE

1.000MHz to 155.520MHz

0°C to 70°C or -40°C to 85°C

-55°C to 125°C

5.0V

DC

±10%

50mA Maximum (Unloaded)

±100ppm, ±50ppm, ±25ppm, or

±20ppm Maximum

2.4V

DC

Minimum

V

DD

-0.4V

DC

Minimum

0.4V

DC

Maximum

0.5V

DC

Maximum

50 ±10(%) (Standard)

50 ±10(%) (Standard)

50 ±5(%) (Optional)

6 nSeconds Maximum

4 nSeconds Maximum

Enables Output

Enables Output

I

OH

=-16mA

I

OH

=-16mA

I

OL

=+16mA

I

OL

=+16mA

Disables Output: High Impedance

±5ppm / year Maximum

10 mSeconds Maximum

≤70.000MHz

>70.000MHz

10TTL Load or 50pF HCMOS Load Maximum

5TTL Load or 15pF HCMOS Load Maximum

±250pSec Maximum, ±100pSec Typical

±50pSec Maximum, ±30pSec Typical

CLASS

REV

.

DATE

ECLIPTEK CORP.

OSCILLATOR

EH11

14 Pin DIP

5.0V

OS44

12/05

800-ECLIPTEK www.ecliptek.com for latest revision

Specifications subject to change without notice.

PART NUMBERING GUIDE

EH11 00 ET T TS - 70.000M - G

FREQUENCY TOLERANCE / STABILITY

00=±100ppm Max.(Standard), 45=±50ppm Max.

25=±25ppm Max., 20=±20ppm Max.

OPERATING TEMP. RANGE

Blank=0°C to 70°C (Standard), ET=-40°C to 85°C

DUTY CYCLE

Blank=50 ±10(%) (Standard), T=50 ±5(%)

AVAILABLE OPTIONS

Blank=None (Standard)

CLXXX=Custom Lead Length (See Page 133)

G=Full Size Gull Wing (See Page 132)

FREQUENCY

OUTPUT CONTROL FUNCTION

TS=Tri-State Enable High

NOTES

__________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

MECHANICAL DIMENSIONS

ALL DIMENSIONS IN MILLIMETERS

MARKING SPECIFICATIONS

Ø

Line 1: ECLIPTEK

Line 2: EH11 TS

Series Designator

Line 3: XX.XXX M

Frequency in MHz (5 Digits Maximum + Decimal)

Line 4: XX Y ZZ

Pin 1: Tri-State

Pin 7: Case Ground

Pin 8: Output

Pin 14: Supply Voltage

Week of Year

Last Digit of Year

Ecliptek Manufacturing Identifier

Note: Pin 1 shall be designated with a dot

ENVIRONMENTAL/MECHANICAL SPECIFICATIONS

Characteristic

Fine Leak Test

Gross Leak Test

Mechanical Shock

Vibration

Lead Integrity

Specification

MIL-STD-883, Method 1014, Condition A

MIL-STD-883, Method 1014, Condition C

MIL-STD-202, Method 213, Condition C

MIL-STD-883, Method 2007, Condition A

MIL-STD-883, Method 2004

Characteristic

Solderability

Temperature Cycling

Resistance to Soldering Heat

Resistance to Solvents

Specification

MIL-STD-883, Method 2002

MIL-STD-883, Method 1010

MIL-STD-883, Method 210

MIL-STD-883, Method 215

MANUFACTURER

CATEGORY

SERIES

PACKAGE

VOLTAGE

CLASS

REV

.

DATE

ECLIPTEK CORP.

OSCILLATOR

EH11

14 Pin DIP

5.0V

OS44

12/05

800-ECLIPTEK www.ecliptek.com for latest revision

Specifications subject to change without notice.

EH11

Series

• RoHS Compliant (Pb-free)

• HCMOS/TTL Output

• 5.0V Supply Voltage

• 8 Pin DIP Package

• Stability to 20ppm

• Custom Lead Length and

Gull Wing Options Available

EH11

H 5.6

L 13.2

W 13.2

OSCILLATOR

ELECTRICAL SPECIFICATIONS

Frequency Range

Operating Temperature Range

Storage Temperature Range

Supply Voltage (V

DD

)

Input Current

Frequency Tolerance / Stability

Inclusive of all conditions: Calibration Tolerance at 25°C,

Frequency Stability over the Operating Temperature Range,

Supply Voltage Change, Output Load Change, First Year

Aging at 25°C, Shock, and Vibration

Output Voltage Logic High (V

OH

)

w/TTL Load

w/HCMOS Load

Output Voltage Logic Low (V

OL

)

Duty Cycle (V

DD

=5.0V

DC

)

w/TTL Load

w/HCMOS Load

at 1.4V

DC

w/TTL Load; at 50% of waveform w/HCMOS

Load (≤70.000MHz)

at 50% of waveform w/ TTL Load or w/HCMOS

Load (>70.000MHz)

at 50% of waveform w/TTL Load or w/HCMOS Load

Rise Time / Fall Time

0.8V

DC

to 2.0V

DC

w/TTL Load or 20% to 80%

of Waveform w/HCMOS Load (≤70.000MHz)

0.8V

DC

to 2.0V

DC

w/TTL Load or 20% to 80%

of Waveform w/HCMOS Load (>70.000MHz)

Tri-State Input Voltage

V

IH

:No Connection

V

IH

:≥2.2V

DC

V

IL

:≤0.8V

DC

Aging (at 25°C)

Start Up Time

Load Drive Capability

Period Jitter: Absolute

Period Jitter: One Sigma

MANUFACTURER

CATEGORY

SERIES

PACKAGE

VOLTAGE

1.000MHz to 155.520MHz

0°C to 70°C or -40°C to 85°C

-55°C to 125°C

5.0V

DC

±10%

50mA Maximum (Unloaded)

±100ppm, ±50ppm, ±25ppm, or

±20ppm Maximum

2.4V

DC

Minimum

V

DD

-0.4V

DC

Minimum

0.4V

DC

Maximum

0.5V

DC

Maximum

50 ±10(%) (Standard)

50 ±10(%) (Standard)

50 ±5(%) (Optional)

6 nSeconds Maximum

4 nSeconds Maximum

Enables Output

Enables Output

I

OH

=-16mA

I

OH

=-16mA

I

OL

=+16mA

I

OL

=+16mA

Disables Output: High Impedance

±5ppm / year Maximum

10 mSeconds Maximum

≤70.000MHz

>70.000MHz

10TTL Load or 50pF HCMOS Load Maximum

5TTL Load or 15pF HCMOS Load Maximum

±250pSec Maximum, ±100pSec Typical

±50pSec Maximum, ±30pSec Typical

CLASS

REV

.

DATE

ECLIPTEK CORP.

OSCILLATOR

EH11

8 Pin DIP

5.0V

OS45

08/05

800-ECLIPTEK www.ecliptek.com for latest revision

62

Specifications subject to change without notice.

PART NUMBERING GUIDE

EH11 00 HS ET T TS - 70.000M - G TR

FREQUENCY TOLERANCE / STABILITY

00=±100ppm Max.(Standard), 45=±50ppm Max.

25=±25ppm Max., 20=±20ppm Max.

PACKAGE

HS=Half Size 8 Pin DIP

OPERATING TEMP. RANGE

Blank=0°C to 70°C (Standard), ET=-40°C to 85°C

DUTY CYCLE

Blank=50 ±10(%) (Standard), T=50 ±5(%)

PACKAGING OPTIONS

Blank=Bulk (Standard),

TR= Tape & Reel (only offered with

Half Size G and Half Size G2 Options)

AVAILABLE OPTIONS

Blank=None (Standard)

CLXXX=Custom Lead Length (See Page 133)

G=Half Size Gull Wing (See Page 132)

G2=Half Size Gull Wing (See Page 132)

FREQUENCY

OUTPUT CONTROL FUNCTION

TS=Tri-State Enable High

MECHANICAL DIMENSIONS

ALL DIMENSIONS IN MILLIMETERS

TAPE AND REEL DIMENSIONS

ALL DIMENSIONS IN MILLIMETERS

Pin 1 Locator for Gull Wing

(1) For “G” Option

Ø

Pin 1: Tri-State

Pin 4: Case Ground

Pin 5: Output

Pin 8: Supply Voltage

MARKING SPECIFICATIONS

Line 1: ECLIPTEK

Line 2: EH11 TS

Series Designator

Line 3: XX.XXX M

ENVIRONMENTAL/MECHANICAL SPECIFICATIONS

Frequency in MHz

(5 Digits Maximum + Decimal)

700 Pieces Per Reel

Compliant to EIA-481A

Characteristic

Fine Leak Test

Gross Leak Test

Mechanical Shock

Vibration

Lead Integrity

Solderability

Temperature Cycling

Resistance to Soldering Heat

Resistance to Solvents

Specification

MIL-STD-883, Method 1014, Condition A

MIL-STD-883, Method 1014, Condition C

MIL-STD-202, Method 213, Condition C

MIL-STD-883, Method 2007, Condition A

MIL-STD-883, Method 2004

MIL-STD-883, Method 2002

MIL-STD-883, Method 1010

MIL-STD-883, Method 210

MIL-STD-883, Method 215

Line 4: XX Y ZZ

Week of Year

Last Digit of Year

Ecliptek Manufacturing Identifier

Note: Pin 1 shall be designated with a dot

MANUFACTURER

CATEGORY

SERIES

PACKAGE

VOLTAGE

CLASS

REV

.

DATE

ECLIPTEK CORP.

OSCILLATOR

EH11

8 pin DIP

5.0V

OS45

08/05

800-ECLIPTEK www.ecliptek.com for latest revision

Specifications subject to change without notice.
