In order to ensure the product operates efficiently and reliably, make sure the specified range of input voltage is not exceeded and the
minimum output load is not less than 10% load. If the actual load is less than the specified minimum load, the output ripple may
increase sharply while its efficiency and reliability will reduce greatly. If the actual output power is very small, please add an
appropriate resistor as extra loading.
Overload Protection
Under normal operating conditions, the output circuit of these products has no protection against over-current and short-circuits. The
simplest method is to connect a self-recovery fuse in series at the input end or add a circuit breaker to the circuit.
Filtering
In some circuits which are sensitive to noise and ripple, a filtering capacitor may be added to the DC/DC output end and input end to
reduce the noise and ripple. However, the capacitance of the output filter capacitor must be proper. If the capacitance is too big, a
startup problem might arise. For every channel of output, provided the safe and reliable operation is ensured, the greatest
capacitance of its filter capacitor sees the external capacitor table. To get an extremely low ripple, an “LC” filtering network may be
connected to the input and output ends of the DC/DC converter, which may produce a more significant filtering effect. It should also
be noted that the inductance and the frequency of the “LC” filtering network should be staggered with the DC/DC frequency to avoid
mutual interference (Figure 1).
Figure 1
Vin
Cin
GND
L
L
+Vo
Cout
0V
2.
3.
DC DC
4.
Output Voltage Regulation and Over-voltage Protection Circuit
The simplest device for output voltage regulation, over-voltage and over-current protection is a linear voltage regulator with overheat
protection that is connected to the input or output end in series (Figure 2).
Figure 2
Vin
GND
REG
REG
+Vo
0V
DC DC
5.
External Capacitor Table
It is not recommended to connect any external capacitor in the application field with less than 0.5 W output.
Vin
(Vdc)
Cout
(µF)
4.7
2.2
--
--
Vout
(Vdc)
5
9
12
15
Cout
(µF)
10
4.7
2.2
1
Table 1
5
12
--
--
Note:
All specifications measured at 25°C, humidity <75%, nominal input voltage, and full load unless otherwise noted.
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VHS1-SIP
│
DESCRIPTION:
DC-DC CONVERTER
date
12/02/2014
│
page
5 of 5
REVISION HISTORY
rev.
1.0
1.01
1.02
1.03
1.04
1.05
description
initial release
new template applied
V-Infinity branding removed
added 9 and 15 V load regulation data
5 V input models changed efficiency, switching frequency, short circuit
protection, and operating temperature
updated datasheet
date
01/03/2011
04/12/2012
09/05/2012
11/05/2012
06/17/2013
12/02/2014
The revision history provided is for informational purposes only and is believed to be accurate.
