Type 361R
105 °C, Miniature, Industrial Grade, Radial Leaded
High-value, High Ripple, Low ESR & ESL
Type 361R capacitors are for industrial applications
from –40 °C to +105 °C. They deliver excellent ripple
capability and low ESR and ESL. Also available with three
mounting leads. For three leads, change Type designation
from 361R to 366R.
Highlights
• Excellent Ripple Capability
• Low ESR and ESL
• High Value
Specifications
Operating Temperature:
Rated Voltage:
Capacitance:
Leakage Current:
Ripple Current Multipliers:
–40 °C to +105 °C
6.3 to 450 Vdc
7 to 18,000 µF ± 20%
≤0.002 CV µF +25 °C, 6.3 to 160 Vdc
≤0.02 CV µF +25 °C, 200 to 450 Vdc
Ambient Temperature
45 °C
2.00
55 °C
1.60
50 Hz
6.3 & 10 V
16 to 25 V
35 V & up
0.91
0.85
0.77
65 °C
1.40
60 Hz 120 Hz
0.93
0.88
0.82
1.00
1.00
1.00
75 °C
1.25
85 °C
1.00
95 °C
0.79
105 °C
0.5
360 Hz 1 kHz 5 kHz 10 kHz & up
1.06
1.12
1.21
1.08
1.18
1.32
1.09
1.21
1.37
1.09
1.22
1.38
Complies with the EU
Directive 2002/95/EC
requirement restricting
the use of Lead (Pb),
Mercury (Hg), Cadmium
(Cd), Hexavalent chromium
(Cr(VI)), PolyBrominated
Biphenyls (PBB) and
PolyBrominated Diphenyl
Ethers (PBDE).
Load Life:
Shelf Life:
Vibration:
Outline Drawings
4,000 h @ +105 °C
∆ Capacitance ±15%
ESR 175% of limit
DCL 100% of limit
1,000 h @ 105 °C
∆ Capacitance ±15%
ESR 150% of limit
DCL 200% of limit
10 to 55 Hz, 0.06” and 10 g, 2 h ea of 3 planes
CDM Cornell Dubilier
•
140 Technology Place
•
Liberty, SC 29657
•
Phone: (864)843-2277
•
Fax: (864)843-3800
•
www.cde.com
Type 361R
105 °C, Miniature, Industrial Grade, Radial Leaded
Case Dimensions
Nominal
Case
Code
EG
EK
EM
EN
ER
FK
FF
FN
FQ
FV
LQ
LV
HH
HK
HG
DxL
(mm)
12.5 x 20.0
12.5 x 25.0
12.5 x 26.5
12.5 x 33.5
12.5 x 42.5
16.0 x 25.0
16.0 x 32.0
16.0 x 33.5
16.0 x 36.0
16.0 x 40.0
18.0 x 36.0
18.0 x 40.0
22.0 x 22.0
22.0 x 25.0
22.0 x 30.0
Insulated
DxL
(mm)
13.0 x 21.5
13.0 x 26.5
13.0 x 28.0
13.0 x 34.2
13.0 x 43.7
16.5 x 26.2
16.5 x 33.5
16.5 x 34.2
16.5 x 37.5
16.5 x 41.7
18.5 x 37.5
18.5 x 42.0
22.5 x 23.5
22.5 x 26.2
22.5 x 32.5
Insulated
Epoxy Seal
(mm)
13.0 x 23.0
13.0 x 29.0
13.0 x 29.5
13.0 x 36.0
13.0 x 45.5
16.5 x 27.9
16.5 x 36.0
16.5 x 36.0
16.5 x 40.0
16.5 x 42.4
18.5 x 40.0
18.5 x 43.0
22.5 x 26.0
22.5 x 27.9
22.5 x 34.0
S
± 0.6
(mm)
5.0
5.0
5.0
5.0
5.0
7.5
7.5
7.5
7.5
7.5
7.5
7.5
10.0
10.0
10.0
T
± 0.5
(mm)
2.5
2.5
2.5
2.5
2.5
3.75
3.75
3.75
3.75
3.75
3.75
3.75
5.0
5.0
5.0
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
0.81
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
3.8
4.5
4.7
5.8
7.3
7.2
9.4
9.5
10.6
11.9
13.4
14.9
11.0
13.5
15.1
Lead Diam.
mm
AWG
Weight
g
L incl. Sleeve & Epoxy Seal - Millimeters
Part Numbering System
361R
Type
361R
or 366R
183
Capacitance
M
Tolerance
6R3
Voltage
LV
Case Code
2
Insulation
0 =
None
2 =
PVC
E
Epoxy End Seal
100 =
10 µF
101 =
100 µF
183 =
18000 µF
M =
±20%
U =
–10 + 75%
6R3 =
6.3 Vdc
063 =
63 Vdc
(blank) =
no epoxy
E =
Epoxy
Typical Performance Curves
CDM Cornell Dubilier
•
140 Technology Place
•
Liberty, SC 29657
•
Phone: (864)843-2277
•
Fax: (864)843-3800
•
www.cde.com
Type 361R
105 °C, Miniature, Industrial Grade, Radial Leaded
Ratings
Cap.
(µF)
2200
3300
3900
4700
6800
6800
6800
8200
Catalog
Part Number
361R222M6R3EG2
361R332M6R3EK2
361R392M6R3EM2
361R472M6R3EN2
361R682M6R3ER2
361R682M6R3FK2
361R682M6R3HH2
361R822M6R3HK2
ESR Max. Ripple A
120 Hz
120 Hz
25ºC (Ω) 85ºC (A)
0.205
0.140
0.131
0.098
0.075
0.084
0.091
0.075
0.068
0.046
0.062
0.058
0.044
0.053
0.049
0.210
0.158
0.144
0.115
0.083
0.093
0.094
0.074
0.073
0.063
0.052
0.059
0.046
0.056
0.051
0.265
0.156
0.147
0.108
0.100
0.100
0.084
0.077
0.082
0.066
0.064
0.014
0.060
0.011
0.053
1.130
1.440
1.380
1.840
2.160
2.000
2.200
2.330
2.330
3.290
2.550
2.750
3.420
2.990
3.240
0.947
1.330
1.420
1.760
2.250
2.000
2.170
2.540
2.440
2.950
3.170
3.000
3.390
3.050
3.400
0.942
1.350
1.410
1.790
1.880
2.080
2.200
2.280
2.430
2.670
2.700
3.110
2.800
3.590
3.000
Nom Size
DXL
(mm)
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
12.5 x 42.5
16 x 25
22 x 22
22 x 25
16 x 32
22 x 30
16 x 36
16 x 40
22 x 40
18 x 36
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
12.5 x 42.5
16 x 25
22 x 22
22 x 25
16 x 32
16 x 36
22 x 30
16 x 40
22 x 40
18 x 36
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
22 x 25
16 x 36
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
Cap.
(µF)
1000
1500
2200
2700
3300
3300
3900
3900
4700
5600
6800
6800
8200
10000
10000
820
1000
1200
1800
2200
2200
2700
3300
3300
3900
4700
4700
4700
5600
6800
680
1000
1200
1500
1800
1800
2200
2200
2700
2700
3300
3300
3300
4700
4700
Catalog
Part Number
361R102M020EG2
361R152M020EK2
361R222M020EM2
361R272M020EN2
361R332M020FK2
361R332M020HH2
361R392M020ER2
361R392M020HK2
361R472M020FF2
361R562M020FQ2
361R682M020FV2
361R682M020HG2
361R822M020LQ2
361R103M020HV2
361R103M020LV2
361R821M025EG2
361R102M025EK2
361R122M025EM2
361R182M025EN2
361R222M025FK2
361R222M025HH2
361R272M025ER2
361R332M025FF2
361R332M025HK2
361R392M025FK2
361R472M025FV2
361R472M025HG2
361R472M025LQ2
361R562M025LV2
361R682M025HV2
361R681M035EG2
361R102M035EK2
361R122M035EM2
361R152M035EN2
361R182M035FK2
361R182M035HH2
361R222M035ER2
361R222M035FF2
361R272M035FQ2
361R272M035HK2
361R332M035FV2
361R332M035HG2
361R332M035LQ2
361R472M035HV2
361R472M035LV2
ESR Max. Ripple A
120 Hz
120 Hz
25ºC (Ω) 85ºC (A)
0.200
0.133
0.103
0.084
0.076
0.076
0.065
0.065
0.060
0.055
0.053
0.047
0.047
0.044
0.044
0.280
0.230
0.190
0.128
0.121
0.121
0.096
0.091
0.091
0.081
0.071
0.071
0.071
0.065
0.053
0.287
0.199
0.190
0.133
0.133
0.110
0.106
0.106
0.086
0.086
0.080
0.081
0.080
0.064
0.064
0.970
1.300
1.510
1.840
2.000
2.320
2.320
2.500
2.480
2.720
2.900
3.330
3.180
3.750
3.280
0.860
1.080
1.150
1.550
1.660
1.840
2.000
2.080
2.230
2.360
2.560
2.750
2.710
2.830
3.610
0.850
1.200
1.250
1.570
1.620
1.840
1.900
2.000
2.330
2.180
2.380
2.570
2.400
3.270
2.700
Nom Size
DXL
(mm)
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
22 x 25
16 x 32
16 x 36
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
22 x 25
16 x 36
16 x 40
22 x 30
18 x 36
18 x 40
22 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
6.3 Vdc (8 Vdc Surge)
20 Vdc (25 Vdc Surge)
10000 361R103M6R3FF2
10000 361R103M6R3HG2
12000 361R123M6R3FQ2
12000 361R123M6R3FV2
15000 361R153M6R3HV2
15000 361R153M6R3LQ2
18000
1500
2200
2700
3300
4700
4700
4700
5600
6800
8200
8200
10000
12000
15000
1000
1800
2200
3300
3300
3300
4700
4700
4700
6800
6800
6800
7800
9000
10000
361R183M6R3LV2
361R152M010EG2
361R222M010EK2
361R272M010EM2
361R332M010EN2
361R472M010ER2
361R472M010FK2
361R472M010HH2
361R562M010HK2
361R682M010FF2
361R822M010FQ2
361R822M010HG2
361R103M010FV2
361R123M010LQ2
361R153M010LV2
361R102M016EG2
361R182M016EK2
361R222M016EM2
361R332M016EN2
361R332M016FK2
361R332M016HH2
361R472M016ER2
361R472M016FF2
361R472M016HK2
361R682M016FQ2
361R682M016FV2
361R682M016HG2
361R782M016LQ2
361R902M016HV2
361R103M016LV2
10 Vdc (12.5 Vdc Surge)
25 Vdc (32 Vdc Surge)
12000 361R123M010HV2
16 Vdc (20 Vdc Surge)
35 Vdc (44 Vdc Surge)
CDM Cornell Dubilier
•
140 Technology Place
•
Liberty, SC 29657
•
Phone: (864)843-2277
•
Fax: (864)843-3800
•
www.cde.com
Type 361R
105 °C, Miniature, Industrial Grade, Radial Leaded
Cap.
(µF)
330
470
560
820
820
1000
1200
1500
1500
1800
1800
2200
2200
2700
2700
330
470
470
560
680
820
820
1200
1200
1500
1500
1800
1800
2200
2200
150
220
270
390
470
470
560
680
680
820
1000
1000
1000
1200
1500
Catalog
Part Number
361R331M050EG2
361R471M050EK2
361R561M050EM2
361R821M050EN2
361R821M050HH2
361R102M050FK2
361R122M050ER2
361R152M050FF2
361R152M050HK2
361R182M050FQ2
361R182M050HG2
361R222M050LQ2
361R222M050FV2
361R272M050HV2
361R272M050LV2
361R331M063EG2
361R471M063EK2
361R471M063EM2
361R561M063EN2
361R681M063ER2
361R821M063FK2
361R821M063HH2
361R122M063FF2
361R122M063HK2
361R152M063FQ2
361R152M063HG2
361R182M063FV2
361R182M063LQ2
361R222M063HV2
361R222M063LV2
361R151M075EG2
361R221M075EK2
361R271M075EM2
361R391M075EN2
361R471M075FK2
361R471M075HH2
361R561M075ER2
361R681M075FF2
361R681M075HK2
361R821M075FQ2
361R102M075FV2
361R102M075HG2
361R102M075LQ2
361R122M075LV2
361R152M075HV2
ESR Max.
120 Hz
25ºC (Ω)
0.443
0.343
0.266
0.180
0.190
0.156
0.125
0.101
0.106
0.083
0.084
0.081
0.081
0.067
0.065
0.450
0.318
0.318
0.268
0.183
0.220
0.220
0.150
0.150
0.125
0.099
0.100
0.100
0.072
0.083
1.070
0.727
0.600
0.410
0.340
0.340
0.285
0.235
0.235
0.195
0.160
0.161
0.160
0.133
0.107
Ripple A
120 Hz
85ºC (A)
0.760
0.960
1.050
1.380
1.560
1.530
1.810
2.140
2.160
2.440
2.490
2.640
2.600
3.190
3.040
0.760
0.960
0.980
1.150
1.540
1.310
1.420
1.700
1.810
1.980
2.310
2.300
2.580
2.990
2.700
0.450
0.580
0.650
0.870
1.000
1.040
1.160
1.320
1.310
1.520
1.660
1.810
1.700
1.900
2.530
Nom Size
DXL
(mm)
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
22 x 22
16 x 25
12.5 x 42.5
16 x 32
22 x 25
16 x 36
22 x 30
18 x 36
16 x 40
22 x 40
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
12.5 x 42.5
16 x 25
22 x 22
16 x 32
22 x 25
16 x 36
22 x 30
16 x 40
18 x 36
22 x 40
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
22 x 25
16 x 36
16 x 40
22 x 30
18 x 36
18 x 40
22 x 40
Cap.
(µF)
100
120
150
220
220
270
270
330
390
470
470
470
560
680
680
33
47
56
82
100
100
100
150
150
180
220
220
220
270
330
27
47
56
68
82
82
100
120
120
150
180
220
220
270
270
Catalog
Part Number
361R101M100EG2
361R121M100EK2
361R151M100EM2
361R221M100EN2
361R221M100HH2
361R271M100ER2
361R271M100HK2
361R331M100FK2
361R391M100FF2
361R471M100FQ2
361R471M100FV2
361R471M100HG2
361R561M100LQ2
361R681M100HV2
361R681M100LV2
361R330M160EG2
361R470M160EK2
361R560M160EM2
361R820M160EN2
361R101M160ER2
361R101M160FK2
361R101M160HH2
361R151M160FF2
361R151M160HK2
361R181M160FQ2
361R221M160FV2
361R221M160HG2
361R221M160LQ2
361R271M160LV2
361R331M160HV2
361R270M200EG2
361R470M200EK2
361R560M200EM2
361R680M200EN2
361R820M200FK2
361R820M200HH2
361R101M200ER2
361R121M200FF2
361R121M200HK2
361R151M200FQ2
361R181M200HG2
361R221M200FV2
361R221M200LQ2
361R271M200HV2
361R271M200LV2
ESR Max.
120 Hz
25ºC (Ω)
1.650
1.320
1.100
0.750
0.750
0.610
0.520
0.500
0.420
0.350
0.350
0.351
0.290
0.241
0.240
5.000
3.500
2.950
2.000
1.650
1.650
1.650
1.100
1.100
0.920
0.750
0.751
0.750
0.610
0.512
5.900
3.600
3.000
2.500
2.000
2.000
1.650
1.380
1.380
1.100
1.000
0.760
0.760
0.781
0.620
Ripple A
120 Hz
85ºC (A)
0.355
0.450
0.500
0.666
0.760
0.750
0.950
0.875
1.010
1.150
1.250
1.250
1.370
1.690
1.570
0.200
0.250
0.280
0.380
0.460
0.430
0.475
0.580
0.610
0.665
0.770
0.840
0.800
0.920
0.990
0.175
0.250
0.280
0.340
0.390
0.430
0.450
0.520
0.545
0.600
0.730
0.760
0.790
0.940
0.910
Nom Size
DXL
(mm)
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
22 x 22
12.5 x 42.5
22 x 25
16 x 25
16 x 32
16 x 36
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
12.5 x 42.5
16 x 25
22 x 22
16 x 32
22 x 25
16 x 36
16 x 40
22 x 30
18 x 36
18 x 40
22 x 40
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
22 x 25
16 x 36
22 x 30
16 x 40
18 x 36
22 x 40
18 x 40
50 Vdc (63 Vdc Surge)
100 Vdc (125 Vdc Surge)
63 Vdc (79 Vdc Surge)
160 Vdc (185 Vdc Surge)
75 Vdc (90 Vdc Surge)
200 Vdc (225 Vdc Surge)
CDM Cornell Dubilier
•
140 Technology Place
•
Liberty, SC 29657
•
Phone: (864)843-2277
•
Fax: (864)843-3800
•
www.cde.com
Type 361R
105 °C, Miniature, Industrial Grade, Radial Leaded
Cap.
(µF)
Catalog
Part Number
ESR Max.
120 Hz
25ºC (Ω)
Ripple A
120 Hz
85ºC (A)
Nom Size
DXL
(mm)
Cap.
(µF)
33
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
12.5 x 42.5
22 x 22
16 x 32
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
18 x 40
22 x 40
8
12
18
22
27
33
33
12.5 x 20
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
22 x 22
12.5 x 42.5
16 x 32
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
7
10
15
18
22
27
27
33
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
12.5 x 42.5
33
39
39
47
56
68
39
39
47
47
56
68
68
39
47
47
56
56
68
82
82
Catalog
Part Number
361R330M350HH2
361R390M350FF2
361R470M350FQ2
361R470M350HK2
361R560M350FV2
361R560M350HG2
361R680M350LQ2
361R820M350HV2
361R820M350LV2
ESR Max.
120 Hz
25ºC (Ω)
5.000
4.250
3.500
3.500
2.950
2.950
2.420
2.000
2.000
Ripple A
120 Hz
85ºC (A)
0.275
0.295
0.340
0.340
0.385
0.420
0.445
0.590
0.500
Nom Size
DXL
(mm)
22 x 22
16 x 32
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
250 Vdc (300 Vdc Surge)
18
27
33
47
47
56
56
68
82
82
100
120
120
150
180
361R180M250EG2
361R270M250EK2
361R330M250EM2
361R470M250EN2
361R470M250FK2
361R560M250ER2
361R560M250HH2
361R680M250FF2
361R820M250FQ2
361R820M250HK2
361R101M250FV2
361R121M250HG2
361R121M250LQ2
361R151M250LV2
361R181M250HV2
9.200
6.100
5.000
3.500
3.500
2.950
2.950
2.420
2.000
2.000
1.650
1.380
1.380
1.100
0.921
0.145
0.190
0.215
0.285
0.295
0.345
0.350
0.390
0.450
0.450
0.515
0.620
0.585
0.685
0.880
400 Vdc (450 Vdc Surge)
361R080M400EK2
361R120M400EM2
361R180M400EN2
361R220M400FK2
361R270M400ER2
361R330M400FF2
361R330M400HH2
361R390M400FQ2
361R390M400HK2
361R470M400FV2
361R470M400HG2
361R560M400LQ2
361R680M400HV2
361R680M400LV2
20.00
13.80
9.100
7.500
6.100
5.000
5.000
4.200
4.200
3.500
3.510
2.950
2.420
2.420
0.105
0.125
0.175
0.200
0.235
0.275
0.275
0.315
0.315
0.355
0.390
0.400
0.530
0.465
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
12.5 x 42.5
16 x 32
22 x 22
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
22 x 40
18 x 40
300 Vdc (365 Vdc Surge)
12
18
22
33
33
39
47
47
56
56
68
68
82
100
100
361R120M300EG2
361R180M300EK2
361R220M300EM2
361R330M300EN2
361R330M300FK2
361R390M300HH2
361R470M300ER2
361R470M300FF2
361R560M300FQ2
361R560M300HK2
361R680M300FV2
361R680M300HG2
361R820M300LQ2
361R101M300HV2
361R101M300LV2
13.80
9.150
7.500
5.000
5.000
4.250
3.500
3.500
2.950
2.950
2.420
2.420
2.000
1.650
1.650
0.120
0.155
0.175
0.240
0.245
0.295
0.315
0.325
0.375
0.375
0.430
0.480
0.485
0.650
0.555
450 Vdc (500 Vdc Surge)
361R070M450EK2
361R100M450EM2
361R150M450EN2
361R180M450FK2
361R220M450ER2
361R270M450FF2
361R270M450HH2
361R330M450FQ2
361R330M450HK2
361R390M450FV2
361R390M450HG2
361R470M450LQ2
361R560M450LV2
361R680M450HV2
20.00
16.50
11.00
9.100
7.500
6.100
6.100
5.000
5.000
4.200
4.200
3.500
2.950
2.450
0.100
0.120
0.165
0.185
0.215
0.245
0.245
0.285
0.300
0.325
0.350
0.365
0.415
0.530
12.5 x 25
12.5 x 26.5
12.5 x 33.5
16 x 25
12.5 x 42.5
16 x 32
22 x 22
16 x 36
22 x 25
16 x 40
22 x 30
18 x 36
18 x 40
22 x 40
350 Vdc (400 Vdc Surge)
10
15
22
27
33
361R100M350EK2
361R150M350EM2
361R220M350EN2
361R270M350FK2
361R330M350ER2
16.50
11.00
7.500
6.100
5.000
0.115
0.145
0.195
0.225
0.265
CDM Cornell Dubilier
•
140 Technology Place
•
Liberty, SC 29657
•
Phone: (864)843-2277
•
Fax: (864)843-3800
•
www.cde.com
京公网安备 11010802033920号
EEWORLD
