REVISION D
NOTES:
D
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: .038[.0015] MAX ON TAILS.
3. MINIMUM PUSHOUT FORCE: .22 KG [.500 LB]
4. MAXIMUM ALLOWABLE BOW: .05[.002] MM/MM[IN/IN] AFTER ASSEMBLY.
5. PARTS TO BE PACKAGED IN TRAYS AS STANDARD.
HSDC1-1XX-XX-X-D-A-XX
No OF POSITIONS
-20 THRU -50
(PER ROW)
LEAD STYLE
-01: SURFACE MOUNT
(USE C-192-02-X)
OPTION
-P: PICK & PLACE PAD
-TR: TAPE & REEL
ALIGNMENT PIN
-A: ALIGNMENT PIN
ROWS
-D: DOUBLE ROW
PLATING SPECIFICATION
-S: SELECTIVE GOLD (USE C-192-02-S)
-H: HEAVY GOLD (USE C-192-02-H)
SEE TABLE 1
0.20 .008
0.68 .027
(HSDC1-150-01-X-D-A SHOWN)
DO NOT
SCALE FROM
THIS PRINT
FIG 1
(No OF POS -1) x 1.00[.039] .05[.002]
0.23 .009
REF (TYP)
"A"
11.25 .443
REF
HSDC1-50-D-A
1.60 .063 REF (TYP)
2 MAX SWAY (TYP)
"A"
C-192-02-X
12.96 .510
0.72 .028
REF
(No OF POS x 1.00[.038]) + .78[.030] REF
3.13 .123
REF (TYP)
SEE NOTE 2
3.44 .135
REF
0.52 .020
REF
(No OF POS -4) x 1.00[.039] REF
90°
0.79 .031
REF (TYP)
SECTION "A"-"A"
SCALE 4 : 1
3.68±0.08 .145±.003
(MEASURE AT BEND)
124°±1°
114° REF
6.70 .264
4.52 .178
REF
8.38 .330
10.28 .405 REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILIMETERS.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
X.X: 0.3[.01]
X.XX: 0.13[.005]
X.XXX: 0.051[.0020]
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: V143XL, COLOR: BLACK
CONTACT: BeCu
HIGH SPEED DUAL COMPRESSION 1MM
IN-PROCESS 1
SCALE 3:1
IN-PROCESS 2
F:\DWG\MISC\MKTG\HSDC1-1XX-XX-X-D-A-XX-MKT.SLDDRW
BY:
B RAY
HSDC1-1XX-XX-X-D-A-XX
08/24/2007
SHEET
1
OF
2
REVISION D
(HSDC1-150-01-X-D-A-P SHOWN)
PPP-64
FIG 2
(((No OF POS x 1.00) + .78) / 2)-3.175 ±0.508
6.35 .250
REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
HIGH SPEED DUAL COMPRESSION 1MM
F:\DWG\MISC\MKTG\HSDC1-1XX-XX-X-D-A-XX-MKT.SLDDRW
BY:
B RAY
HSDC1-1XX-XX-X-D-A-XX
08/24/2007
SHEET
2
OF
2
