TrueNet
®
Multimode Fiber Optic Patch Cords
As an integral part of the TrueNet
®
Fiber Connectivity product portfolio, ADC’s multimode fiber
optic patch cords are essential to meet the requirements of today’s high-speed data networks.
These patch cords can be used throughout the network in cross-connect, test or equipment areas
to link optical equipment and are backed by the TrueNet Zero-Bit Error Warranty.
Features:
• LC and SC duplex connectors are equipped with a removable duplex clip for simple Tx/Rx
reconfiguration in the field.
• Lead-free OFNP jacket and RoHS compliant
• All patch cords are shipped with insertion loss tests for individual cords
Spec Sheet
• Readily available in LC-LC, LC-SC, and SC-LC configurations in standard lengths of 1, 2,
3, 5, 7, 10, and 15 meters.
• Offered in configurations with standard multimode glass types of 50 micron, 62.5 micron
and 50 micron ultra (laser optimized to 300 meters)
w w w. ad c. c o m
•
+1 - 95 2- 9 38 -8 0 8 0
•
1 -8 0 0 -3 6 6 -3 8 9 1
Specifications
Operating Temperature Range:
Intermatability Standard:
Insertion Loss:
Reflectance:
32º to 158º F (0º to 70º C)
TIA/EIA 604-10 (FOCIS 10)
0.10 typical, 0.30 maximum
<-20 dB (MM)
62.5/125 Multimode Fiber Optic Patch Cords
Ordering Information
Description
62.5/125 multimode; OFNP jacket
2
2mm zipcord SC-LC connectors
2mm zipcord SC-SC connectors
2mm zipcord LC-LC connectors
1
2
Catalog Number
1
PAT-CLM6Q-XXXMPT
PAT-CM6Q-XXXMPT
PAT-LM6Q-XXXMPT
XXX = length in meters: 001 = 1.0m, 002 = 2.0m, 003 = 3.0m, 005 = 5.0m, 007 = 7.0m, 010 = 10.0m, 015 = 15.0m
62.5/125 patch cords do not come standard in 6.0m lengths.
Contact ADC for availability of custom lengths.
50/125 Multimode Fiber Optic Patch Cords
Ordering Information
Description
50/125 multimode - 150 meters @ 10Gigabit; OFNP jacket
2mm zipcord SC-LC connectors
2mm zipcord SC-SC connectors
2mm zipcord LC-LC connectors
1.6mm zipcord LC-LC connectors
PAT-CLM5EQ-XXXMPT
PAT-CM5EQ-XXXMPT
PAT-LM5EQ-XXXMPT
PAT-LM5EV-XXXMPT
PAT-CLM5UQ-XXXMPT
PAT-CM5UQ-XXXMPT
PAT-LM5UQ-XXXMPT
PAT-LM5UV-XXXMPT
Catalog Number
3
Spec Sheet
50/125 multimode - 300 meters @ 10Gigabit; OFNP jacket
2mm zipcord SC-LC connectors
2mm zipcord SC-SC connectors
2mm zipcord LC-LC connectors
1.6mm zipcord LC-LC connectors
1
XXX = length in meters: 001 = 1.0m, 002 = 2.0m, 003 = 3.0m, 005 = 5.0m, 007 = 7.0m, 010 = 10.0m, 015 = 15.0m
Contact ADC for availability of custom lengths.
Website: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our website.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
103064AE 5/08 Revision © 2008, 2007 ADC Telecommunications, Inc. All Rights Reserved
