XC74UL00AA
CMOS Logic
ETR1302_002
■GENERAL
DESCRIPTION
The XC74UL00AA is a 2-input CMOS NAND Gate, manufactured using silicon gate CMOS fabrication.
CMOS low power circuit operation makes high speed LS-TTL operation achievable.
With a wave forming buffer connected internally, stabilized output can be achieved as the circuit offers high noise
immunity.
As the XC74UL00AA is integrated into mini molded, SSOT-25 and SON-6 package, high density mounting is possible.
■APPLICATIONS
●Palmtops
●Digital
equipment
■FEATURES
High Speed Operation
: tpd = 2.6ns (TYP.)
Operating Voltage Range
: 2V ~ 5.5V
Low Power Consumption
: 1μA (MAX.)
CMOS 2-Input NAND Gate
Ultra Small Package
* Under Development
: SSOT-25, SON-6*
■PIN
CONFIGURATION
B
GND
Vcc
Y
A
■FUNCTIONS
INPUT
A
L
L
H
H
H=High level
L=Low level
B
L
H
L
H
OUTPUT
Y
H
H
H
L
SSOT-25
（TOP
VIEW）
XC74UL00AAN
SON-6
（TOP
VIEW）
XC74UL00AAR
■ABSOLUTE
MAXIMUM RATINGS
PARAMETER
Supply Voltage
Input Voltage
Output Voltage
Input Diode Current
Output Diode Current
Output Current
V
CC
,GND Current
Power Dissipation
SSOT-25
＊
1
SON-6
＊
2
SYMBOL
V
CC
V
IN
V
OUT
I
IK
I
OK
I
OUT
I
CC
,I
GND
Pd
Tstg
RATINGS
-0.5~+6.0
-0.5~+6.0
-0.5~V
CC
+0.5
-20
±20
±25
±50
150
200
-65~+150
Ta=-40℃~85℃
UNITS
V
V
V
mA
mA
mA
mA
mW
℃
Storage Temperature Range
Voltage is all ground standardized.
＊1）Ta=55℃
＊2）Ta=25℃
1/4
XC74UL00AA
■RECOMMENDED
OPERATING CONDITIONS
PARAMETER
Supply Voltage
Input Voltage
Output Voltage
Operating Temperature Range
SYMBOL
V
CC
V
IN
V
OUT
Topr
I
OH
Output Current
I
OL
Input Rise and Fall Time
tr,tf
V
CC
(V)
－
－
－
－
3.0
4.5
3.0
4.5
3.3
5.0
CONDITIONS
2~5.5
0~5.5
0~V
CC
-40~+85
-4
-8
4
8
0~100
0~20
ns/V
mA
UNITS
V
V
V
℃
■DC
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
V
CC
(V)
2.0
V
IH
Input Voltage
V
IL
3.0
5.5
2.0
3.0
5.5
2.0
3.0
V
OH
4.5
3.0
Output Voltage
4.5
2.0
3.0
V
OL
4.5
3.0
4.5
Input Current
Static Supply Current
I
IN
I
CC
0~5.5
5.5
V
IN
=V
CC
or GND
V
IN
=V
CC
or GND,I
OUT
=0μA
V
IN
=V
IH
I
OL
=4mA
I
OL
=8mA
I
OL
=50μA
V
IN
=V
IH
or V
IL
I
OH
=-4mA
I
OH
=-8mA
I
OH
=-50μA
CONDITIONS
Ta=25℃
MIN.
1.5
2.1
3.85
－
－
－
1.9
2.9
4.4
2.58
3.94
－
－
－
－
－
-0.1
－
TYP.
－
－
－
－
－
－
2.0
3.0
4.5
－
－
－
－
－
－
－
－
－
MAX.
－
－
－
0.5
0.9
1.65
－
－
－
－
－
0.1
0.1
0.1
0.36
0.36
0.1
1.0
Ta=-40℃~85℃
MIN.
1.5
2.1
3.85
－
－
－
1.9
2.9
4.4
2.48
3.80
－
－
－
－
－
-1.0
－
MAX.
－
－
－
0.5
0.9
1.65
－
－
－
－
－
0.1
0.1
0.1
0.44
0.44
1.0
10.0
μA
V
V
V
V
UNITS
■SWITCHING
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
C
L
15pF
V
CC
(V)
3.3
5.0
3.3
5.0
3.3
5.0
3.3
5.0
5.0
V
IN
=V
CC
or GND
CONDITIONS
Ta=25℃
MIN.
－
－
－
－
－
－
－
－
－
－
TYP.
3.7
2.7
5.4
3.6
3.3
2.5
4.6
3.5
2
9.3
MAX.
7.9
5.5
11.4
7.5
7.9
5.5
11.4
7.5
10
－
Ta=-40℃~85℃
MIN.
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
－
－
MAX.
9.5
6.5
13.0
8.5
9.5
6.5
13.0
8.5
10
－
tr=tf=3ns
UNITS
ns
t
PLH
50pF
Delay Time
t
PHL
15pF
ns
ns
50pF
Input Capacitance
Power Dissipation Capacitance
C
IN
Cpd
－
ns
pF
pF
No Load, f=1MHz
2/4
XC74UL00AA
1. The products and product specifications contained herein are subject to change without
notice to improve performance characteristics.
Consult us, or our representatives
before use, to confirm that the information in this catalog is up to date.
2. We assume no responsibility for any infringement of patents, patent rights, or other
rights arising from the use of any information and circuitry in this catalog.
3. Please ensure suitable shipping controls (including fail-safe designs and aging
protection) are in force for equipment employing products listed in this catalog.
4. The products in this catalog are not developed, designed, or approved for use with such
equipment whose failure of malfunction can be reasonably expected to directly
endanger the life of, or cause significant injury to, the user.
(e.g. Atomic energy; aerospace; transport; combustion and associated safety
equipment thereof.)
5. Please use the products listed in this catalog within the specified ranges.
Should you wish to use the products under conditions exceeding the specifications,
please consult us or our representatives.
6. We assume no responsibility for damage or loss due to abnormal use.
7. All rights reserved. No part of this catalog may be copied or reproduced without the
prior permission of Torex Semiconductor Ltd.
