XC74WLU04ASR
CMOS Logic
ETR1327_001
■GENERAL
DESCRIPTION
XC74WLU04ASR is triple inverter (unbuffered) manufactured using silicon gate CMOS processes.
enables LS-TTL.
With wave forming buffers connected internally, stabilized output can be achieved as the series offers high noise
immunity.
As the series is integrated into a mini molded, MSOP-8B package, high density mounting is possible.
The
small supply current, which is one of the features of the CMOS logic, gives way to high speed operations which
■Applications
●Palmtops
●Digital
equipment
■FEATURES
High Speed Operations
: tpd = 2.3ns (TYP.) (V
CC
=5V)
Operating Voltage Range
: 2V ~ 5.5V
Low Power Consumption
: 1μA (MAX.)@Ta=25℃
CMOS Logic Triple Inverter(Unbufferd)
Small Package
: MSOP-8B
■PIN
CONFIGURATION
■FUNCTIONS
INPUT
A
H
L
H=High level
L=Low level
OUTPUT
Y
L
H
■ABSOLUTE
MAXIMUM RATINGS
PARAMETER
Supply Voltage
Input Voltage
Output Voltage
Input Diode Current
Output Diode Current
Switch Output Current
V
CC
,GND Current
Power Dissipation (Ta = 25℃)
Storage Temperature Range
Note : Voltage is all ground standardized.
Ta=-40℃~85℃
SYMBOL
V
CC
V
IN
V
OUT
I
IK
I
OK
I
OUT
I
CC
,I
GND
Pd
Tstg
RATINGS
-0.5~+6.0
-0.5~+6.0
-0.5~V
CC
+0.5
-20
±20
±25
±50
300
-65~+150
UNITS
V
V
V
mA
mA
mA
mA
mW
℃
1/4
XC74WLU04ASR
1. The products and product specifications contained herein are subject to change without
notice to improve performance characteristics.
Consult us, or our representatives
before use, to confirm that the information in this catalog is up to date.
2. We assume no responsibility for any infringement of patents, patent rights, or other
rights arising from the use of any information and circuitry in this catalog.
3. Please ensure suitable shipping controls (including fail-safe designs and aging
protection) are in force for equipment employing products listed in this catalog.
4. The products in this catalog are not developed, designed, or approved for use with such
equipment whose failure of malfunction can be reasonably expected to directly
endanger the life of, or cause significant injury to, the user.
(e.g. Atomic energy; aerospace; transport; combustion and associated safety
equipment thereof.)
5. Please use the products listed in this catalog within the specified ranges.
Should you wish to use the products under conditions exceeding the specifications,
please consult us or our representatives.
6. We assume no responsibility for damage or loss due to abnormal use.
7. All rights reserved. No part of this catalog may be copied or reproduced without the
prior permission of Torex Semiconductor Ltd.
4/4
