05484
Only One Name Means ProTek’Tion™
DSL70
ULTRA LOW CAPACITANCE STEERING DIODE ARRAY
DESCRIPTION
The DSL70 is an ultra low capacitance steering diode array. Designed for protection against Electrostatic Discharge
(ESD), Electrical Fast Transients (EFT) and secondary lightning threats, this device is ideal for use in high-speed signal
interface application such as USB, microprocessor bus and mobile electronics.
The DSL70 is capable of protecting one line pair or two single lines via the steering of transient voltage to power lines
or ground. Its ultra low capacitance allows maintenance of signal integrity for high-speed data lines while protecting
the circuit ICs from the damage of severe transients. An extremely low leakage current makes the DSL70 suitable for
battery powered devices and POE applications. The DSL70 is available in the small SOT-143 package, which reduces
internal lead inductance for low, overshoot voltage during fast front time transient events like ESD. This device meets
the IEC 61000-4-2 and IEC 61000-4-4 requirements.
SOT-143 PACKAGE
FEATURES
APPLICATIONS
•
•
•
•
•
•
XDSL
USB Interface Ports
POE Applications
Video
Handheld Electronics
Laptops
•
Compatible with IEC 61000-4-2 (ESD): Air - 15kV, Contact - 8kV
•
Compatible with IEC 61000-4-4 (EFT): 40A - 5/50ns
•
Compatible with IEC 61000-4-5 (Surge): 30A, 8/20µs - Level 2(Line-
Gnd) & Level 3 (Line-Line)
•
225 Milliwatts Continuous Power Dissipation
•
Provides Two Lines of Protection
•
Low Leakage Current
•
Ultra Low Capacitance: 3pF Typical
•
RoHS Compliant
•
REACH Compliant
MECHANICAL CHARACTERISTICS
Molded JEDEC SOT-143 Package
Approximate Weight: 9 milligrams
Lead-Free Pure-Tin Plating (Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
•
8mm Tape and Reel Per EIA Standard 481
•
Flammability Rating UL 94V-0
•
•
•
•
PIN CONFIGURATION
V
N
1
4 V
P
I/O 1 2
3 I/O 2
05484.R1 11/15
Page 1
www.protekdevices.com
05484
Only One Name Means ProTek’Tion™
DSL70
TYPICAL DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
Forward Peak Pulse Current (tp = 8/20µs)
SYMBOL
T
A
T
STG
I
PP
VALUE
-55 to 150
-55 to 150
27
UNITS
°C
°C
A
ELECTRICAL CHARACTERISTICS PER LINE
@ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
REPETITIVE
PEAK
REVERSE
VOLTAGE
V
RRM
VOLTS
DSL70
NOTES
PSA
50
MINIMUM
REVERSE
BREAKDOWN
VOLTAGE
I @ 50µA
V
(BR)
VOLTS
85
MAXIMUM
REVERSE
LEAKAGE
CURRENT
@ V
RRM
I
R
µA
0.005
MAXIMUM
FORWARD
CLAMPING
VOLTAGE
8/20µs
I
PP
@ 1A
V
FC
VOLTS
1.5
MAXIMUM
FORWARD
CLAMPING
VOLTAGE
8/20µs
I
PP
@ 27A
V
FC
VOLTS
9
MAXIMUM
CAPACITANCE
(Note 1)
0V, 1MHz
C
J
pF
5
1. Measured between I/O pins to GND pins.
2. Measured between I/O pins.
I
PP
- Peak Pulse Current - % of I
PP
MAXIMUM
FORWARD
CLAMPING
VOLTAGE
8/20µs
I
PP
@ 10A
V
FC
VOLTS
6
MAXIMUM
FORWARD
CLAMPING
VOLTAGE
8/20µs
I
PP
@ 24A
V
FC
VOLTS
9
MAXIMUM
CAPACITANCE
(Note 2)
0V, 1MHz
C
J
pF
2.5
120
100
80
60
40
20
0
0
5
t
f
FIGURE 1
PULSE WAVE FORM
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
e
-t
t
d
= t/(I
PP
/2)
10
15
t - Time - µs
20
25
30
05484.R1 11/15
Page 2
www.protekdevices.com
05484
Only One Name Means ProTek’Tion™
DSL70
SOT-143 PACKAGE INFORMATION
OUTLINE DIMENSIONS
DIM
A
B
C
D
F
G
J
K
L
L1
R
S
NOTES
A
G
L
MILLIMETERS
MIN
2.80
1.20
0.84
0.39
0.79
1.78
0.08
0.46
0.445
0.40
0.72
2.11
INCHES
MIN
0.110
0.047
0.033
0.015
0.031
0.070
0.003
0.018
0.0175
0.016
0.028
0.083
MAX
3.04
1.39
1.14
0.50
0.93
2.03
0.15
0.60
0.60
0.60
0.83
2.48
MAX
0.120
0.055
0.045
0.020
0.037
0.080
0.006
0.024
0.024
0.024
0.033
0.098
H
C
F
D
B S
L1
K
J
R
1. Dimensioning and tolerances per ANSI Y14.M, 1985.
2. Controlling dimension: inches.
3. Dimensions are exclusive of mold flash and metal burrs.
PAD LAYOUT DIMENSIONS
DIM
A
B
C
D
E
F
NOTES
C
A
MILLIMETERS
MIN
1.88
1.80
0.71
0.76
1.07
0.71
INCHES
MIN
0.074
0.071
0.028
0.030
0.042
0.028
MAX
2.13
2.06
0.97
1.02
1.32
0.97
MAX
0.084
0.081
0.038
0.040
0.052
0.038
E
F
D
B
1. Controlling dimension: inches.
05484.R1 11/15
Page 4
www.protekdevices.com
05484
Only One Name Means ProTek’Tion™
DSL70
TAPE AND REEL
P0
t
D
P2
10 Pitches Cumulative
Tolerance on Tape. ± 0.2
E
Top Cover Tape
A0
K0
Pin 1
F
W
B0
P
User Direction of Feed
SPECIFICATIONS
REEL DIA.
178mm (7”)
1.
2.
3.
4.
5.
TAPE
WIDTH
8mm
A0
B0
K0
D
E
F
W
P0
P2
P
tmax
0.25
3.10 ± 0.10 2.70 ± 0.10 1.35 ± 0.10 1.50 ± 0.10 1.75 ± 0.10 3.50 ± 0.05 8.00 ± 0.30 4.00 ± 0.10 2.00 ± 0.05 4.00 ± 0.10
NOTES
Dimensions are in millimeters.
Surface mount product is taped and reeled in accordance with EIA-481.
Suffix - T7 = 7” Reel - 3,000 pieces per 8mm tape.
Suffix - T13 = 13” Reel - 10,000 pieces per 8mm tape.
Marking on Part - marking code (see page 2) and date code.
ORDERING INFORMATION
BASE PART NUMBER
DSL70
DSL70
LEADFREE SUFFIX
n/a
n/a
TAPE SUFFIX
-T7
-T13
QTY/REEL
3000
10,000
REEL SIZE
7”
13”
TUBE QTY
n/a
n/a
This device is only available in a Lead-Free configuration.
05484.R1 11/15
Page 5
www.protekdevices.com
