TA053-059-22-10
REV1_20040412
5.3 – 5.9 GHz Low Noise Amplifier
FEATURES
•
P
-1
dB: 10 dBm
•
Noise Figure: 1 dB
•
IP3: 20 dBm
•
Bias Condition: 90 mA @ 12 V
•
Small Signal Gain: 22 dB
DESCRIPTION
The TA053-059-22-10 is a low noise amplifier designed for applications in the 5.3 to 5.9 GHz frequency
range. This amplifier utilizes low noise devices that provide excellent noise figure. High efficiency
operation is achieved by using hybrid MIC designs and advanced GaAs PHEMT devices. The amplifier
requires only a +12V DC power supply.
ELECTRICAL SPECIFICATIONS at 25
°
C
Symbol
FREQ
SSG
GOF
P
-1
dB
IP3
NF
VSWR, IN
VSWR, OUT
VDC
IDC
OTR
Description
Frequency Range
Small Signal Gain
Small Signal Gain Flatness
Output Power at 1 dB Gain Compression
Third Order Intercept Point
Noise Figure
Input VSWR
Output VSWR
DC Supply Voltage (with built-in regulator)
Current Supply
Operating Temperature Range
Min.
5.3
22
10
20
1.0
1.5:1
1.5:1
12
90
-30
1.1
1.7:1
1.7:1
110
60
Typ.
±
0.5
Max.
5.9
±
0.75
Unit
GHz
dB
dB
dBm
dBm
dB
-
-
Volt
mA
°C
CASE: HG2
Note: The previous product part number of TA053-059-22-10 is TC5561G.
TRANSCOM, INC.,
90 Dasoong 7
th
Road, Tainan Science-Based Industrial Park, Hsin-She Shiang, Tainan County, Taiwan, R.O.C.
Web-Site: www.transcominc.com.tw
Phone: 886-6-5050086
Fax: 886-6-5051602
P1/1
