Power Choke Coil
PCMC series,PCMB series
•
Small size of 7.3mm 6.6mm and
*High speed drive DC/DC inverter for
Applications
server, router etc.
low tap of 3.0mm max
•
Excellent loss characteristics and
*CPU power for note PC and desktop PC
high saturation current
Completely lead free
RoHS compliant
SPECIFICATIONS
Mechanical
L
A
A1
B1
Equivalent
circuit
Dimension
(Inch Size)
PCMC063
(2926)
W
B
L
W
T
A
A1
B
B1
7.3max.
6.6 0.2
3.0max.
2.0 0.1
1.3 0.3
3.6 0.2
3.0 0.3
PCMC104 (4539)
104T
104E
11.5max.
10 0.2
4.0max.
4.5max.
2.5 0.1
2.0 0.5
5.0 0.2
3.0 0.2
PCMC133
(5450)
PCMC135
(5450)
13.8max.
12.6 0.2
3.5max.
2.5 0.1
2.0 0.5
6.0 0.2
4.0 0.3
13.8max.
12.6 0.2
5.0max.
2.5 0.1
2.0 0.5
6.0 0.2
4.0 0.3
( unit : mm)
Electrical
063 type
104 type
Rdc(m )
Rated current Saturation current
L0( H)
(A)
(A)
Typical MAX.
Inductance
60.0
30.0
1.2
1.1
0.36
40.0
25.0
1.8
1.6
0.56
38.0
20.0
3.0
2.7
0.88
PCMC104Ｔ
36.0
18.0
3.3
3.0
1.00
33.0
16.0
4.2
3.8
1.50
27.0
12.0
7.0
6.7
2.20
27.0
25.0
1.3
1.1
0.45
6.0
6.0
30.0
27.5
10.0
16.0
14.0
7.0
5.8
2.20
PCMB104E
14.5
11.0
13.2
11.0
3.30
13.0
10.0
15.0
13.2
4.70
Rdc(m )
Rated current Saturation current
L0( H)
(A)
(A)
Inductance
Typical MAX.
60.0
32.5
1.7
1.5
0.10
41.0
24.0
3.0
2.4
0.20
52.0
26.0
2.5
1.9
0.22
30.0
20.0
3.9
3.5
0.33
26.0
17.5
4.2
4.0
0.47
25.0
15.5
5.5
5.0
0.68
PCMC063Ｔ
24.0
13.0
8.0
6.7
0.82
22.0
11.0
10.0
9.0
1.00
20.0
10.0
12.0
10.0
1.20
18.0
9.0
15.0
14.0
1.50
14.0
8.0
20.0
18.0
2.20
13.5
6.0
30.0
28.0
3.30
10.0
5.5
40.0
37.0
4.70
11.5
9.0
12.0
10.8
1.50
10.0
8.0
20.0
18.0
2.20
PCMB063Ｔ
6.5
5.5
35.0
32.5
4.70
6.0
4.5
60.0
54.0
8.20
5.5
4.0
68.0
62.0
10.0
135 type
Rdc(m )
Rated current Saturation current
L0( H)
(A)
(A)
Inductance
Typical MAX.
75.0
41.0
1.1
0.77
0.36
65.0
38.0
1.3
1.1
0.47
55.0
36.0
1.5
1.2
0.50
55.0
36.0
1.5
1.2
0.56
54.0
34.0
1.7
1.5
0.68
50.0
29.0
2.5
2.1
1.00
48.0
23.0
4.1
3.4
1.50
35.0
20.0
5.0
4.0
2.20
32.0
15.0
9.2
7.7
3.30
133 type
Rdc(m )
Rated current Saturation current
L0( H)
(A)
(A)
Inductance
Typical MAX.
1.8
50.0
0.56
29.0
2.2
49.0
0.68
2.3
28.0
2.5
40.0
1.00
24.0
3.3
3.5
29.0
2.20
16.0
8.0
7.2
PCMC135T
PCMC133E
* The data is measured at 25 C
* Rated current signify current value at temperature raise of 40 C
* Saturation current signify current value at inductance change of 20%
PART NUMBER
PCMC 104T - R56 M N
Materials
Inductance tolerance M
20%
Inductance value (R56 0.56 H, R68 0.68 H)
Dimensions (063T 6.6*7.3*3.0mm, 104T 10*11.5*4.0mm,
133E 12.6*13.8*3.5mm,135T 12.6*13.8*5.0mm)
Part Code
susumu group catalog
