GB-339 SERIES
Full-Color, LED Lamps
(5mm, 4 Pins)
DESCRIPTION:
The 339 Full Color series is full color LED in 5mm round package with 4 pins and white
diffused or water clear lens.
It is perfect for use in full color commercial LED display and indicators.
The semi-conductor materials used are:
GB-339RPGBW & GB-339RPGBC: AlGaInP for Red, InGaN for Blue and True Green
GB-339RPGBW-A & GB-339RPGBC-A: AlGaAs for Red, InGaN for Blue and True Green
PACKAGE DIMENSIONS
1
2
3
4
1
1
2
3
4
2
3
4
φ5.0
(.197)
5.8 (.228)
1
2
3
4
True Green Anode
Blue Anode
Common Cathode
Red Anode
True Green Cathode
Blue Cathode
Common Anode
Red Cathode
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Reverse Voltage
Reverse Current (Vr =5V)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
(1.6mm (1/16)From Body)
5 Volt
100µA
-40
o
C To 85
o
C
o
o
-40 C To 100 C
o
260 C For 5 Seconds
o
8.6(.339)
1.0 (.04)
Note 3
0.6 (.024)
25.0 (.984)
MIN
26.0 (1.024)
MIN
0.5 (.02)
27.0(1.063)
MIN
0.5 (.02)
NOTES : 1. All dimensions are in millimeters.
2. Lead spacing is measured where the leads emerge from the package.
3. Protuded resin under flange is 1.5 mm (0.059") Max.
4. Specifications are subject to change without notice.
1.27 (.05)
1.27 (.05)
1 2 3 4
1.27 (.05)
Unit: mm
Tol: +/- 0.2mm
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Emitted
Color
Ultra Red
GB-339RPGBC-A
(Common Anode Type)
o
Part No.
Lens
Color
Peak
Wavelength
λp
(nm)
660
Vf (v)
Min Max
1.6
2.8
2.8
1.6
2.8
2.8
1.6
2.8
2.8
1.6
2.8
2.8
2.6
4.0
4.0
2.6
4.0
4.0
2.5
4.0
4.0
2.5
4.0
4.0
Rec.
If (mA).
20
20
20
20
20
20
20
20
20
20
20
20
Iv (mcd)
Min Typ.
350
700
200
60
250
70
350
700
200
120
200
60
750
1500
400
140
500
150
750
1500
400
250
450
130
View
Angle
2θ
1/2
(Deg)
35
35
35
65
65
65
35
35
35
65
65
65
True Green
Blue
Ultra Red
Water Clear
525
468
660
GB-339RPGBW-A
(Common Anode Type)
True Green
Blue
Ultra Red
White Diffused
525
468
635
GB-339RPGBC
(Common Cathode Type)
True Green
Blue
Ultra Red
Water Clear
525
468
635
GB-339RPGBW
(Common Cathode Type)
True Green
Blue
White Diffused
525
468
TESTING CONDITION FOR EACH PARAMETER :
PARAMETER:
REVERSE VOLTAGE
REVERSE CURRENT
FORWARD VOLTAGE
LUMINOUS INTENSITY
VIEWING ANGLE
RECOMMENDED
OPERATING CURRENT
SYMBOL
Vr
Ir
Vf
Iv
2θ
1/2
If (Rec)
UNIT
VOLT
µA
VOLT
MCD
DEGREE
0.7
SPATIAL DISTRIBUTION :
0
o
10
o
20
o
30
o
0
o
10
o
20
o
TEST CONDITION
Vr = 5.0 Volt
If = 20mA
If = 20mA
If = 20mA
1.0
0.9
0.8
30
o
40
o
50
o
60
o
70
o
80
o
1.0
0.9
0.8
0.7
mA
0.5
0.3 0.1
0.2
0.4
Water Diffused Lens
0.6
90
o
0.5
0.3 0.1
0.2
0.4
Water Clear Lens
0.6
