Networking
Components
ELECTRICAL CHARACTERISTICS @25 C
Model
DPS0501B
DPS0502B
DPS05U09D
DCS05U09MD
o
ETHERNET DC/DC CONVERTER
IN 5VDC OUT 9VDC
Input Voltage
Output Voltage
Output
Regulated
Nominal / Range (VDC)
(VDC)
Current (mA)
Output
5
5
5
5
4.75-5.25
4.75-5.25
4.75-5.25
4.75-5.25
9
9
9
9
120
200
200
200
N
N
N
N
Enable
Function
N
N
N
N
Efficiency
(%) TYPE
70
70
75
75
Isolation
500VDC
500VDC
500VAC
500VAC
M
ECHANICAL CONSTRUCTION
DPS0501B, DPS0502B
A
*B
50
S0 3
D P 963
L
D E E IN
D
M A NA
I
CH
R
S
FO M O
C
:B
EV
R
C
1 2 3
9 10 11 12
D
I
J
TOP VIEW
E
B
H
UNIT : mm / inch
A = 31.50 0.254 / 1.240
B = 8.85 / 0.384 MAX
0.010
PART NO. & DATE CODE
PIN
DPS050*B
DEL
MADE IN
CHINA
FOR
REV:B COMS
1
2
3
9
12
11 10 9
G
F
3 2 1
10
11
12
SINGLE OUTPUT
+Vin
NC
NC
NC
-Vout
+Vout
-Vin
C = 15.20 0.254 / 0.598
D = 3.20 0.30 / 0.126
E = 2.54 / 0.100 TYP
F = 1.20 0.127 / 0.047
G = 0.51 0.127 / 0.020
H = 0.254 0.127 / 0.010
I = 15.24 / 0.600 (TYP)
J = 27.94 / 1.100 (TYP)
0.010
0.012
0.005
0.005
0.005
BOTTOM VIEW
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
31-1, SHIEN PAN ROAD, KUEI SAN INDUSTRIAL ZONE, TAOYUAN SHIEN, TAIWAN, R.O.C.
TEL: 886-3-3626301; FAX: 886-3-3618901
www.deltaww.com/products/networking/
79
Networking
Components
ETHERNET DC/DC CONVERTER
IN 5VDC OUT 9VDC
M
ECHANICAL CONSTRUCTION
DPS05U09D
A
UNIT: mm / inch
DPS05U09D
MADE IN CHINA
B
DATE CODE
J
C
D
A = 33.60 0.254 / 1.323 0.010
B = 15.20 0.254 / 0.598 0.010
C = 12.30 0.254 / 0.484 0.010
D = 3.20 0.30 / 0.126 0.012
E = 2.54 / 0.100 (TYP)
F = 1.60 0.127 / 0.063 0.005
G = 0.51 0.127 / 0.020 0.005
H = 27.94 / 1.100 (TYP)
I = 0.25 0.127 / 0.010 0.005
J = 16.00 0.254 / 0.630 0.010
H
E
46
00 A
9D HIN
U0 C
05 IN
PS ADE
D M
G
K
1 2
10 11 12
F
I
24 23
15 14 13
PIN
1, 24
10,15
11,14
12,13
OTHERS
FUNCTION
+Vin
-Vout
+Vout
-Vin
NC
K = 20.32 / 0.800 (TYP)
DCS05U09MD
A
B
DATE CODE
UNIT: mm / inch
A = 24.80 0.50 / 0.976 0.020
B = 9.90 0.50 / 0.390 0.020
C
D
I
E
F
BOTTOM VIEW
16
11 10 9
1
6
7
8
DCS05U09MD
DC
5
S0
U0
9
MD
00
50
C = 11.50 0.50 /0.450 0.020
D = 3.20 0.30 / 0.126 0.012
E = 0.50 / 0.020 (TYP)
F = 0.254 / 0.010 (TYP)
PIN
FUNCTION
+Vin
-Vin
+Vout
-Vout
G = 2.54 / 0.010 (TYP)
H = 7.62 / 0.300 (TYP)
I = 17.78 / 0.700 (TYP)
J = 12.70 / 0.500 (TYP)
G
H
S
CHEMATICS
+
VIN
INPUT
FILTER
J
1,16
8, 9
7,10
6,11
DPS0501B, DPS0502B, DPS05U09D, DPS05V09MD
POWER
OSCILLATOR
RECTIFIERS
LOW PASS
FILTER
+
VOUT
-
-
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
31-1, SHIEN PAN ROAD, KUEI SAN INDUSTRIAL ZONE, TAOYUAN SHIEN, TAIWAN, R.O.C.
TEL: 886-3-3626301; FAX: 886-3-3618901
www.deltaww.com/products/networking/
80
