HIT673-EQ Overview

Silicon PNP Epitaxial

HIT673-EQ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	TO-92
package instruction	SC-43A, 3 PIN
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	NOT FOR AUTOMOTIVE OR INDUSTRIAL USE
Maximum collector current (IC)	0.5 A
Collector-emitter maximum voltage	50 V
Configuration	SINGLE
Minimum DC current gain (hFE)	60
JEDEC-95 code	TO-92
JESD-30 code	O-PBCY-T3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	PNP
Maximum power dissipation(Abs)	0.4 W
Certification status	Not Qualified
surface mount	NO
Terminal surface	NOT SPECIFIED
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

Silicon PNP Epitaxial

REJ03G1608-0100

Rev.1.00

Nov 28, 2007

Features

•

Low frequency power amplifier

•

Complementary pair with HIT1213

Outline

RENESAS Package code: PRSS0003DA-A

(Package name: TO-92 (1))

1. Emitter

2. Collector

3. Base

Absolute Maximum Ratings

(Ta = 25°C)

Item

Collector to base voltage

Collector to emitter voltage

Emitter to base voltage

Collector current

Collector peak current

Collector power dissipation

Junction temperature

Storage temperature

Note:

≤

10 ms, Duty cycle

≤

20%

Symbol

CBO

CEO

EBO

C (peak) Note

Tstg

Ratings

–50

–5

–0.5

–1.0

0.4

150

–55 to +150

Unit

°C
