RD74LVC1G02

2–input NOR Gate

REJ03D0703–0100

Rev.1.00

Feb 23, 2006

Description

The RD74LVC1G02 has two–input NOR gate in a 5-pin package. Low voltage and high-speed operation is suitable for

the battery powered products (e.g., notebook computers), and the low power consumption extends the battery life.

Features

The basic gate function is lined up as renesas uni logic series.

Supply voltage range : 1.65 to 5.5 V

Operating temperature range: –40 to +85°C

All inputs: V

(Max.) = 5.5 V (@V

= 0 V to 5.5 V)

All outputs: V

(Max.) = 5.5 V (@V

= 0 V)

Output current:

±4 mA (@V

= 1.65 V)

±8 mA (@V

= 2.3 V)

±24 mA (@V

= 3.0 V)

±32 mA (@V

= 4.5 V)

•

Ordering Information

Part Name

RD74LVC1G02WPE

Package Type

WCSP-5 pin

Package Code

(Previous Code)

SXBG0005LB–A

(TBS-5CV)

Package

Abbreviation

Taping Abbreviation

(Quantity)

E (3,000 pcs/reel)

•

Article Indication

Marking

Year code

Month code

E3YM

Rev.1.00 Feb 23, 2006 page 1 of 7
