RD74LVC1G04
Inverter
REJ03D0509-0100
Rev.1.00
Oct. 06, 2005
Description
The RD74LVC1G04 has an inverter in a 5-pin package. Low voltage and high-speed operation is suitable for the
battery powered products (e.g., notebook computers), and the low power consumption extends the battery life.
Features
The basic gate function is lined up as Renesas uni logic series.
Supply voltage range : 1.65 to 5.5 V
Operating temperature range: –40 to +85°C
All inputs: V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs: V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
Output current:
±4 mA (@V
CC
= 1.65 V)
±8 mA (@V
CC
= 2.3 V)
±24 mA (@V
CC
= 3.0 V)
±32 mA (@V
CC
= 4.5 V)
•
Ordering Information
Package Code
Part Name
RD74LVC1G04WPE
Package Type
WCSP-5pin
5pin
(Previous Code)
SXBG0005LB-A
(TBS-5CV)
Package
Abbreviation
WP
Taping Abbreviation
(Quantity)
E (3,000 pcs/reel)
•
•
•
•
•
•
Article Indication
Marking
Year code
Month code
E5YM
Rev.1.00 Oct. 06, 2005 page 1 of 7
RD74LVC1G04
Pin Arrangement
0.7 mm
Height 0.4 mm
0.4 mm pitch
0.17 mm 5–Ball (WP) GND
3
4
Y
A
2
1.1 mm
Pin#1 INDEX
DNU*
1
5
V
CC
DNU: Do not use.
(Bottom view)
(Top view)
Logic Diagram
Y
A
Function Table
Input A
H
L
H: High level
L: Low level
Output
Y
L
H
Rev.1.00 Oct. 06, 2005 page 2 of 7
RD74LVC1G04
Absolute Maximum Ratings
Item
Supply voltage range
Input voltage range
*1
*1, 2
Symbol
V
CC
V
I
V
O
I
IK
I
OK
I
O
I
CC
or I
GND
θ
ja
Tstg
Ratings
–0.5 to 6.5
–0.5 to 6.5
–0.5 to V
CC
+0.5
–0.5 to 6.5
–50
–50
±50
±100
200
–65 to 150
Unit
V
V
V
mA
mA
mA
mA
°C/W
°C
WP
Test Conditions
Output voltage range
Input clamp current
Output clamp current
Output : H or L
V
CC
: OFF
V
I
< 0
V
O
< 0
V
O
= 0 to V
CC
Continuous output current
Continuous current through
V
CC
or GND
Package Thermal impedance
Storage temperature
Notes:
The absolute maximum ratings are values, which must not individually be exceeded, and furthermore no two
of which may be realized at the same time.
1. The input and output voltage ratings may be exceeded if the input and output clamp-current ratings are
ngs
observed.
2. This value is limited to 5.5 V maximum.
Recommended Operating Conditions
Item
Supply voltage range
Input voltage range
Output voltage range
Output current
Symbol
V
CC
V
I
V
O
I
OL
Min
1.65
0
0
—
—
—
—
—
I
OH
—
—
—
—
—
Input transition rise or fall rate
∆
∆t
/
∆v
0
0
0
Operating free-air temperature
T
a
–40
Note: Unused or floating inputs must be held high or low.
Max
5.5
5.5
V
CC
4
8
16
24
32
–4
–8
–16
–24
–32
20
10
5
85
°C
ns / V
V
CC
= 4.5 V
V
CC
= 1.65 to 1.95 V,
2.3 to 2.7 V
V
CC
= 3.0 to 3.6 V
V
CC
= 4.5 to 5.5 V
V
CC
= 4.5 V
V
CC
= 1.65 V
V
CC
= 2.3 V
V
CC
= 3.0 V
Unit
V
V
V
mA
V
CC
= 1.65 V
V
CC
= 2.3 V
V
CC
= 3.0 V
Conditions
Rev.1.00 Oct. 06, 2005 page 3 of 7
RD74LVC1G04
Electrical Characteristics
Ta = –40 to 85°C
Item
Input voltage
Symbol
V
IH
V
CC
(V)
1.65 to 1.95
2.3 to 2.7
3.0 to 3.6
4.5 to 5.5
V
IL
1.65 to 1.95
2.3 to 2.7
3.0 to 3.6
4.5 to 5.5
Output voltage
V
OH
Min to Max
1.65
2.3
3.0
4.5
V
OL
Min to Max
1.65
2.3
3.0
4.5
Input current
Quiescent
supply current
I
IN
I
CC
∆I
CC
Output leakage
current
Input capacitance
I
OFF
C
IN
0 to 5.5
5.5
3 to 5.5
0
3.3
Min
V
CC
×0.65
1.7
2.0
V
CC
×0.7
—
—
—
—
V
CC
–0.1
1.2
1.9
2.4
2.3
3.8
—
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
3.5
Max
—
—
—
—
V
CC
×0.35
0.7
0.8
V
CC
×0.3
—
—
—
—
—
—
0.1
0.45
0.3
0.4
0.55
0.55
±5
10
500
±10
—
µA
pF
µA
µA
V
I
OH
= –100
µA
I
OH
= –4 mA
I
OH
= –8 mA
I
OH
= –16 mA
I
OH
= –24 mA
I
OH
= –32 mA
I
OL
= 100
µA
I
OL
= 4 mA
I
OL
= 8 mA
I
OL
= 16 mA
I
OL
= 24 mA
I
OL
= 32 mA
V
IN
= 5.5 V or GND
V
IN
= V
CC
or GND,
I
O
= 0
One input at V
CC
–0.6 V,
Other input at V
CC
or GND
V
IN
or V
O
= 0 to 5.5 V
V
IN
= V
CC
or GND
Unit
V
Test condition
Note: For conditions shown as Min or Max, use the appropriate values under recommended operating conditions.
Rev.1.00 Oct. 06, 2005 page 4 of 7
RD74LVC1G04
Switching Characteristics
V
CC
= 1.8 ± 0.15 V
Ta = –40 to 85°C
Item
Propagation delay time
Symbol
t
PLH
t
PHL
Min
2.0
3.0
Max
6.4
7.5
Unit
ns
Test Conditions
C
L
= 15 pF, R
L
= 1 MΩ
C
L
= 30 pF, R
L
= 1.0 kΩ
A
FROM
(Input)
Y
TO
(Output)
V
CC
= 2.5 ± 0.2 V
Ta = –40 to 85°C
Item
Propagation delay time
Symbol
t
PLH
t
PHL
Min
1.0
1.4
Max
4.2
5.2
Unit
ns
Test Conditions
C
L
= 15 pF, R
L
= 1 MΩ
C
L
= 30 pF, R
L
= 500
Ω
A
FROM
(Input)
Y
TO
(Output)
V
CC
= 3.3 ± 0.3 V
Ta = –40 to 85°C
Item
Propagation delay time
Symbol
t
PLH
t
PHL
Min
0.7
1.0
Max
3.3
4.2
Unit
ns
Test Conditions
C
L
= 15 pF, R
L
= 1 MΩ
C
L
= 50 pF, R
L
= 500
Ω
A
FROM
(Input)
Y
TO
(Output)
V
CC
= 5.0 ± 0.5 V
Ta = –40 to 85°C
Item
Propagation delay time
Symbol
t
PLH
t
PHL
Min
0.7
1.0
Max
3.1
3.7
Unit
ns
Test Conditions
C
L
= 15 pF, R
L
= 1 MΩ
C
L
= 50 pF, R
L
= 500
Ω
A
FROM
(Input)
Y
TO
(Output)
Operating Characteristics
Ta = 25°C
Item
Power dissipation capacitance
Symbol
C
PD
V
CC
(V)
1.8
2.5
3.3
5.0
Min
—
—
—
—
Typ
16
18
18
20
Max
—
—
—
—
Unit
pF
Test Conditions
f = 10 MHz
Test Circuit
Measurement point
From Output
C
L
*
R
L
Note: C
L
includes probe and jig capacitance.
Rev.1.00 Oct. 06, 2005 page 5 of 7
