E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Drum Type, SISDR125 Series
S
CHEMATICS
Magnetically Shielded
Miniature in size and high energy storage
Ideal for high current requirements of notebook,
video recorders and other DC-DC conversion
applications
Custom inductance value or tolerance is available
RoHS compliant
E
LECTRICAL
S
PECIFICATION
@ 25
o
C
Part
Number
SISDR125M-R47F
SISDR125M-1R0F
SISDR125M-1R5F
SISDR125M-2R2F
SISDR125M-3R3F
SISDR125M-4R7F
SISDR125M-6R8F
SISDR125M-8R2F
SISDR125M-100F
SISDR125M-150F
SISDR125M-220F
SISDR125M-330F
SISDR125M-470F
SISDR125M-680F
SISDR125M-820F
SISDR125M-101F
SISDR125M-151F
SISDR125M-221F
SISDR125M-331F
SISDR125M-471F
SISDR125M-681F
SISDR125M-821F
SISDR125M-102F
Inductance
(uH)
0.456
0.894
1.478
2.208
3.084
5.274
6.588
8.048
9.654
15.35
22.36
33.74
47.47
67.91
86.89
102.7
151.1
216.8
332.6
473.1
679.8
828.0
1008
1
Inductance
Tolerance
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
±20%
DCR
(m
W
Typ)
1.7
2.3
2.7
4.4
6.3
10.5
12.3
17.6
18.9
29.8
39.6
50.5
74.0
101
128
170
248
384
482
718
1100
1490
1690
Isat
(
A
)
2
Irms
(
A
)
18.4
15.5
14.1
11.1
9.26
7.18
6.64
5.54
5.35
4.27
3.70
3.28
2.71
2.22
2.05
1.78
1.48
1.19
1.06
0.87
0.70
0.60
0.57
3
Volt-mSec
Typ.
3.17
4.43
5.70
6.97
8.23
10.8
12.0
13.3
14.6
18.4
22.2
27.2
32.3
38.6
43.7
47.5
57.6
69.0
85.5
102
122
135
149
Marking
(XYYY)
MR47
M1R0
M1R5
M2R2
M3R3
M4R7
M6R8
M8R2
M100
M150
M220
M330
M470
M680
M820
M101
M151
M221
M331
M471
M681
M821
M102
33.0
23.6
18.3
15.0
12.7
9.71
8.68
7.86
7.17
5.69
4.71
3.84
3.24
2.70
2.39
2.20
1.81
1.51
1.22
1.02
0.85
0.77
0.70
Notes:
1. Inductance is tested at 0.25Vrms, 100kHz.
2. Saturation current, Isat, indicates the value of DC current when the inductance is 30% typical lower than its
initial value.
3. Heating current, Irms, is the value of current when the temperature rising
DT=40
o
C typical.
4. Operating temperature range: -40
o
C to +85
o
C.
5. The part temperature (ambient temperature + temperature rise) should not exceed the upper limit of the
operating temperature under worst case operating conditions. Circuit design, component placement, PWB
trace size and thickness, airflow and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
1/F.,Harbour View,No.12 Science Park East Avenue,Phase II,Hong Kong Science Park,Shatin,N.T.,HK . Tel: (852) 2954 3333 . Fax: (852) 2954 3304
1
PI002(01)
Revised in 12/03
E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Drum Type, SISDR125 Series
S
CHEMATICS
M
ECHANICAL
D
IMENSIONS
.492
Max
12.50
.543
13.80
.152
3.85
.492
Max
12.50
XYYY
(DATE)
.217
5.50
Recommended
Pad Layout
.236 Max
6.00
.081 Typ
2.05
REFERENCE OR
GUAGE PLANE
.193
Typ
4.90
.394
Typ
10.00
Notes:
inches
mm with higher precedence in mm.
7. U
nless otherwise specified, all tolerances are
±
.010
.
0.25
6. All dimensions are specified in
８.
When ordering, please add suffix
＂T＂
to the part number for tape & reel packaging (330mm reel)
.
Weight (in gram)
Tape & Reel
:
:
3.5 typ.
600 / reel
S
CHEMATICS
1
2
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
1/F.,Harbour View,No.12 Science Park East Avenue,,
Phase II,Hong Kong Science Park,Shatin,N.T.,HK
Tel: (852) 2954 3333
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: Http://www.eemagnetic.com
Information herein is for reference only and subject to change without notice. It does not constitute any representation, warranty or commitment of the company in respect
of the products in any aspect. All logos, brands and product names mentioned herein are trademarks or registered trademarks of their respective owners. The company
does not assume any liability arising out of the application or use of any product or circuit described herein. Copyrights 2012, E & E Magnetic Products Limited.
1/F.,Harbour View,No.12 Science Park East Avenue,Phase II,Hong Kong Science Park,Shatin,N.T.,HK . Tel: (852) 2954 3333 . Fax: (852) 2954 3304
1
PI002(01)
Revised in 12/03
