RKZ-KK Series
Silicon Planar Zener Diode for Surge Absorption and Stabilizer
REJ03G1518-0100
Rev.1.00
Mar 02, 2007
Features
•
Emboss Taping Reel Pack.
•
Super small Flat Lead Package (SFP) is suitable for surface mount design.
Ordering Information
Part No.
RKZ-KK Series
Laser Mark
Let to Mark Code
Package Name
SFP
Package Code
PUSF0002ZB-A
Pin Arrangement
Cathode mark
Mark
1
C1
2
1. Cathode
2. Anode
REJ03G1518-0100 Rev.1.00 Mar 02, 2007
Page 1 of 5
RKZ-KK Series
Absolute Maximum Ratings
(Ta = 25°C)
Item
Power dissipation
Junction temperature
Storage temperature
Note:
1. With P.C. Board.
Symbol
Pd *
1
Value
150
150
−55
to +150
Unit
mW
°C
°C
Tj
Tstg
Electrical Characteristics
(Ta = 25°C)
Zener Voltage
V
Z
(V) *
Part No.
RKZ2.0BKK
RKZ2.2BKK
RKZ2.4BKK
RKZ2.7B2KK
RKZ3.0B2KK
RKZ3.3B2KK
RKZ3.6B2KK
RKZ3.9B2KK
RKZ4.3B2KK
RKZ4.7B2KK
RKZ5.1B2KK
RKZ5.6B2KK
RKZ6.2B2KK
RKZ6.8B2KK
RKZ7.5B2KK
RKZ8.2B2KK
RKZ9.1B2KK
RKZ10B2KK
RKZ11B2KK
RKZ12B2KK
RKZ13B2KK
RKZ15B2KK
RKZ16B2KK
RKZ18B2KK
RKZ20B2KK
RKZ22B2KK
RKZ24B2KK
RKZ27BKK
RKZ30BKK
RKZ33BKK
RKZ36BKK
Min
1.90
2.10
2.30
2.65
2.95
3.25
3.55
3.87
4.15
4.55
4.98
5.49
6.06
6.65
7.28
8.02
8.85
9.77
10.76
11.74
12.91
14.34
15.85
17.56
19.52
21.54
23.72
25.10
28.00
31.00
34.00
1
Test
Condition
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
Reverse Current
Test
I
R
(µA)
Condition
Max
120
120
120
120
50
20
10
10
10
10
5
5
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
V
R
(V)
0.5
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.5
3.0
3.5
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
15.0
17.0
19.0
21.0
23.0
25.0
27.0
Dynamic Resistance
Test
r
d
(Ω)
Condition
Max
100
100
100
110
120
130
130
130
130
130
130
80
50
30
30
30
30
30
30
35
35
40
40
45
50
55
60
70
80
80
90
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
ESD-Capability *
— (kV) *
Min
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
25
25
25
20
20
15
15
13
8
8
2
2
Max
2.20
2.40
2.60
2.90
3.20
3.50
3.80
4.10
4.34
4.75
5.20
5.73
6.33
6.93
7.60
8.36
9.23
10.21
11.22
12.24
13.49
14.98
16.51
18.35
20.39
22.47
24.78
28.90
32.00
35.00
38.00
Notes: 1. Tested with pulse (Pw = 40 ms).
2. C =150 pF, R = 330
Ω,
Both forward and reverse direction 10 pulse
Failure criterion ; According to IR spec
3. The material of lead is exposed for cutting plane. Therefore, soldering nature of lead tip part is considered as
unquestioned. Please kindly consider soldering nature.
REJ03G1518-0100 Rev.1.00 Mar 02, 2007
Page 2 of 5
RKZ-KK Series
Mark Code
Part No.
RKZ2.0BKK
RKZ2.2BKK
RKZ2.4BKK
RKZ2.7B2KK
RKZ3.0B2KK
RKZ3.3B2KK
RKZ3.6B2KK
RKZ3.9B2KK
RKZ4.3B2KK
RKZ4.7B2KK
RKZ5.1B2KK
RKZ5.6B2KK
RKZ6.2B2KK
RKZ6.8B2KK
RKZ7.5B2KK
RKZ8.2B2KK
Note:
Mark No.
C1
C2
C3
C5
C7
C9
D2
D4
D6
D9
E3
E6
E9
F3
F6
F9
Part No.
RKZ9.1B2KK
RKZ10B2KK
RKZ11B2KK
RKZ12B2KK
RKZ13B2KK
RKZ15B2KK
RKZ16B2KK
RKZ18B2KK
RKZ20B2KK
RKZ22B2KK
RKZ24B2KK
RKZ27BKK
RKZ30BKK
RKZ33BKK
RKZ36BKK
Mark No.
G3
G6
G9
J3
J6
J9
M3
M6
M9
P3
P6
P8
P9
N4
N5
1. Example of Marking
C1
RKZ2.0BKK
N5
RKZ36BKK
REJ03G1518-0100 Rev.1.00 Mar 02, 2007
Page 3 of 5
RKZ-KK Series
Main Characteristic
RKZ2.4BKK
RKZ3.0B2KK
RKZ3.6B2KK
RKZ4.3B2KK
RKZ5.1B2KK
RKZ6.8B2KK
RKZ7.5B2KK
RKZ8.2B2KK
RKZ9.1B2KK
RKZ10B2KK
RKZ11B2KK
RKZ12B2KK
RKZ13B2KK
RKZ15B2KK
RKZ16B2KK
RKZ18B2KK
RKZ20B2KK
10
RKZ6.2B2KK
RKZ2.0BKK
8
Zener Current I
Z
(mA)
6
4
RKZ24B2KK
RKZ22B2KK
RKZ27BKK
RKZ30BKK
RKZ33BKK
2
0
0
4
8
12
16
20
24
28
32
RKZ36BKK
36
40
Zener Voltage V
Z
(V)
Fig.1 Zener current vs. Zener voltage
0.10
0.08
Zener Voltage
Temperature Coefficient
γ
Z
(%/°C)
50
40
Zener Voltage
Temperature Coefficient
γ
Z
(mV/°C)
250
Polyimide board
20hx15wx0.8t
%/°C
0.06
0.04
mV/°C
0.02
0
-0.02
-0.04
-0.06
-0.08
-0.10
0
5
10
15 20 25 30
30
20
10
0
-10
-20
-30
-40
-50
35 40
200
Power Dissipation Pd (mW)
3.0
1.5
150
1.5
unit: mm
100
50
0
0
50
100
150
Zener Voltage V
Z
(V)
Fig.2 Temperature Coefficient vs. Zener voltage
Ambient Temperature Ta (°C)
Fig.3 Power Dissipation vs. Ambient Temperature
REJ03G1518-0100 Rev.1.00 Mar 02, 2007
Page 4 of 5
0.8
200
RKZ-KK Series
Package Dimensions
Package Name
SFP
JEITA Package Code
RENESAS Code
PUSF0002ZB-A
Previous Code
SFP / SFPV
MASS[Typ.]
0.0010g
D
b
E
H
E
c
A
φ
b
e
1
Reference
Symbol
Dimension in Millimeters
Pattern of terminal position areas
A
b
c
D
E
H
E
φ
b
e
1
Min
0.50
0.25
0.08
0.55
0.90
1.30
Nom
0.30
0.13
0.60
1.00
1.40
0.50
1.40
Max
0.55
0.35
0.18
0.65
1.10
1.50
REJ03G1518-0100 Rev.1.00 Mar 02, 2007
Page 5 of 5
