HVD369B_06: Description4.9 pF, SILICON, VARIABLE CAPACITANCE DIODE; Categorysemiconductor Discrete semiconductor; File Size142KB，5 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Compare View All

HVD369B_06 Overview

4.9 pF, SILICON, VARIABLE CAPACITANCE DIODE

Preview

Download Datasheet

View All

HVD369B

Variable Capacitance Diode for VCO

REJ03G0502-0200

Rev.2.00

Jan 31, 2006

Features

•

Low capacitance and to be usable at GHz.

High capacitance ratio. (n = 2.3 min)

Low series resistance. (r

= 0.5

Ω

max)

Super small Flat Lead Package (SFP) is suitable for surface mount design.

Ordering Information

Type No.

HVD369B

Laser Mark

Package Name

SFP

Package Code

PUSF0002ZB-A

Pin Arrangement

Cathode mark

Mark

1. Cathode

2. Anode

Rev.2.00 Jan 31, 2006 page 1 of 4

Sales Strategic Planning Div.
