STANDARD POWER INDUCTORS - SURFACE MOUNT
HCSM
TRADITIONAL
Pb
HCSMLF
*
PART
NUMBER
HC37-1251SM
HC37-2101SM
HC37-2801SM
HC37-4201SM
HC44-2801SM
HC44-4201SM
HC44-5701SM
HC44-9001SM
HC50-6501SM
HC50-8401SM
HC50-1252SM
HC50-1702SM
HC68-1052SM
HC68-1762SM
HC68-2202SM
HC68-2902SM
COMPLIANT
RoHS
Wirewound,Toroidal
L µH
@ 1kHz
1.25
2.10
2.80
4.20
2.80
4.20
5.70
9.00
6.50
8.40
12.5
17.0
10.5
17.6
22.0
29.0
SRF
MHz
MIN
260
160
110
100
110
85
65
55
55
45
35
29
30
24
21
16
DCR
OHMS
MAX
0.0025
0.0040
0.0063
0.0079
0.0036
0.0054
0.0075
0.0114
0.0066
0.0083
0.0114
0.0170
0.0062
0.0123
0.0175
0.0250
CURRENT
RATING L µH
A DC w/DC
17.40
13.90
11.00
9.83
15.60
12.80
10.90
8.87
12.00
10.80
9.25
7.58
13.20
9.32
7.87
6.57
0.81
1.32
2.24
3.36
1.68
2.50
4.56
7.20
3.50
4.70
10.00
13.60
5.20
9.40
17.60
23.20
@I
A DC
14.3
11.5
5.0
4.0
13.9
11.4
4.0
3.0
12.4
10.4
3.7
3.4
15.4
10.9
3.7
3.0
A
MAX
0.615 (15.62)
0.615 (15.62)
0.615 (15.62)
0.615 (15.62)
0.665 (16.89)
0.665 (16.89)
0.665 (16.89)
0.665 (16.89)
0.740 (18.80)
0.740 (18.80)
0.740 (18.80)
0.740 (18.80)
0.945 (24.0)
0.945 (24.0)
0.945 (24.0)
0.945 (24.0)
B
MAX
0.600 (15.62)
0.600 (15.62)
0.600 (15.62)
0.600 (15.62)
0.665 (16.89)
0.665 (16.89)
0.665 (16.89)
0.665 (16.89)
0.740 (18.80)
0.740 (18.80)
0.740 (18.80)
0.740 (18.80)
0.940 (23.88)
0.940 (23.88)
0.940 (23.88)
0.940 (23.88)
DIMENSIONS
C
MAX
0.370 (9.40)
0.370 (9.40)
0.370 (9.40)
0.370 (9.40)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
0.400 (10.16)
D
NOM
0.440 (11.18)
0.440 (11.18)
0.440 (11.18)
0.440 (11.18)
0.490 (12.45)
0.490 (12.45)
0.490 (12.45)
0.490 (12.45)
0.560 (14.22)
0.560 (14.22)
0.560 (14.22)
0.560 (14.22)
0.700 (17.78)
0.700 (17.78)
0.700 (17.78)
0.700 (17.78)
E
NOM
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.560 (14.22)
0.560 (14.22)
0.560 (14.22)
0.560 (14.22)
0.630 (16.00)
0.630 (16.00)
0.630 (16.00)
0.630 (16.00)
0.820 (20.83)
0.820 (20.83)
0.820 (20.83)
0.820 (20.83)
All part numbers provide 20% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: HC37-1251SMLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
• Operating Temperature Range:
-30°C to +130°C
TOP VIEW
SIDE VIEW
• Current Rating is based on a 55°C temperature
rise at an ambient temperature of 25°C
• Excellent electromagentic shielding
TAPE AND REEL SPECS:
HC37
250
24 mm
32 mm
13 in.
HC44
200
24 mm
32 mm
13 in.
HC50
200
24 mm
44 mm
13 in.
HC68
150
32 mm
44 mm
13 in.
HCXX-
XXXXSM
A
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
TAPE AND REEL SPECS:
C
B
TOP VIEW
SIDE VIEW
RECOMMENDED FOOT PRINT
0.080
(2.03)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
TAPE AND REEL SPECS:
HCXX-
XXXXSM
A
D
B
C
E
CENTERS
in. (mm)
RECOMMENDED FOOT PRINT
0.080
(2.03)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
D
010814
