BCR20KM-12L

Description
Triac Medium Power Use
CategoryAnalog mixed-signal IC    Trigger device
File Size108KB,7 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Download Datasheet Parametric Compare View All

BCR20KM-12L Overview

Triac Medium Power Use

BCR20KM-12L Parametric

Parameter NameAttribute value
MakerRenesas Electronics Corporation
package instruction,
Reach Compliance Codeunknow
Critical rise rate of commutation voltage - minimum value10 V/us
Maximum DC gate trigger current20 mA
Maximum DC gate trigger voltage1.5 V
Maximum leakage current2 mA
Maximum on-state voltage1.5 V
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Maximum rms on-state current20 A
Off-state repetitive peak voltage600 V
surface mountNO
Trigger device typeTRIAC
BCR20KM-12L
Triac
Medium Power Use
REJ03G0329-0200
Rev.2.00
Nov.09.2004
Features
I
T (RMS)
: 20 A
V
DRM
: 600 V
I
FGTI
, I
RGTI
, I
RGT
: 30 mA (20 mA)
Note5
Viso : 2000 V
Insulated Type
Planar Passivation Type
UL Recognized : Yellow Card No. E223904
File No. E80271
Outline
TO-220FN
2
1. T
1
Terminal
2. T
2
Terminal
3. Gate Terminal
3
1
1
2 3
Applications
Vacuum cleaner, electric heater, light dimmer, copying machine, and other general controlling devices
Maximum Ratings
Parameter
Repetitive peak off-state voltage
Note1
Non-repetitive peak off-state voltage
Note1
Symbol
V
DRM
V
DSM
Voltage class
12
600
720
Unit
V
V
Rev.2.00,
Nov.09.2004,
page 1 of 6
