MS336RAA181GSZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> MS336RAA181GSZ

MS336RAA181GSZ: DescriptionGeneral Purpose Inductor, 0.18uH, 2%, 1 Element, Ceramic-Core, SMD, 0907, CHIP, 0805; CategoryPassive components inductor; File Size101KB，2 Pages; ManufacturerCOILCRAFT; Websitehttp://www.coilcraft.com/

Download Datasheet Parametric View All

MS336RAA181GSZ Overview

General Purpose Inductor, 0.18uH, 2%, 1 Element, Ceramic-Core, SMD, 0907, CHIP, 0805

MS336RAA181GSZ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	0907
Reach Compliance Code	compliant
ECCN code	EAR99
uppercase and lowercase codes	0907
structure	Chip
core material	CERAMIC
DC Resistance	0.64 Ω
Nominal inductance(L)	0.18 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e0
Number of functions	1
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	1.52 mm
Package length	2.29 mm
Package form	SMT
Package width	1.73 mm
method of packing	TR, Plastic, 7 Inch
Minimum quality factor (at nominal inductance)	37
Maximum rated current	0.4 A
self resonant frequency	730 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
special characteristics	Q MEASURED AT 100 MHZ
surface mount	YES
Terminal surface	Tin/Lead (Sn63Pb37)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	100 MHz
Tolerance	2%
Base Number Matches	1

Preview

Download Datasheet

View All

0805 CHIP INDUCTORS

High-Reliability Chip Inductors

MS336RAA

The MS336RAA inductors provide exceptional Q values,

even at high frequencies. They have a ceramic body and

wire wound construction to provide the highest SRFs

available in 0805 size.

Inductance

(nH)

2.8@

3.0@

3.3@

5.6@

6.8@

7.5@

8.2@

10@

12@

15@

18@

22@

24@

27@

33@

36@

39@

43@

47@

56@

68@

82@

91@

100@

110@

120@

150@

180@

220@

240@

270@

330@

390@

250 MHz

200 MHz

150 MHz

100 MHz

This robust version of Coilcraft’s standard 0805CS series

features high temperature materials that allow operation in

ambient temperatures up to 155°C and a leach-resistant

base metalization with tin-lead (Sn-Pb) terminations that

ensures the best possible board adhesion.

Q min

Part number

Percent

tolerance

5,2

5,2,1

SRF min

(MHz)

5000

4760

4440

3840

3560

3460

3180

2560

2480

2080

1920

2060

1720

1520

1600

1440

1360

1280

1200

1060

1000

880

730

650

610

580

520

480

DCR max

(Ohms)

0.06

0.08

0.11

0.14

0.12

0.10

0.15

0.17

0.20

0.22

0.25

0.27

0.29

0.34

0.31

0.34

0.38

0.42

0.48

0.46

0.48

0.51

0.56

0.64

0.70

1.00

1.40

1.50

Imax

(mA)

800

600

500

470

460

440

400

390

380

340

330

270

260

230

210

Color

code

Gray

White

Black

Orange

Brown

Green

Red

Blue

Orange

Yellow

Green

Blue

Gray

Violet

Gray

Orange

White

Yellow

Black

Brown

Red

Orange

Black

Yellow

Brown

Green

Blue

Violet

Gray

Red

White

Black

Brown

MS336RAA020JSZ

MS336RAA3N0JSZ

MS336RAA030JSZ

MS336RAA050JSZ

MS336RAA060JSZ

MS336RAA070JSZ

MS336RAA080_SZ

MS336RAA100_SZ

MS336RAA120_SZ

MS336RAA150_SZ

MS336RAA180_SZ

MS336RAA220_SZ

MS336RAA240_SZ

MS336RAA270_SZ

MS336RAA330_SZ

MS336RAA360_SZ

MS336RAA390_SZ

MS336RAA430_SZ

MS336RAA470_SZ

MS336RAA560_SZ

MS336RAA680_SZ

MS336RAA820_SZ

MS336RAA910_SZ

MS336RAA101_SZ

MS336RAA111_SZ

MS336RAA121_SZ

MS336RAA151_SZ

MS336RAA181_SZ

MS336RAA221_SZ

MS336RAA241_SZ

MS336RAA271_SZ

MS336RAA331_SZ

MS336RAA391_SZ

57@

61@

48@

75@

54@

56@

63@

57@

46@

41@

48@

59@

56@

64@

57@

44@

45@

44@

49@

52@

51@

49@

54@

38@

52@

33@

37@

36@

34@

1000 MHz

500 MHz

250 MHz

100 MHz

1. When ordering, specify

tolerance, termination

and

testing

codes:

MS336RAA821GSZ

Tolerance: F

= 1%

= 2%

= 5%

Termination: S

= Tin-lead (63/37) over silver-platinum-glass frit.

Special order:

= Tin-silver-copper (95.5/4/0.5) over silver-plati-

num-glass frit.

= Tin-lead (63/37) over tin over nickel over silver-

platinum-glass frit.

= Tin-silver-copper (95.5/4/0.5) over tin over

nickel over silver-platinum-glass frit.

Testing:

= COTS

= Group A screening per Coilcraft CP-SA-10001

= Group A screening per Coilcraft CP-SA-10003

2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/

HP 4286A impedance analyzer or equivalent with Coilcraft-provided

correlation pieces.

3. Q measured using an Agilent/HP 4291A with an Agilent/

HP 16197A test fixture or equivalents.

4. SRF measured on an Agilent 8753ES or equivalent with a Coilcraft

CCF1297 test fixture.

5. DCR measured on a Keithley micro-ohmmeter or equivalent and a

Coilcraft CCF858 test fixture.

6. Electrical specifications at 25°C.

Refer to Doc 362 “Soldering Surface Mount Components” before soldering.

Document MS100-1 Revised 06/12/13

1102 Silver Lake Road

Cary, IL 60013

Phone 800-981-0363

Fax 847-639-1508

Email cps@coilcraft.com

www.coilcraft-cps.com

This product may not be used in medical or high

risk applications without prior Coilcraft approval.

Specifications subject to change without notice.

Please check our web site for latest information.
