Ordering number : EN*A0098
Bi-CMOS LSI
LV4901H
Overview
Buit-in 80mW Headphone amplifier
BTL 10W×2ch Crass-D Audio Power Amplifier
The LV4901H is a 10W per channel stereo digital power amplifier that takes analog inputs. The LV4901H uses unique
SANYO-developed feedback technology to achieve excellent audio quality despite being a class D amplifier and can be
used to implement high quality flat display panel (FDP) based systems.
Features
•
Supports circuit designs that do not require output LC filters
•
BTL output, class D amplifier system
•
Unique SANYO-developed feedback technology achieves superb audio quality
•
High-efficiency class D amplifier, Low EMI
•
Soft muting function reduces impulse noise at power on/off
•
Full complement of built-in protection circuits : overcurrent protection, thermal protection, and low power supply
voltage protection circuits
•
Built in boot strap diode
•
Built in Headphone amplifier
Functions
•
10W output (VD = 12V, RL = 8Ω, THD + N = 10%)
•
Efficiency :
η >
85% (VD = 12V, RL = 8Ω, fin = 1kHz, PO = 10W)
•
80mW Stereo Headphone amplifier (VD = 12V, RL = 16Ω, THD + N = 10%)
•
Package HSOP-36
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
'
s products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'
s products or
equipment.
70208 MS PC No.A0098-1/14
LV4901H
Specifications
Absolute Maximum Ratings
at Ta = 25°C
Parameter
Maximum supply voltage
Maximum output current
Allowable power dissipation
Operating temperature
Storage temperature
Symbol
VD
IO peak
Pd max
Topr
Tstg
Independent package
Conditions
Externally applied voltage
Ratings
14
3.5
886
-25 to +75
-50 to +150
Unit
V
A/ch
mW
°C
°C
Recommended Operating Conditions
at Ta = 25°C
Parameter
Recommended supply voltage range
Recommended load resistance
Symbol
VD
RL (SP)
RL (HP)
Conditions
min
Externally applied voltage
Speaker load
Headphone
10
4
Ratings
typ
12
8
16
max
13.5
V
Ω
Ω
Unit
Electrical Characteristics
at Ta = 25°C
Parameter
Symbol
Conditions
min
Digital amplifier block
: VD = 12V, RL = 8Ω, L = 22μH, C = 0.33μF, CL = 1μF
Standby current
Mute current
Quiescent current
Voltage gain
Output offset voltage
Total harmonic distortion
Maximum output
Channel separation
Ripple rejection ratio
Noise
High-level input voltage
Low-level input voltage
Power supply voltage drop protection
circuit upper limit value
Power supply voltage drop protection
circuit lower limit value
Headphone amplifier block
: VD = 12V, RL = 16Ω, fin = 1kHz
Quiescent current
Voltage gain
Total harmonic distortion
Maximum output
Channel separation
Ripple rejection ratio
High-level input voltage
Low-level input voltage
Noise
ICCOhp
VG
THD
PO
CH sep.
SVRR
VIH
VIL
VNO
HP_STBY = H
VO = -10dBm
PO = 1mW, DIN AUDIO
THD = 10%, DIN AUDIO
fin = 1kHz, Vr = 0dBm, Rg = 0, DIN AUDIO
fr = 100Hz, Vr = 0dBm, Rg = 0, DIN AUDIO
HP_STBY pin
HP_STBY pin
Rg = 0Ω, DIN AUDIO
50
60
35
55
3
1
200
10
5.5
12
0.25
80
45
70
9.5
14
0.8
mA
dB
%
mW
dB
dB
V
V
μVrms
UV_LOWER
VD pin voltage monitor
7.0
V
Ist
Imute
ICCO
VG
Voffset
THD@1W
PO1@10%
CH sep.
SVRR
VNO
VIH
VIL
UV_UPPER
STBY = L, MUTE = L
STBY = H, MUTE = L
STBY = H, MUTE = H
fin = 1kHz, VO = 0dBm
Rg = 0
PO = 1W, fin = 1kHz, AES17
THD+N = 10%, AES17
fin = 1kHz, VO = 0dBm, Rg = 0, DIN AUDIO
fr = 100Hz, Vr = 0dBm, Rg = 0, A-weight
Rg = 0, A-weight
STBY pin and MUTE pin
STBY pin and MUTE pin
VD pin voltage monitor
8.0
3
1
8
55
35
27
-150
0.2
10
70
50
200
500
13
13
60
29
25
20
70
31
150
0.8
μA
mA
mA
dB
mV
%
W
dB
dB
μVrms
V
V
V
Ratings
typ
max
Unit
Note : The values of these characteristics were measured in the SANYO test environment. The actual values in an end system will vary depending on the
printed circuit board pattern, the external components actually used, and other factors.
No.A0098-2/14
