FACTSHEET F-202-1
ICO–624–MGT
ICO–320–CTT
LOW PROFILE DIP SOCKETS
Mates with:
APO, APA
ICO
SERIES
OPTION
ICO
ROW SPACING &
NO. OF CONTACTS
STYLE
OPTION
PLATING
OPTION
(Leave Blank for
Standard Version)
Specify from chart below
• Low profile down to .083" (2,11mm)
above printed circuit board
• Side & end stackable
• Open body design
• Surface mountable lead sockets
(2,54) .100 x
No. of Positions
Row Space Contacts
= 30
µ
"
(0,76
µ
m) Gold Contact
10
µ
"
(0,25
µ
m) Gold Shell
GG
–L
= Locking Socket
Requires
Style –S,
–ZS, –P,
or –ZP
and .035
"
±
.003
"
(0,89mm
±
0,08)
board hole.
(7,62)
.300
(3,43)
.135
(7,64) .300
(10,16) .400
or
(15,24) .600
Row
Spacing
+(2,41)
.095
(2,54)
.100
TYP
(2,54) .100
x No. of Spaces
–308
–314
–316
–318
–320
–322
–324
–422
–624
–628
–632
–640
.300 (7,62)
.400 (10,16)
.600 (15,24)
08
14
16
18
20
22
24
22
24
28
32
40
= 30
µ
"
(0,76
µ
m) Gold Contact
200
µ
"
(5,08
µ
m) Tin Shell
GT
TT
= 200
µ
"
(5,08
µ
m) Tin Contact
and Shell
(–C, –S, –ZS, –A, –L, –M,
–N, only)
(1,27)
.050
= 10
µ
" (0,25
µ
m) Gold Contact
200
µ
" (5,08
µ
m) Tin Shell
(Styles –S & –ZS only)
ST
Requires GT
Plating Option
SPECIFICATIONS
For complete specifications
see www.samtec.com?ICO
Insulator Material:
Black Glass Filled
Polyester
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ min
Temperature Range:
-65°C to +125°C with Gold
-65°C to +105°C with Tin
Withstanding Voltage:
1000 VRMS @ 60 Hz
Contact:
BeCu
Shell:
Brass except style K
Phosphor Bronze
Plating:
Au or Sn over 50µ"
(1,27µm) Ni
Current Rating:
1A
Contact Resistance:
10 mΩ max
Lead Size Range:
.015" to .022" (0,38mm to
0,56mm) DIA and most IC
leads except C, L, M, and N
Insertion Force:
Standard = 9 oz avg, 16 oz
max; Low Insertion Force =
2.5 oz avg, 5.5 oz max
Withdrawal Force:
Standard = 2.5 oz avg, 1.5 oz
min; Low Insertion Force =
2.0 oz avg, 0.35 oz min
except Styles ZM and ZN =
2.0 avg, 0.5 oz min
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
–L
= Low Profile
For LIF Specify –ZL
(0,76)
.030
(0,51)
.020
–M
= Low Profile
For LIF Specify –ZM
(0,51)
.020
–N
= Micro Socket
For LIF Specify –ZN
–ZP or –ZT
= Short Tail
Low Insertion Force
Y
(1,32)
.052
DIA
(5,84
±0,25)
.230
(2,74)
±.010
.108
±.010
(1,32)
.052
DIA
(0,51)
.020
DIA
(6,10
±0,25)
.240
±.010
(2,74)
.108
±.010
(1,32)
.052
DIA
(0,76)
.030
DIA
(4,83
±0,25)
.190
(2,41)
±.010
.095
±.010
LEAD
STYLE
Z
Y
(1,32)
.052
DIA
(0,51)
.020
DIA
Z
–ZP
–ZT
(5,20) (0,76)
.205 .030
(4,24) (0,51)
.167 .020
(0,76)
.030
DIA
(0,89)
.035
Lead DIA Accepted
= .015" to .020"
(0,38mm to 0,51mm)
Lead DIA Accepted
= .016" to .021"
(0,41mm to 0,53mm)
Lead DIA Accepted
= .016" to .020"
(0,41mm to 0,51mm)
Locking
lead (–L)
available.
See
OPTION.
–C
= Micro Socket
For LIF Specify –ZC
(0,25)
.010
(2,11)
.083
(1,32)
.052
DIA
(0,74)
.029
DIA
–F
= Flush Top
–S, –ZS, –ZA, –J, or –K
= Printed Circuit
–ZS & –ZA= Low Insertion Force
(0,76)
.030
LEAD
STYLE
(1,32)
.052
DIA
(7,37
±0,25
.290
(3,18)
±.010
.125
±.010
Y
X
DIA TAIL
Z
(4,19)
.165
(1,32)
.052
DIA
–S or –ZS
Z
X
Y
–ZA
–J
–K
(0,51)
.020
DIA
(0,51) (3,18) (7,62)
.020
.125
.300
(0,51) (4,57) (8,89)
.020
.180
.350
(0,64) (10,41) (15,24)
.025
.410
.600
(0,89) (12,95) (17,86)
.035
.510
.703
Lead DIA Accepted
= .016" to .020"
(0,41mm to 0,51mm)
Locking lead (–L) available.
See OPTION.
