2.54 mm pitch connector
Right-angle through hole type male connector for PCB
FFC-( )(T )LAMEP( )( )
●
Configuration of product Part No.
For PCB
Right-angle Through hole
FFC- ( ) (T ) L AMEP ( ) ( )
➀
➁
➂
➃
➄
➅
➆
➄
Type of contact
AMEP: 0.635 mm square
contacts, single row type
➅
Contact plating
1 : Gold plate
21: Tin copper plate
➆
Insulator color
Blank: Blue
B
: Black
➀
Series name
➁
No. of contacts: 1–52
➂
Length of contact
Blank: Standard
T, T1–T27 (Refer to the following
dimension table.)
➃
Type of contact
L: Right-angle
B
A
2.54
œ0.635
2.54
C
2.54
D
➀
➁
œ0.635
●
Dimensions
No. of
contacts
E
ø1
+0.1
0
2.54
– 0.05
+
●
Components
➀
Insulator
➁
Contact
Part No.
FFC- (1~52 )LAMEP( )( )
FFC- (1~52 )TLAMEP( )( )
FFC- (1~52 )T1LAMEP( )( )
FFC- (1~52 )T2LAMEP( )( )
FFC- (1~52 )T3LAMEP( )( )
FFC- (1~52 )T4LAMEP( )( )
FFC- (1~52 )T5LAMEP( )( )
FFC- (1~52 )T6LAMEP( )( )
FFC- (1~52 )T7LAMEP( )( )
FFC- (1~52 )T8LAMEP( )( )
FFC- (1~52 )T9LAMEP( )( )
FFC- (1~52 )T10LAMEP( )( )
FFC- (1~52 )T11LAMEP( )( )
FFC- (1~52 )T13LAMEP( )( )
C
6
D
1.27
3.81
E
3.45
5.95
2.6
5.1
7.65
10.2
12.7
15.3
5.1
7.65
10.2
12.7
15.27
3.45
A
– 0.1
Recommended PCB layout
Part No.
FFC- (1~52 )T14LAMEP(
FFC- (1~52 )T15LAMEP(
FFC- (1~52 )T16LAMEP(
FFC- (1~52 )T17LAMEP(
FFC- (1~52 )T18LAMEP(
FFC- (1~52 )T19LAMEP(
FFC- (1~52 )T20LAMEP(
FFC- (1~52 )T23LAMEP(
FFC- (1~52 )T24LAMEP(
FFC- (1~52 )T25LAMEP(
FFC- (1~52 )T26LAMEP(
FFC- (1~52 )T27LAMEP(
C
)(
)(
)(
)(
)(
)(
)(
)(
)(
)(
)(
)(
)
)
)
)
)
)
)
)
)
)
)
)
+
5.72
8.51
1.4
5.72
3.94
2.6
5
7
6
3.3
3.2
7
3
* T12, T21 and T22 is obsolete.
D
3.94
6.48
1.4
3.94
1.4
1.27
1.46
1.27
3.81
13.5
E
6
8.5
3
5.5
2.6
3.45
1.9
3.2
2.6
1.93
5.5
1.4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
A
–
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
B
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
No. of
contacts
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
A
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
101.60
104.14
106.68
109.22
111.76
114.30
116.84
119.38
121.92
124.46
127.00
129.54
B
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
101.60
104.14
106.68
109.22
111.76
114.30
116.84
119.38
121.92
124.46
127.00
129.54
132.08
Mating connectors:
