Crimp
NH
CONNECTOR
Disconnectable Crimp style connectors
Features ––––––––––––––––––––––––
• Superior folded beam construction
(1) This sturdy construction withstands repeated stress, resists
permanent deformation, and offers a very long service life.
(2) High reliability is ensured whether the contact pressure is
high or low.
(3) This contact design has a large tolerance for variations in
mating post thickness and resists deformation when pried.
2.5mm
pitch
• Double-sided contact
(1) The receptacle contact has a protected entry which
eliminates contact damage caused by mismating.
(2) It provides high contact pressure, is free from abnormal
stress, and maintains continuity at all times.
(3) It has an extremely long service life due to its folded beam
design.
• Wide, sturdy post
This 2.5mm pitch connector is used to
connect wires to printed circuit boards.
The header is available in three
configurations: top, side, and bottom entry.
This allows the wires to be perpendicular
or parallel to the printed circuit board in
any direction.
The post has a large cross-sectional area to resist prying
during insertion into printed circuit boards and mating with
connector housings.
• Molded-in header
The posts are molded into the insulator to provide stability
when mounted on printed circuit boards. This also prevents
flux from entering the connector during soldering.
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 15m
Ω
max.
After environmental testing/ 20m
Ω
max.
• Insulation resistance: 500M
Ω
min.
• Withstanding voltage: 1,500V AC/minute
• Applicable wire: AWG #30 to #22
• Applicable PC board thickness: 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
1
2
3
JS
4 5
T
Standards ––––––––––––––––––––––
0
1
2
Recognized E60389
Certified LR20812
J50168090
1
NH
CONNECTOR
Contact –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Model No.
9
3.8
2.2
1.7
4
1.2
Applicable wire
mm
2
0.08 to 0.33
0.05 to 0.08
AWG #
28 to 22
30 to 28
Insulation O.D. (mm)
1.2 to 1.7
0.9 to 1.2
Q'ty /
reel
5,000
SHF-001T-0.8BS
SHF-002T-0.8BS
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
0.7
1.95
RoHS compliance
Note:
1. Contact JST for gold-plated products.
2. Also contact JST if you require shielded wires, thin wires or other special
wires.
3. Contact JST for brass products.
Housing –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Cir-
cuits
2
3
1.8
Model No.
H 2P-SHF-AA
H 3P-SHF-AA
H 4P-SHF-AA
H 5P-SHF-AA
H 6P-SHF-AA
H 7P-SHF-AA
H 8P-SHF-AA
H 9P-SHF-AA
H10P-SHF-AA
H11P-SHF-AA
H12P-SHF-AA
H13P-SHF-AA
H14P-SHF-AA
H15P-SHF-AA
H16P-SHF-AA
H18P-SHF-AA
H20P-SHF-AA
H21P-SHF-AA
H22P-SHF-AA
H24P-SHF-AA
H25P-SHF-AA
Dimensions (mm)
A
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
42.5
47.5
50.0
52.5
57.5
60.0
B
5.7
8.2
10.7
13.2
15.7
18.2
20.7
23.2
25.7
28.2
30.7
33.2
35.7
38.2
40.7
45.7
50.7
53.2
55.7
60.7
63.2
C
8.7
11.2
13.7
16.2
18.7
21.2
23.7
26.2
28.7
31.2
33.7
36.2
38.7
41.2
43.7
48.7
53.7
56.2
58.7
63.7
66.2
Q'ty /
bag
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
500
500
200
200
200
200
200
200
200
200
4
5
6
2
4.6
7
8
1.5
A
B
C
3
11.7
9
10
11
12
13
14
15
16
18
20
21
22
24
25
Material
PA 6, UL94V-0, natural (white)
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
H2P-SHF-AA-oo-
(blank)…natural (white)
K…black R…red TR…tomato red E…blue M…green
O…orange N…brown
2
NH
CONNECTOR
Header ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
2.5
1
0.64
Model No.
Cir-
cuits
2
3
4
5
6
3.5
A
5.6
6
Q'ty / box
Side Bottom
entry entry
type type
1,000
1,000
500
500
500
500
500
500
250
250
200
200
200
200
200
250
250
250
250
150
150
150
150
100
100
100
100
50
50
Top entry
type
Dimen-
Top
Side entry Bottom entry sions A entry
(mm)
type
type
type
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
40.0
42.5
45.0
47.5
50.0
52.5
55.0
57.5
60.0
1,000
1,000
1,000
1,000
500
500
500
500
250
250
250
250
250
250
250
200
200
250
250
250
250
250
250
250
B 2P-SHF-1AA BS 2P-SHF-1AA BE 2P-SHF-1AA
B 3P-SHF-1AA BS 3P-SHF-1AA BE 3P-SHF-1AA
B 4P-SHF-1AA BS 4P-SHF-1AA BE 4P-SHF-1AA
B 5P-SHF-1AA BS 5P-SHF-1AA BE 5P-SHF-1AA
B 6P-SHF-1AA BS 6P-SHF-1AA BE 6P-SHF-1AA
B 7P-SHF-1AA BS 7P-SHF-1AA BE 7P-SHF-1AA
B 8P-SHF-1AA BS 8P-SHF-1AA BE 8P-SHF-1AA
B 9P-SHF-1AA BS 9P-SHF-1AA BE 9P-SHF-1AA
B10P-SHF-1AA BS10P-SHF-1AA BE10P-SHF-1AA
B11P-SHF-1AA BS11P-SHF-1AA BE11P-SHF-1AA
B12P-SHF-1AA BS12P-SHF-1AA BE12P-SHF-1AA
B13P-SHF-1AA BS13P-SHF-1AA BE13P-SHF-1AA
B14P-SHF-1AA BS14P-SHF-1AA BE14P-SHF-1AA
B15P-SHF-1AA BS15P-SHF-1AA BE15P-SHF-1AA
B16P-SHF-1AA BS16P-SHF-1AA
B17P-SHF-1AA
B19P-SHF-1AA
–
–
B18P-SHF-1AA BS18P-SHF-1AA
B20P-SHF-1AA BS20P-SHF-1AA
B21P-SHF-1AA BS21P-SHF-1AA
B22P-SHF-1AA BS22P-SHF-1AA
B23P-SHF-1AA
–
B24P-SHF-1AA BS24P-SHF-1AA
B25P-SHF-1AA BS25P-SHF-1AA
–
–
–
–
–
–
–
–
–
–
3.4 3.2
0.64
7
8
9
10
11
Side entry type
1
6
12
13
14
15
5.6
3.5
16
17
–
–
–
–
–
–
–
–
–
–
–
200
3
18
2.5
A
0.64
5.5
3
0.64
19
20
21
22
23
–
200
200
200
–
200
200
Bottom entry type
11.4
1
5.8
24
25
Material and Finish
Post: Brass, copper-undercoated, tin-plated (reflow treatment)
Wafer: PA 66, UL94V-0, natural (white) for the top and side entry types
PA 6, UL94V-0, natural (white) for the bottom entry type
7
6
10
RoHS compliance
This product displays (LF)(SN) on a label.
3.3
2.5
A
0.64
3.4
3
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B2P-SHF-1AA-oo-
(blank)…natural (white)
BK…black R…red TR…tomato red E…blue M…green
O…orange N…brown
3
NH
CONNECTOR
PC board layout
(viewed from soldering side)
and Assembly layout –––––––––––––––––––
Top entry type
6.5
2.5
±0.05
3.1
min.
3.5
min.
2.5
±0.05
3.1
min.
3 to 12
17.7
Side entry type
14.9
1.6
φ
0.9
+0.1
0
φ
0.9
+0.1
0
6.5
3
14.7
1.6
3.5 3
Bottom entry type
2.5
±0.05
12.2
3
max.
1.6
2.8
9.5
3.1
4
min.
Note:
1. Tolerances are non-cumulative: ±0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline.
Contact JST for details.
Crimping machine, Applicator–––––––––––––––––––––––––––––––––––––––––––––––
Contact
SHF-001T-0.8BS
SHF-002T-0.8BS
Note: *Strip-crimp applicator
Crimping machine
AP-K2N
AP-K2N
7.5
min.
φ
0.9
+0.1
0
Crimp applicator
MKS-L
*MKS-SC
MKS-L
*MKS-SC
14.7
Dies
MK/SHF-001-08S
SC/SHF-001-08S
MK/SHF-002-08S
SC/SHF-002-08S
Crimp applicator with dies
APLMK SHF001-08S
APLSC SHF001-08S
APLMK SHF002-08S
APLSC SHF002-08S
4
