VISHAY
BAS16WS
Vishay Semiconductors
Small Signal Diodes
Features
• Silicon Epitaxial Planar Diode
• Fast switching diode
• Also available in case SOT-23 with designation
BAS16
Mechanical Data
Case:
SOD-323 Plastic Case
Weight:
approx. 4 mg
Marking:
A6
Packaging Codes/Options:
D5/10 K per 13" reel (8 mm tape), 30 K/box
D6/3 K per 7" reel (8 mm tape), 30 K/box
17431
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Reverse voltage
Peak reverse voltage
Forward current (continuous)
Non-repetitive peak forward current
t = 1
µs
t = 1 ms
t=1s
Power dissipation
1)
Test condition
Symbol
V
R
V
RM
I
F
I
FSM
I
FSM
I
FSM
P
tot
Value
75
100
250
2.0
1.0
0.5
200
1)
Unit
V
V
mA
A
A
A
mW
Valid provided electrodes are kept at ambient temperature
Thermal Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Maximum junction temperature
Storage temperature
Test condition
Symbol
T
j
T
S
Value
150
- 65 to 150
Unit
°C
°C
Electrical Characteristics
T
amb
= 25 °C, unless otherwise specified
Parameter
Forward voltage
Test condition
I
F
= 1 mA
I
F
= 10 mA
I
F
= 50 mA
I
F
= 150 mA
Leakage current
V
R
= 25 V, T
J
= 150 °C
V
R
= 75 V
V
R
= 75 V, T
J
= 150 °C
Symbol
V
F
V
F
V
F
V
F
I
R
I
R
I
R
Min
Typ.
Max
715
855
1.00
1.25
30
1
50
Unit
mV
mV
V
V
µA
µA
µA
Document Number 85752
Rev. 3, 24-Jun-03
www.vishay.com
1
