IMC-06033.9NH+/-5% datasheet, PDF

Datasheet> All Categories > Passive components> inductor> IMC-06033.9NH+/-5%

IMC-06033.9NH+/-5%: DescriptionGeneral Fixed Inductor, 1 ELEMENT, 0.0039 uH, CERAMIC-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP; CategoryPassive components inductor; File Size22KB，1 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

IMC-06033.9NH+/-5% Overview

General Fixed Inductor, 1 ELEMENT, 0.0039 uH, CERAMIC-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP

IMC-06033.9NH+/-5% Parametric

Parameter Name	Attribute value
Maker	Vishay
Reach Compliance Code	unknown
ECCN code	EAR99
core material	CERAMIC
DC Resistance	0.15 Ω
Nominal inductance(L)	0.0039 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e4
Manufacturer's serial number	IMC-0603
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Minimum quality factor (at nominal inductance)	30
Maximum rated current	0.45 A
self resonant frequency	5500 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
special characteristics	Q MEASURED AT 1000 MHZ
surface mount	YES
Terminal surface	GOLD
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	100 MHz
Tolerance	5%
Base Number Matches	1

Preview

Download Datasheet

View All

IMC-0603

Vishay Dale

High Frequency, Surface Mount, Laser Spiral,

Coated Inductors

FEATURES

•

Very small in size.

High self-resonant frequency values.

High Q values relative to size at higher frequencies.

Coated coil provides protection and moisture resistance.

Compatible with vapor phase and infrared reflow soldering.

Tape and reel packaging for automatic handling, 3000/reel, EIA-481.

L and Q value not affected by mounting orientation.

ELECTRICAL SPECIFICATIONS

Inductance Range:

1.0nH to 220nH.

Inductance Tolerance:

0.3nH for 1.0 - 3.3nH.

5% for 3.9nH to 220nH.

Operating Temperature:

- 40°C to + 100°C

Core Material:

Ceramic.

TEST EQUIPMENT

• Inductance and Q measured on HP4291B.

• SRF measured on HP8753E.

• DCR measured on HP4338B.

SELF-RESONANT

FREQ. MIN.

(MHz)

6000

5500

4800

4600

3550

3500

2800

2500

2300

2000

1800

1500

1300

1200

1100

1000

900

DCR

MAXIMUM

(Ohms)

0.06

0.07

0.08

0.09

0.10

0.12

0.15

0.17

0.18

0.20

0.28

0.32

0.35

0.41

0.45

0.50

0.55

0.60

0.80

0.95

1.20

1.30

1.50

1.80

3.00

4.50

6.5

7.5

RATED DC

CURRENT*

(mA)

500

450

430

400

350

300

250

200

130

100

STANDARD ELECTRICAL SPECIFICATIONS

TEST FREQ.

INDUCTANCE

(nH)

TOLERANCE

(MHz)

MINIMUM

(MHz)

1.0

0.3nH, 0.2nH

100

1000

1.2

0.3nH, 0.2nH

100

1000

1.5

0.3nH, 0.2nH

100

1000

1.8

0.3nH, 0.2nH

100

1000

2.2

0.3nH, 0.2nH

100

1000

2.7

0.3nH, 0.2nH

100

1000

3.3

0.3nH, 0.2nH

100

1000

3.9

100

1000

4.7

100

1000

5.6

100

1000

6.8

100

1000

8.2

100

1000

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

5%, 2%

100

500

100

5%, 2%

100

500

120

5%, 2%

100

500

150

5%, 2%

100

500

180

5%, 2%

100

500

5%, 2%

220

100

500

*Value obtained when current flows and the temperature has risen 15°C

DIMENSIONS

in inches [millimeters]

0.031

0.008

[0.8

0.20]

0.016

0.008

[0.4

0.2]

0.016

0.004

[0.4

0.1]

Recommended

Pad Layout

0.035

[ 0.8]

0.02

[0.8]

0.063

0.008

[1.6

0.20]

0.031

0.006

[0.8

0.15]

0.091

[2.3]

DESCRIPTION

IMC-0603

MODEL

10nH

INDUCTANCE VALUE

INDUCTANCE TOLERANCE

SAP PART NUMBERING GUIDELINES (INTERNAL)

SIZE

TOL.

PRODUCT FAMILY

See the end of this data book for conversion tables

PACKAGE

CODE

INDUCTANCE

VALUE

Document Number 34039

Revision 16-May-03

For technical questions, contact Magnetics@vishay.com

www.vishay.com
