LM6261MX: DescriptionBasic information of LM6261MX amplifier: LM6261MX is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, SO-8 LM6261MX amplifier core information: The minimum operating temperature of the LM6261MX is -25 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 5 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the LM6261MX has a nominal slew rate of 300 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LM6261MX gain becomes 0.707 times the low-frequency gain is 50000 kHz. The nominal supply voltage of the LM6261MX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of the LM6261MX is 9000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of LM6261MX: The width of LM6261MX is: 3.9 mm and the length is 4.9 mm. The LM6261MX has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8 LM6261MX amplifier additional information: Its temperature grade is: OTHER. And its humidity sensitivity level is: NOT SPECIFIED. The LM6261MX is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8. The corresponding JESD-609 code is: e0. The package code of LM6261MX is: SOP. The materials used in the LM6261MX package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The LM6261MX package pin forms are: SMALL OUTLINE. Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size1MB，15 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Alternative parts：LM6261MX

Download Datasheet Parametric Compare View All

LM6261MX Overview

Basic information of LM6261MX amplifier:

LM6261MX is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, SO-8

LM6261MX amplifier core information:

The minimum operating temperature of the LM6261MX is -25 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 5 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the LM6261MX has a nominal slew rate of 300 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LM6261MX gain becomes 0.707 times the low-frequency gain is 50000 kHz.

The nominal supply voltage of the LM6261MX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of the LM6261MX is 9000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of LM6261MX:

The width of LM6261MX is: 3.9 mm and the length is 4.9 mm. The LM6261MX has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8

LM6261MX amplifier additional information:

Its temperature grade is: OTHER. And its humidity sensitivity level is: NOT SPECIFIED. The LM6261MX is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8.

The corresponding JESD-609 code is: e0. The package code of LM6261MX is: SOP. The materials used in the LM6261MX package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The LM6261MX package pin forms are: SMALL OUTLINE.

Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.

LM6261MX Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	SOIC
package instruction	PLASTIC, SO-8
Contacts	8
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	5 µA
Nominal Common Mode Rejection Ratio	94 dB
Maximum input offset voltage	9000 µV
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	NOT SPECIFIED
Negative supply voltage upper limit	-18 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	1.75 mm
Nominal slew rate	300 V/us
Supply voltage upper limit	18 V
Nominal supply voltage (Vsup)	15 V
surface mount	YES
technology	BIPOLAR
Temperature level	OTHER
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	50000 kHz
width	3.9 mm
