TYPE
Fixed Inductors for Surface Mounting
Meeting Your Needs
D53FU
45
TYPE D53FU
Frequency Range:
10kHz - 1MHz
Inductance Range:
1.8 - 33mH
5.2
5
Max.
3.2 Max.
Unit: mm
Features
• Low profile (3.2mm max.)
• Ideal for IC inverter EL lamp driver applications
• Available on tape and reel for auto-insertion
• Suitable for reflow soldering
• Lead-free terminations
Recommended patterns:
Solder Pad
Solder Pad
STANDARD PARTS SELECTION GUIDE
(1) Inductance is measured by LCR-meter 4284A (HP) or equivalent.
(2) DC Resistance is measured by Digital Multimeter TR6871
(Advantest) or equivalent.
(3) Maximum allowable DC current is that which causes a 10% inductance
reduction from the initial value, or coil temperature to rise by 40°C,
whichever is smaller. (Reference ambient temperature 20°C).
No Paste
No Paste
Unit: mm
TYPE D53FU
TOKO
Part
Number
#889FU-182M=P3
#889FU-222M=P3
#889FU-272M=P3
#889FU-332M=P3
#889FU-392M=P3
#889FU-472M=P3
#889FU-562M=P3
#889FU-682M=P3
#889FU-822M=P3
#889FU-103M=P3
#889FU-123M=P3
#889FU-153M=P3
#889FU-183M=P3
#889FU-223M=P3
#889FU-273M=P3
#889FU-333M=P3
Inductance
(1)
(mH)
±20%
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
DC
(2)
Resistance
(
Ω
) max.
19
22
32
37
42
54
60
70
89
122
138
159
233
267
310
425
Inductance
(3)
Decrease Current
(mA) max.
101
92
82
75
69
63
57
53
48
44
40
37
36
32
30
29
Temperature
(3)
Rise Current
(mA) max.
94
92
72
69
64
56
52
51
46
37
35
32
27
26
24
20
Note:
=P3
is added to each part number to indicate tape and reel packaging.
Please read PRECAUTIONS and NOTES sections of this catalog for safe operation. This catalog contains consumer grade specifications only. Detailed technical specifications are available upon request.
R-LOG1104A
1.800.PIK.TOKO
www.tokoam.com
1.847.297.0070
