REVISION BF
NOTES:
FTE-1XX-XX-X-DV-XX-XX
OPTIONS
-P: PICK AND PLACE PAD (SEE FIG 2, SHT 2)
(ONLY AVAILABLE FOR 08-90 POSITIONS)
(USE PPP-37)
( USE PPP-37-NT FOR TAPE & REEL)
-TR: TAPE & REEL PACKAGING
(USE PPP-37-NT ONLY)
-A: ALIGNMENT PIN (MOLDED OR STAKED)
[ SAMTEC DISCRETION ON WHICH
-A PIN USED]
(MOLDED 4 POS MIN, SEE FIG 6, SHT 2)
(USE FTE-90-D-XX)
(STAKED 7 POS MIN, SEE FIG 5, SHT 2)
(USE FTE-90-D-A)
-M: METAL PICK & PLACE PAD
USE MPP-17-5 (SEE FIG 9 - SHT 3)
(10 POS MIN, AVAILABLE IN -01 STYLE ONLY)
FLEX SHROUD OPTIONS
(STYLE -01 ONLY)
-ES: END SHROUD
[SAMTEC DISCRETION ON WHICH -ES USED]
(SEE FIG 3, SHT 2 FOR SNAPPED-ON,
11 POSITIONS MIN)
(SEE FIG 8, SHT 2 FOR MOLDED,
5 POSITIONS PER ROW MIN, SEE TABLE 2)
-EC: END SHROUD WITH LOCKING CLIPS
(SEE FIG 7, SHT 2)
(11 POSITIONS MIN)
-EP: END SHROUD WITH GUIDE POSTS
(SEE FIG 4, SHT 2)
(11 POSITIONS MIN)
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM CUT FLASH: .010 [0.25]
No OF POSITIONS
3. MINIMUM PUSHOUT FORCE: 1 LB
-05 THRU -90
4. SHEAR TAILS TO DIMENSION SHOWN.
(PER ROW)
5. MAXIMUM BURR: .003 [0.08]
LEAD STYLE
6. MAXIMUM COPLANARITY:
-05 THRU -49 = .004 [0.10]
-01: .075 POST
-50 THRU -64 = .006 [0.15]
(USE T-1S29-04-X-2 FOR HAND FILL,
-65 THRU -90 = .009 [0.22]
T-1S29-02-X-2 FOR MACHINE FILL).
7. FOR -XX POSITION ASSEMBLY USE -XX POSITION
-02: .175 POST
BODY EXCEPT AS LISTED IN TABLE 2.
(USE T-1S29-04-X-2 FOR HAND FILL,
8. IF -A CALLED OUT ON ASSEMBLY, USE -A ON END OF BODY CALLOUT.
T-1S29-02-X-2 FOR MACHINE FILL).
USE FTE-190-0X-G-DV-SA FOR STOCK THAT WILL BE CUT FOR STAKED -A ORDERS.
-03: .120 POST
USE FTE-190-0X-G-DV FOR ORDERS NOT REQUIRING STAKED -A OPTION.
(USE T-1S29-04-X-2 FOR HAND FILL,
9. MAXIMUM ATTACHED FLASH ALLOWED ON POST SIDE ONLY: .02 [0.5]
T-1S29-02-X-2 FOR MACHINE FILL).
10. DURING CUT PROCESS, WALL MUST BE A MINIMUM OF .004" OR COMPLETELY REMOVED.
11. IF RETENTION IS BELOW SPECIFICATION, A SUBSTITUTION OF FTE-90-D FOR FTE-90-D-A
IS ACCEPTABLE.
PLATING SPEC
-G: 10µ" GOLD IN CONTACT AREA,
C
3µ" GOLD ON TAIL
+.004[+0.10]
(No OF POS x .0315)
-.010[-0.25]
.0157 0.399
"A"
.0315 0.800
180
C
L
.1200 3.048
REF
ROW SPECIFICATION
-DV: DOUBLE ROW VERTICAL
(USE FTE-90-D-A)
02
SEE NOTE 11
01
"A"
2 MAX SWAY
(EITHER DIRECTION)
.0120 0.305 SQ REF
179
2 MAX SWAY
(EITHER DIRECTION)
T-1S29-XX-X-2
SEE NOTE 9
C
"A"
(SEE TABLE 1)
SEE NOTE 6
FTE-90-D
2.5 MAX SWAY
(EITHER DIRECTION)
.0472±.016 1.200±0.41
C
.075 1.91
(CONTACT AREA)
.055 1.40 REF
C
90°±3°
.070 1.78
SEE NOTE 2
SEE NOTE 2
.18 4.6
BURR SIDE
(SEE NOTE 4 & 5)
SECTION "A"-"A"
FTE-1XX-03-X-DV SHOWN
FIG 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.X:
.1 [2.5]
.XX: .01 [0.3]
2
.XXX: .005 [0.13]
.XXXX: .0020 [0.051]
MATERIAL:
DECIMALS
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
INSULATOR: BLACK, LCP, UL 94 VO
TERMINAL: PHOS BRONZE
F:\DWG\MISC\MKTG\FTE-1XX-XX-X-DV-XX-XX-MKT.SLDDRW
.8MM x 1.2MM C.L. TERMINAL STRIP ASSM.
FTE-1XX-XX-X-DV-XX-XX
9/01/2009
SHEET
1
OF
3
BY:
DEAN P
REVISION BF
.200 5.08
REF
C
L
"P"
.125 3.18
REF
"R" REF
(NO OF POS x .0315 [.800] + .217 [5.53])
FTE-EP
.0080 [0.203]
.275 6.99 REF
.075 1.91 REF
.290 7.37
REF
"M"
"M"= No OF POS X .0315 [0.800]
"P"= ("M" - .200 [5.08]) / 2 .020 [0.51]
-EP OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
.120 3.05 REF
(NO OF POS x .0315 [0.800])
+ .025 [0.64] REF
.150 3.81
REF
.314 7.98
-P OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
FIG 2
FIG 4
((NO OF POS + 2) x .0315)
- .010
[-0.25]
.0057 0.145 REF
(SEE NOTE 10)
+.004
[+0.10]
(NO OF POS X .0315)
+.004[+0.10]
-.010[-0.25]
NO OF POS X .0315 [0.800] + .062 [1.57]
.197 5.00 REF
FTE-ES
.008 [0.20]
.164 4.17
REF
.130 3.30 REF
'B'
FTE-XX-D-ES-XX-X
.165 4.19 REF
.150 3.81
DETAIL 'B'
SCALE 6 : 1
(4 PLCS)
.140 3.56
REF
.164 4.17
.135 3.43
REF
-ES OPTION (SNAPPED ON) (11 POS MIN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
C
(NO OF POS - 2) x .0315 [0.800]
.003 [0.08]
C .025 0.64
SM-A11H
.025 0.64 REF
C
L
FIG 3
-ES OPTION (MOLDED) (5 POS MIN)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
{(NO OF POS x .0315 [0.800]) + .160 [4.06]} .008 [0.20]
FTE-EC
FIG 8
.164 4.17
.024 0.61
REF
{(NO OF POS x .0315 [0.800]) + .111 [2.82]}
.008 [0.20]
-A OPTION (STAKED) (7 POS MIN)
(DIFFERENT AS SHOWN OTHERWISE SAME AS FIG 1)
FIG 5
.037 0.94 REF
-EC OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
FIG 7
.070 1.78
LC-05-TM
FTE-90-D-XX
C
L
(NO OF POS - 2) x .0315 [0.800]
.003 [0.08]
.025 0.64
REF
*
PROPRIETARY NOTE
*
.037 0.94
REF
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
-A OPTION (MOLDED) (4 POS MIN)
(DIFFERENT AS SHOWN OTHERWISE SAME AS FIG 1)
FIG 6
.025 0.64 REF
F:\DWG\MISC\MKTG\FTE-1XX-XX-X-DV-XX-XX-MKT.SLDDRW
.8MM x 1.2MM C.L. TERMINAL STRIP ASSM.
SHEET SCALE: 4:1
FTE-1XX-XX-X-DV-XX-XX
9/01/2009
SHEET
2
OF
3
BY:
DEAN P
REVISION BF
"M"
.250 6.35
REF
MPP-17-5
.100 2.54
"P"
.065 1.65 REF
.080 2.03
"M" = No OF POSITIONS x .0315 [0.800]
"P" = {( "M" - .250 [6.35]) / 2 } .020 [0.51]
-M OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
PT-1-24-01-37
PT-FTE001-DV-P
PT-FTE001-DV-P
PT-1-24-01-37
FIG 9
-01-EC & -EC-M OPTIONS
-01-EC-P OPTION
-01-ES-P OPTION
-01-ES-A-P OPTION
PT-1-24-13-09
-01 & -03 OPTION
-01-A &
-03-A OPTION
PT-1-24-01-37
-02 OPTION
PT-FTE001-DV-P
-02-A OPTION
PT-FTE001-DV-P
PT-1-24-01-09
-01-ES & -01-ES-A OPTIONS
*
PROPRIETARY NOTE
*
-01-ES-M OPTION
01-EP
01-EP-M
-01-EP-P OPTION
-01-P, -02-P &
-03-P OPTION
-01-A-P, -02-A-P &
-03-A-P OPTION
-01-M
& -01-A-M
OPTION
F:\DWG\MISC\MKTG\FTE-1XX-XX-X-DV-XX-XX-MKT.SLDDRW
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
.8MM x 1.2MM C.L. TERMINAL STRIP ASSM.
FTE-1XX-XX-X-DV-XX-XX
9/01/2009
SHEET
3
OF
3
BY:
DEAN P
