PLL400-915AY datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Analog mixed-signal IC> PLL400-915AY

PLL400-915AY: DescriptionPHASE LOCKED LOOP, 928 MHz, DSO12; Categorysemiconductor Analog mixed-signal IC; File Size51KB，1 Pages; ManufacturerSIRENZA; Websitehttp://www.sirenza.com/

Download Datasheet Parametric Compare View All

PLL400-915AY Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PLL400-915AY	-	-	View	Buy Now

PLL400-915AY Overview

PHASE LOCKED LOOP, 928 MHz, DSO12

PLL400-915AY Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	12
Minimum operating temperature	-40 Cel
Maximum operating temperature	85 Cel
Rated supply voltage	5 V
Minimum supply/operating voltage	4.75 V
Maximum supply/operating voltage	5.25 V
Processing package description	0.600 X 0.600 INCH, 0.140 INCH HEIGHT, ROHS COMPLIANT, PLL400-12
each_compli	Yes
EU RoHS regulations	Yes
state	Active
Analog IC other types	PHASE LOCKED LOOP
jesd_30_code	S-XDSO-N12
jesd_609_code	e4
moisture_sensitivity_level	1
Packaging Materials	UNSPECIFIED
ckage_code	SON
packaging shape	SQUARE
Package Size	SMALL OUTLINE
eak_reflow_temperature__cel_	260
qualification_status	COMMERCIAL
seated_height_max	3.5 mm
surface mount	YES
Temperature level	INDUSTRIAL
terminal coating	GOLD OVER NICKEL
Terminal form	NO LEAD
Terminal spacing	2.03 mm
Terminal location	DUAL
ime_peak_reflow_temperature_max__s_	30
length	15.24 mm
width	15.24 mm

Preview

Download Datasheet

View All

PLL Product Specification

Model:

Customer:

PLL350-1120(Y)

SIRENZA

MICRODEVICES, INC.

Rev:

AppNote:

Date:

9/1/2006

113 Option 207000

Operating Temperature Range:

( -30 ° to 80 ° C)

RoHS Compliant

To order models as RoHS Compliant add "Y" suffix to base

model number.

Parameter

Frequency Range -

Step Size -

Settling Time - to within 1 kHz

Output Power -

Output Phase Noise:

1 kHz

10 kHz

30 kHz

Power Supply -

Supply Current -

Spurious Product - 100 kHz

Reference Feedthrough -

Harmonic Suppression:

2nd Harmonic

3rd Harmonic

Ref Osc Signal:

Frequency

Amplitude

Phase Noise - 1 kHz

Input Impedance

Output Impedance -

Min

1090

Typ

1120

100

Max

1150

150

Units

MHz

kHz

mSec

dBm

Remarks

-1

-79

-107

-118

4.75

-75

-74

-95

-112

5.25

-70

dBc/Hz

Volts

dBc

-15

-10

dBc

-145

100

MHz

Vp-p

dBc/Hz

Package Information

Package Type:

PLL350

(0.8 x 0.582 x 0.154 inches

Drawing Number:

61054

)

Comments

Indicates parameter to be tested 100% in production

Performance tests and ratings for Sirenza Microdevices' products were performed internally by Sirenza and measured using specific computer systems

and/or components and reflect the approximate performance of the the products as measured by those tests. Any difference in circuit implementation, test

software, or test equipment may affect actual performance. The information provided herein is believed to be reliable at press time and Sirenza

Microdevices assumes no responsibility for the use of this information. All such use shall be entirely at the user's own risk. Prices and specifications for

Sirenza Microdevices' products are subject to change without notice. Buyers should consult Sirenza Microdevices' standard terms and conditions of sale

for Sirenza's limited warranty with regard to its products. These products may be patented or include patented technology. No patent rights or licenses to

any of the circuits described herein are implied or granted to any third party. Sirenza Microdevices does not authorize or warrant any product for use in

life-support devices and/or systems.

Page 1 of 1

Sirenza Microdevices, Inc.

303 S. Technology Ct.

Broomfield, CO 80021

tel 303.327.3030

fax 303.410.7988
