IBEK
€
www.ibek.ch
Single & double outputs
Input to output isolated
6 Watt
DC-DC-Converter
Family IPS6
•
•
•
•
•
•
•
•
•
Ultra wide 1:4 input voltage ranges
Shutdown input (optional)
Very high efficiency up to 84%
High reliability
Continuous no-load and short-circuit proof
Extended ambient temperature range -40…+85‚C
2" x 1" x 0.41” case with industrial standard pinning
Made in Switzerland, accordingly ISO 9001:2000
2 years warranty
Standard Types
2
Single output
xx IPS6-05-TC
RoHS
xx IPS6-12-TC
RoHS
xx IPS6-15-TC
RoHS
Double output
3
xx IPS6-0505-TC
RoHS
xx IPS6-1212-TC
RoHS
xx IPS6-1515-TC
RoHS
2
Electromagnetic emission EN 55022 < A
Conducted and radiated emissions
24 IPS
No load input current
Input current in shutdown condition
Switching frequency
Output voltage accuracy
Static line regulation
Static load regulation FL to 10%
Output voltage noise (20 MHz BW)
Efficiency
I/O Electric strength test voltage
Coupling capacitance
Shutdown input (SD) :
Ambient temperature range
Case temperature range
Storage temperature range
Case material
MTBF, GB @ 40‚C case
(MIL-HDBK-217F, Notice 2)
1
Input voltage
VDC
9…36
(nominal 24)
45 V for 10 ms
repetition rate
10 s
Output
VDC
mA
5
12
15
€ 5
• 12
€ 15
1200
500
400
€ 600
• 250
€ 200
48 IPS
15
10
mA typ.
1.3 mA typ.
400 kHz typ.
€ 1% max.
€ 15 mV typ.
0…25 mV typ.
5 VDC 12 VDC 15 VDC outputs
50
120
150
mVpp typ.
80% to 84% typ.
1500 VDC
1000 pF
Apply -0.3…+0.6 VDC to shut down (switch off) the
Output voltage(s). Normal operation with open pin.
-T: -25…+71‚C; -S: -40…+85‚C
1
-T: -25…+95‚C; -S: -40…+105‚C
-T: -55…+105‚C; -S: -55…+105‚C
Metal with plastic bottom cover, UL94 V-0 rated
1.500.000 hours
18…75
(nominal 48)
To complete type number replace "xx" by the required nominal
input voltage, e.g. 24 IPS6-05-TC
RoHS
.
3
Double outputs should have symmetrical load conditions to
comply with the specifications listed on the left side.
Extended temperature range -S is available for all types.
Replace -T by -S on type number, e.g. 48 IPS6-1515-SC
RoHS
.
Modifications and customs are available upon request.
Power derating from 6W to 5W for 71‚C to 85‚C
Dimensions in mm (inches)
Pin
1
2
3
4
5
6
4
4
Pin Configuration
Single output
Double output
+Vi
+Vi
-Gi
-Gi
+Vo
+Vo
No pin
Go
-Go
-Vo
SD
SD
Optional shutdown pin. If required replace C by G on type
number, e.g. 24 IPS6-05-TG
RoHS
.
Specifications subject to change without notice
15.12.2008
More power with IBEK
€
!
Page 26.9
