IML 10 Series
10 Watt DC-DC Converters
Wide input voltage ranges up to 75 V DC
1 or 2 outputs up to 30 V DC
1500 V DC I/O electric strength test voltage
LGA
• Magnetic feedback for single output models
• Short circuit protection
• Industry standard 2" x 1" case with 10.5 mm
profile
Selection chart
Output 1
Output 2
Input voltage
Type
1
Options
1
U
o nom
I
o nom
U
o nom
I
o nom
U
i
[V DC]
18...36
36...75
18...36
36...75
18...36
36...75
18...36
36...75
36...75
18...36
36...75
18...36
36...75
24 IML 10-03-3
48 IML 10-03-3
24 IML 10-05-3
48 IML 10-05-3
24 IML 10-12-3C
48 IML 10-12-3C
24 IML 10-15-3C
48 IML 10-15-3C
48 IML 10-0503-3
24 IML 10-12-12-3
48 IML 10-12-12-3
24 IML 10-15-15-3
48 IML 10-15-15-3
C,
C,
C,
C,
Z
Z
Z
Z
[V DC]
[A]
[V DC]
[A]
3.3
2
-
-
3.3
2
-
-
5
1.9
-
-
5
1.9
-
-
12
0.9
-
-
12
0.9
-
-
15
0.7
-
-
15
0.7
-
-
5.1
1
3.3
1
12
0.45
12
0.45
12
0.45
12
0.45
15
0.35
15
0.35
15
0.35
15
0.35
1
For availability contact Power-One.
C, Z
C, Z
C, Z
C, Z
C, Z
www.power-one.com
Edition 4/04.2001
1
Board Mountable
Input
Input voltage range
24 IML 10
48 IML 10
IML 10 Series
18...36 V DC
36...75 V DC
Output
Output voltage setting accuracy
U
i nom
, 50%
l
o nom
, single output models
±1.5%
U
o nom
U
i nom
, 50%
l
o nom
, double outp., main/aux. outp.±1.5%/±1.5%
U
o nom
Minimum load
recommended
10%
l
o nom
Line/load regulation
U
i min
...U
i max
, 50%
l
o nom
, single output models
±3%
U
o nom
Line regulation
U
i nom
, 50%
l
o nom
, double output models, main output
±1%
U
o nom
Load regulation
U
i nom
, 10...100%
l
o nom
, double outp. mod., main outp.
±3%
U
o nom
tracking output
±3%
U
o nom
Output voltage switching noise
U
i nom
, 0...100%
l
o nom
, peak-peak, total
max. 1.5%
U
o nom
Efficiency
U
i nom
,
l
o nom
up to 84%
Control and protection
Input protection
Overload protection
No-load protection
U
i min
...U
i max
, any load
none
fully protected, hiccup mode
yes
Safety and EMC
Electric strength test voltage
Electromagnetic interference
I/O
1500 V DC
class A
Environmental
Operating ambient temperature
U
i nom
, l
o nom
Storage temperature
non operational
Relative humidity
non condensing
–25...60°C
–40...100°C
93%
Options
Open version without housing
C-pinout
Z
C
Accessories
DIN and chassis mounting bracket
www.power-one.com
Edition 4/04.2001
2
