2SC2532
TOSHIBA Transistor Silicon NPN Epitaxial Type (PCT process)
2SC2532
Audio Frequency Amplifier Applications
Driver Stage for LED Lamp Applications
Temperature Compensation Applications
·
High h
FE
: h
FE
(1) = 5000 (min) (IC = 10 mA)
h
FE
(2) = 10000 (min) (IC = 100 mA)
Unit: mm
Maximum Ratings
(Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
40
40
10
300
60
150
125
-55~125
Unit
V
V
V
mA
mA
mW
°C
°C
JEDEC
JEITA
TOSHIBA
TO-236MOD
SC-59
2-3F1A
Weight: 0.012 g (typ.)
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Base-emitter voltage
Symbol
I
CBO
I
EBO
h
FE
(1)
h
FE
(2)
V
CE (sat)
V
BE
Test Condition
V
CB
=
40 V, I
E
=
0
V
EB
=
8 V, I
C
=
0
V
CE
=
5 V, I
C
=
10 mA
V
CE
=
2 V, I
C
=
100 mA
I
C
=
300 mA, I
B
=
0.3 mA
V
CB
=
2 V, I
C
=
100 mA
Min
¾
¾
5000
10000
¾
¾
Typ.
¾
¾
¾
¾
0.9
1.25
Max
0.1
0.1
¾
¾
1.3
1.6
V
V
Unit
mA
mA
Marking
Equivalent Circuit
1
2003-03-27
2SC2532
RESTRICTIONS ON PRODUCT USE
000707EAA
·
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor
devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical
stress. It is the responsibility of the buyer, when utilizing TOSHIBA products, to comply with the standards of
safety in making a safe design for the entire system, and to avoid situations in which a malfunction or failure of
such TOSHIBA products could cause loss of human life, bodily injury or damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as
set forth in the most recent TOSHIBA products specifications. Also, please keep in mind the precautions and
conditions set forth in the “Handling Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability
Handbook” etc..
·
The TOSHIBA products listed in this document are intended for usage in general electronics applications
(computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances,
etc.). These TOSHIBA products are neither intended nor warranted for usage in equipment that requires
extraordinarily high quality and/or reliability or a malfunction or failure of which may cause loss of human life or
bodily injury (“Unintended Usage”). Unintended Usage include atomic energy control instruments, airplane or
spaceship instruments, transportation instruments, traffic signal instruments, combustion control instruments,
medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this
document shall be made at the customer’s own risk.
·
The information contained herein is presented only as a guide for the applications of our products. No
responsibility is assumed by TOSHIBA CORPORATION for any infringements of intellectual property or other
rights of the third parties which may result from its use. No license is granted by implication or otherwise under
any intellectual property or other rights of TOSHIBA CORPORATION or others.
·
The information contained herein is subject to change without notice.
3
2003-03-27
