RF Signal Choke—3361I-series
A. Specifications:
Part
Number
3361I-090
3361I-100
3361I-110
3361I-120
3361I-130
3361I-140
3361I-150
3361I-165
3361I-180
3361I-200
3361I-220
3361I-240
3361I-280
3361I-310
3361I-350
1
BLK
BRN
BRN
BRN
BRN
BRN
BRN
BRN
BRN
RED
RED
RED
RED
ORG
ORG
Color Dots
2
3
WHT
BLK
BRN
RED
ORG
YEL
GRN
BLU
GRY
BLK
RED
YEL
GRY
BRN
GRN
BLK
BLK
BLK
BLK
BLK
BLK
BLK
GRN
BLK
BLK
BLK
BLK
BLK
BLK
BLK
Inductance
(nH) ± 5%
90
100
110
120
130
140
150
165
180
200
220
240
280
310
350
Q
80
80
80
80
80
80
80
80
80
80
80
70
70
70
70
Test Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR(Ω)
Max.
0.035
0.035
0.035
0.035
0.035
0.045
0.045
0.045
0.045
0.045
0.058
0.058
0.058
0.058
0.058
Rated Current
(mA)
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
B. Mechanical Dimensions:
UNIT: mm
DIM.
A
B
C
D
E
F
6.0
8.0
3.0
4.5
0.5φ
6.5
TOL.
±0.5
+1.0/-0.5
+1.0/-0.5
±0.5
±0.05
MAX.
COLOR DOT 1
C. General information:
1.
2.
3.
4.
5.
6.
7.
For high frequency up to 1.0GHz.
High Q up to 150MHz.
Electrical specifications at 25°C.
Temperature stability: 155ppm/°C.
Operating temperature: -30°C TO +85°C.
Tolerance for ± 1% is available upon request.
For LC filter, CATV diplex filter.
Custom specifications are available.
COLOR DOT 2
COLOR DOT 3
Note:
RoHS
compliant; for the
ROHS
parts, we add “-LFR” at the end of the P/N.
RF Signal Choke P/N: 3361I-Series
