THE CONNOR-WINFIELD CORP.
2111 COMPREHENSIVE DRIVE.
AURORA, IL 60505.
FAX (630) 851-5040.
PHONE (630) 851-4722.
www.conwin.com
PRODUCT
D ATA
SHEET
CRYSTAL CONTROLLED OSCILLATORS
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Storage Temperature
Supply Voltage
Control Voltage
OPERATING SPECIFICATIONS
PARAMETER
Center Frequency
Frequency Calibration, Vc=2.18 Vdc
Frequency Stability
Aging (Daily)
Aging (20 Years)
Total Frequency Tolerance
Operating Temperature Range
Supply Voltage
Supply Current
Phase Jitter (BW=12KHz to 20MHz)
Phase Jitter (BW=10Hz to 20MHz)
Period Jitter
SSB Phase Noise at 10Hz offset
SSB Phase Noise at 10KHz offset
Start Up Time: Oscillator
Warm Up Time
TDEV @ 1.0 Sec.
TDEV @ 4.0 Sec.
INTPUT CHARACTERISTICS
PARAMETER
Control Voltage Range
Frequency at Vc=0.3 Vdc
Frequency at Vc=3.0 Vdc
Slope of Frequency Adjust
Input Impedance
HCMOS OUTPUT CHARACTERISTICS
PARAMETER
LOAD
Voltage
(High)
(Low)
Current
(High)
(Low)
Duty Cycle at 50% of Vcc
Rise / Fall Time 10% to 90%
PACKAGE CHARACTERISTICS
Package
(Voh)
(Vol)
(Ioh)
(Ioh)
MINIMUM
-
4.5
-
-4
-
45
-
NOMINAL
-
-
-
-
50
-
MAXIMUM
15
-
0.4
-
4
55
6
UNITS
pf
Vdc
Vdc
mA
mA
%
nS
(Vc)
MINIMUM
0.5
-30
18
5
100k
NOMINAL
2.18
-
-
-
-
MAXIMUM
4.1
-18
30
-
-
UNITS
Vdc
ppm
ppm
ppm/V
Ohm
TABLE 4.0
NOTE
6
6
(Vcc)
(Icc)
(Fo)
MINIMUM
1.544
-1.5
-0.25
-30
-2.5
-4.6
0
4.75
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
5.0
-
-
-
-
-90
-135
-
-
-
-
NOMINAL
-
MAXIMUM
20.0
1.5
0.25
30
2.5
4.6
70
5.25
350
1
3
3
-
-
10
5
1
2
UNITS
MHz
ppm
ppm
ppb
ppm
ppm
°C
Vdc
mA
ps rms
ps rms
ps rms
dBc/Hz
dBc/Hz
mS
Minutes
nS
nS
1
2
3
4
UNITS
(Vcc)
(Vc)
MINIMUM
-40
-0.5
-0.5
NOMINAL
-
-
-
MAXIMUM
85
7.0
7.0
UNITS
°C
Vdc
Vdc
TABLE 2.0
NOTE
TABLE 1.0
NOTE
ASOV5S3
DESCRIPTION
5
The Connor-Winfield
ASOV5S3 is a true Surface
Mount 5.0V Oven Controlled
Crystal Oscillator (OCXO) with
an HCMOS output. The
ASOV5S3 is designed for
Stratum 3 applications
requiring tight frequency
stability and low jitter.
TABLE 3.0
NOTE
FEATURES
FREQUENCY ADJUST
5.0V OPERATION
LOW JITTER <1pS RMS
TEMPERATURE STABILITY
±0.25ppm
FREQUENCY TOLERANCE OF
±4.6ppm OVER TWENTY YEARS
SURFACE MOUNT PACKAGE
TAPE AND REEL PACKAGING
TABLE 5.0
Surface Mount, Non-hermetic package consisting of an FR4 substrate with
grounded metal cover.
TABLE 6.0
The component solder used internal to this device has a mel ting point of
221°C. The peak temperature inside the device should be less than or equal
to 220°C for a maximum of 10 seconds
Ultrasonic cleaning is not recommended
PROCESS RECOMMENDATIONS
Solder Reflow
Wash
Notes:
ORDERING INFORMATION
Initial calibration @ 25°C, Vc=2.18 Vdc.
Frequency vs. temperature stability
At the time of shipment after48 hours of operation.
Inclusive of calibration, operating temperature range, supply voltage change, load change, shock
and vibration, 20 years aging, Vc=2.18 Vdc.
5) Measured @ 25°C, within 5 minutes, the unit will be within +/-0.1ppm of its reference frequency,
measured after 30 minutes of continuous operation at a stable 25°C
6) Referenced to Fo @ 25°C, Positive Transfer Characteristic
1)
2)
3)
4)
ASOV5S3 - 12.80MHz
OCXO
SERIES
CENTER
FREQUENCY
Specifications subject to change without notice.
DATA SHEET #:
Cx016
PAGE
1
OF
2
REV:
04
DATE:
6/24/03
a
Copyright 2001 Connor-Winfield all rights reserved.
CW 0107
ASOV5S3
12.80M
SURFACE MOUNT 5.0V HCMOS STRATUM 3 OCXO
THE CONNOR-WINFIELD CORP.
2111 COMPREHENSIVE DRIVE.
AURORA, IL 60505.
FAX (630) 851-5040.
PHONE (630) 851-4722.
www.conwin.com
PRODUCT
D ATA
SHEET
CRYSTAL CONTROLLED OSCILLATORS
ENVIRONMENTAL CHARACTERISTICS
Temperature Cycle: Per MIL-STD-883, Method 1010, Condition B. -55°C to 125°C, 20 cycles,10 minute dwell, 1m inute
transition.
SOLDERING
Pad Solderability: Per MIL-STD-883, Method 200. 8 hour steam age prior to 254°C ±5°C Solder pot dip, 95% Coverage.
Solder Reflow: The component solder internal to this device has a melt ing point of 221°C, the peak temperature inside the
device should be less than or equal to 220°C for a maximum of 10 seconds.
MECHANICAL CHARACTERISTICS
Vibration: Per MIL-STD-202, Method 204, Condition A. 10G’s peak, 10Hz to 500Hz, 15mi nute cycles 12 times each
perpendicular axis.
Shock: Per MIL-STD-202, Method 213, Condition D. 500G’s, 1ms, half sine, 3 shocks per direction.
Moisture Resistance: Per MIL-STD-202, Method 106. 95% RH @ 65°C, 10 cycles 10°C to 65°C.
PIN FUNCTION
.330 max
(8.382mm)
CW
DATE CODE
ASOV5S3
12.80M
1
7
8
14
CONTROL VOLTAGE
GROUND (CASE)
OUTPUT
Vcc
Dimensional Tolerance:
±.005 (.127mm)
KEEP OUT AREA
90%
.830
(21.08mm)
50%
10%
.565
(14.35mm)
CONTROL
VOLTAGE
4.1Vdc
POWER
SUPPLY
5.0Vdc
14
8
1
7
Specifications subject to change without notice.
DATA SHEET #:
Cx016
PAGE
2
OF
2
REV:
04
DATE:
6/24/03
a
Copyright 2001 Connor-Winfield all rights reserved.
