P/N: C-13-001-E-XX
1310nm Laser Diodes
Features
Uncooled laser diode with MQW structure
5mW CW operation at –40 to +85ºC
High temperature operation without active cooling
Hermetically sealed active component
Built-in InGaAs monitor photodiode
Complies with Telcordia(Bellcore) GR-468-CORE
TO-56 packaging with a flat window cap or a ball lens
cap
RoHS compliance available
Absolute Maximum Rating (Tc=25ºC)
Parameter
Optical Output Power
LD Reverse Voltage
LD Forward Current
PD Reverse Voltage
PD Forward Current
Operating Temperature
Storage Temperature
Symbol
Po
V
RLD
I
FLD
V
RPD
I
FPD
T
opr
T
stg
Value
10(CW)
2
150
10
2
-40 to +85
-40 to +85
Unit
mW
V
mA
V
mA
ºC
ºC
Optical and Electrical Characteristics( Tc=25ºC)
Optical and Electrical Characteristics( Tc=25ºC)
Parameter
Slope Efficiency
Flat window cap
Ball lens cap
Threshold Current
Optical output power
Peak Wavelength
Spectral Width
Forward Voltage
Symbol
Min.
Typical
Max.
Unit
Test Condition
SE
0.3
0.2
0.35
0.3
10
-
1310
2
1.2
-
mW/mA
CW,P
o
=5mW
Ith
Po
λ
Δλ
V
F
-
5
1290
-
-
15
-
1330
5
1.5
mA
mW
nm
nm
V
CW,P
o
=5mW
CW,kink free
Note
CW,P
o
=5mW
CW,P
o
=5mW
DS-5669 JUN1609-Rev 00
P/N: C-13-001-E-XX
1310nm Laser Diodes
Warnings
Handling Precautions:
This device is susceptible to damage as a result of electrostatic discharge (ESD). A static
free environment is highly recommended. Follow guidelines according to proper ESD procedures.
Laser Safety:
Radiation emitted by laser devices can be dangerous to human eyes. Avoid eye exposure to direct or
indirect radiation.
