R3116x Series
0.8% Accuracy, 0.5V Operating VD with Delay Function (External Capacitor Type)
The R3116x Series are CMOS-based voltage detector ICs with the built-in output delay circuit. The R3116x can operate at low voltage
from 0.5V and the detector threshold can be specified from 0.7V. The detector threshold accuracy as high as
±
0.8% helps to increase
stable operating area coupled with lower voltage. Additionally, the high accuracy output delay time at
±
15% allows easy control of
the start-up sequence. In addition to SOT-23-5 and SC-82AB packages, a 1mm square DFN(PLP)1010-4 package is also available.
FEATURES
•
Supply Current (I
SS
) ························Typ. 0.35μA (V
DD
=-V
SET
+1.0V, R3116x151x)
•
Temp. coeff. of Detector Threshold ···Typ.
±
30ppm/°C
•
Operating Voltage Range (V
DD
) ······0.5V to 6.0V
•
Two Output Types···························Nch. Open Drain Output and
•
Detector Threshold Range (-V
DET
) ··0.7V to 5.0V (Internally fixed)
CMOS
•
Output Delay···································Typ. 100ms delay set with a 0.022μF external
•
Packages········································DFN(PLP)1010-4,
•
Reset Signal ···································"L"
•
Detector Threshold Accuracy··········± 0.8%
capacitor
SC-82AB, SOT-23-5
(The above shows specification at Topt=25
°
C. Design assurance value at -40
°
C
≤
Topt
≤
85
°
C is also available. For details, please refer to the datasheet.)
BLOCK DIAGRAMS
R3116xxx1A
(Nch. open drain output)
V
DD
OUT
V
DD
R3116xxx1C
(CMOS output)
Delay
Circuit
Vref
GND
C
D
Vref
Delay
Circuit
OUT
GND
C
D
SELECTION GUIDES
Halogen Free
Package
Q'ty per Reel
Part No.
DFN(PLP)1010-4 10,000 pcs R3116K.xx.1.
∗
.-TR
SC-82AB
3,000 pcs R3116Q.xx.1.
∗
.-TR-FE
SOT-23-5
3,000 pcs R3116N.xx.1.
∗
.-TR-FE
TIMING CHARTS
Release Voltage
+V
DET
Supply
Voltage Detector Threshold
-V
DET
(V
DD
)
Minimum Operating
V
DDL
Voltage
GND
Pull-up Voltage
Output
Voltage
(V
OUT
)
Hysteresis
.xx.
: Specify the detector threshold within the range of
0.7V (.07.) to 5.0V (.50.) in 0.1V steps.
.
∗
.
: Select the output type from (.A.) Nch. open drain or (.C.) CMOS.
PACKAGES (Top View)
DFN(PLP)1010-4
4
3
GND
SC-82AB
4
3
SOT-23-5
5
4
t
PHL
R3116xxx1A
Release Voltage
+V
DET
Supply
Voltage Detector Threshold
-V
DET
(V
DD
)
Minimum Operating
V
DDL
Voltage
GND
Pull-up Voltage
Output
Voltage
(V
OUT
)
t
D
∗
Hysteresis
1
2
1
2
1
2
3
1
2
3
4
OUT
C
D
GND
V
DD
1
2
3
4
V
DD
GND
C
D
OUT
1
2
3
4
5
OUT
V
DD
GND
NC
C
D
GND
∗
) The tab is substrate level (GND).
t
PHL
R3116xxx1C
t
D
APPLICATIONS
•
Microcontroller and logic circuit reset
•
Wave shaping circuit
No.EK-161-121001
•
Battery checker
•
Battery back-up circuit
•
Window comparator
•
Power failure detector
CMOS Voltage Detector
R3116x Series
CMOS Voltage Detector
0.8% Accuracy, 0.5V Operating VD with Delay Function (External Capacitor Type)
COMPARISON OF VOLTAGE DETECTORS
R3116x Series
Supply Current (at released)
Operating Voltage Range
Detector Threshold Range
Detector Threshold Accuracy
Output Delay
Output Delay Time Accuracy
Temp. coeff. of Detector Threshold
Packages
Typ. 0.35μA
0.5V to 6.0V
0.7V to 5.0V
±0.8%
±15%
Typ.
±30ppm/°C
DFN(PLP)1010-4 (1.0mm×1.0mm)
SC-82AB (2.0mm×2.1mm)
SOT-23-5 (2.9mm×2.8mm)
Typ. 0.5μA
0.7V to 6.0V
0.9V to 5.0V
±2%
-
Typ.
±100ppm/°C
SON1612-6 (1.6mm×1.6mm)
SC-82AB (2.0mm×2.1mm)
SC-88A (2.0mm×2.1mm)
SOT-23-5 (2.9mm×2.8mm)
R3112x Series
Typ. 100ms delay set with a 0.022μF external capacitor
HIGHER ACCURACY OUTPUT DELAY TIME
WHAT IS DFN(PLP)1010-4?
The high-accuracy output delay time allows easy control of the start-up
sequence.
The DFN(PLP)package is a leadless package using an
electroforming sheet in place of lead frame.
This extremely compact package features increased
power dissipation and conversion to thinner type.
The name is representing by a combination of the body
size and the number of pins, i.e., DFN(PLP)1010-4
stands for the body size of 1.0mm
×
1.0mm and 4pins.
An environment-friendly, leadfree package with gold
plated contacts complies with the RoHS Directive.
The currently available information as of October 2012 is provided in this New Product News.
EK-161-121001
