The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
sDouble
Row Straight Pin Header (SMT)
s(Four-Wall
Type Compliant to Emboss Absorption)
BPCB
mounting pattern
BTube
Dimensions
Note 1.If the pattern exists in
the shaded area, and
isn't treated with
resist, it could touch
the connector contact.
Note 2.The hole isn't needed
at "Without boss".
[Specific No.] -
**,
(**)
(20): Tin plated tube packaging
(29): Tin plated embossed tape packaging
(50): Gold plated tube packaging
(59): Gold plated embossed tape packaging
Unit: mm
Number of
Part Number
CL No.
Contacts
10
20
30
40
10
20
30
40
A
12.1
B
5
C
8.7
D
7.5
20
–
–
–
–
DF13A-10DP-1.25V(**) 536-0510-8-**
DF13A-20DP-1.25V(**) 536-0515-1-**
DF13A-30DP-1.25V(**) 536-0520-1-**
DF13A-40DP-1.25V(**) 536-0525-5-**
DF13A-10DP-1.25V(**) 536-0600-9-**
DF13A-20DP-1.25V(**) 536-0605-2-**
DF13A-30DP-1.25V(**) 536-0610-2-**
DF13A-40DP-1.25V(**) 536-0615-6-**
Specification Specification Specification Specification Tube Package Emboss
(20)
K
K
–
–
K
K
–
–
(29)
K
K
–
–
K
K
–
–
(50)
K
K
K
K
K
K
K
K
(59)
K
K
K
K
K
K
K
K
Quantity
40 pcs
26
19
15
40
26
19
15
Width
24
32
44
44
24
32
44
44
Without
boss
With
boss
Remarks
18.35 11.25 14.95 13.75
24.6 17.5 21.2
12.1
5
8.7
30.85 23.75 27.45 26.25
18.35 11.25 14.95
24.6 17.5 21.2
30.85 23.75 27.45
Note 1.Please order the tube packaging product, multiplying the tube packaging quantity.
Note 2.Please order the embossed tape packaging product according to reel number. (1 reel: 1000 pcs.)
Note 3.The absorption cap is attached to the embossed tape packaging product.
B190
