FEATURES AND SPECIFICATIONS
Features and Benefits
s
50
µ
" Gold meets FCC 68 requirements
s
Keying options available
s
Top-covered leads meet British Telecom 4000V test
s
Contacts are duplex plated after stamping, eliminating
bare edges in the mating area
s
Every jack must pass on-line functional tests, including
hi-pot and continuity
Reference Information
Product Specification: PS-41314
Packaging: Film pack or tray
UL File No.: E107635
CSA File No.: LR19980
Mates With: WE Co. and FCC 68 plugs
Designed In: Inches
Electrical
Voltage: 125V
Current: 1.5A
Contact Resistance: 10m
Ω
max.
Dielectric Withstanding Voltage: 1000V AC
Insulation Resistance: 500 M
Ω
min.
Mechanical
Durability: 500 cycles min.
Physical
Housing: Black glass-filled polyester, UL 94V-0
Contact: Phosphor Bronze
Plating: 1.27
µ
m (50
µ
") min. Gold in contact area and
1.27
µ
m (50
µ
") min. Tin/Lead on solder tails both
over Nickel overall
Operating Temperature: -40 to +80˚C
Modular Jack
41369/42063/42313
Right Angle, Standard Profile
Flush Mount
CATALOG DRAWING (FOR REFERENCE ONLY)
O
ORDERING INFORMATION AND DIMENSIONS
Circuits
4
4
6
6
6
6 Offset Latch
8
8 Keyed
8
8 Keyed
8
8 Keyed
8
8 Keyed
Loaded
Contacts
2
4
2
4
6
6
2
2
4
4
6
6
8
8
Order No.
Film Pack
15-43-7040
15-43-7044
15-43-7063
15-43-7064
15-43-7066
15-43-6111
15-43-7080
15-43-9010
15-43-7084
15-43-9007
15-43-7086
15-43-9004
15-43-7088
15-43-9001
Tray Pack
• 15-43-7540
• 15-43-7544
• 15-43-7563
• 15-43-7564
• 15-43-7566
15-43-6110
• 15-43-7580
• 15-43-9510
• 15-43-7584
• 15-43-9507
• 15-43-7586
• 15-43-9504
• 15-43-7588
• 15-43-9501
Universal
Service Order
Code
Keyed
No
No
No
No
No
Offset Latch
DECconnect
No
Yes/RJ45
No
Yes/RJ45
No
Yes/RJ45
No
Yes/RJ45
11.20
11.20
13.20
13.20
13.20
Dimension
A
(.440)
(.440)
(.520)
(.520)
(.520)
1.27
3.81
1.27
3.81
6.35
B
(.050)
(.150)
(.050)
(.150)
(.250)
11.56
11.56
13.59
13.59
13.59
C
(.455)
(.455)
(.535)
(.535)
(.535)
7.62
7.62
10.16
10.16
10.16
D
(.300)
(.300)
(.400)
(.400)
(.400)
Modular Plugs and Jacks
RJ11W/RJ11C
RJ16
RJ12/RJ18/RJ25
13.20 (.520)
15.20
15.20
15.20
15.20
15.20
15.20
15.20
15.20
(.600)
(.600)
(.600)
(.600)
(.600)
(.600)
(.600)
(.600)
6.35 (.250)
1.27
1.27
3.81
3.81
6.35
6.35
8.89
8.89
(.050)
(.050)
(.150)
(.150)
(.250)
(.250)
(.350)
(.350)
13.59 (.535)
15.62
15.62
15.62
15.62
15.62
15.62
15.62
15.62
(.615)
(.615)
(.615)
(.615)
(.615)
(.615)
(.615)
(.615)
10.16 (.400)
11.43
11.43
11.43
11.43
11.43
11.43
11.43
11.43
(.450)
(.450)
(.450)
(.450)
(.450)
(.450)
(.450)
(.450)
RJ48
RJ14/RJ45
