M20 Connectors
Jumper Sockets
Suitable for use with pin headers shown on pages 52 to 57.
Can be fitted by hand, giving an alternative on-board
programming method to DIP switches.
Open top for use with test probes.
End and side stackable.
Choice of colours available.
Multi-usage socket provides up to 300 operations (Gold).
Twin-leaf contacts.
Pin insertion
Length
5.75 Max.
4.25 Min.
A
Direction of
pin insertion
10.3
6.3
A
2.3
A
2.3
5.0
5.0
Black, Grey, Red, Blue
Black, Grey
Black, Grey, Red
HIGH FORCE, SINGLE OPERATION
OPEN TOP
1.40
2.40
A
6.00
2.54
3.40
A
5.00
2.54
Direction of Pin Insertion
SECTION A-A
Black, Grey, Red, Blue
HOW TO ORDER
M7 X XX – XX
SERIES CODE
TYPE
5
7
9
Open Top
Closed Top
Closed Top with handle
FINISH
05
06
Gold
Tin/Lead
Tin
HIGH REL
65
66
67
71
Grey
Red
Black
Blue
SINGLE OPERATION
80
81
82
83
Grey
Red
Black
Blue
46
www.harwin.com
48
6.3
2.54mm (.100") PITCH
HIGH REL, MULTIUSAGE
OPEN TOP
5.0
A
Section A-A
2.3
Section A-A
CLOSED TOP WITH HANDLE
A
CLOSED TOP
Section A-A
A
Pin insertion
Length
5.75 Max.
4.25 Min.
