Low and Ultra-Low Profile MagJack
®
for 10/100 & Gigabit Applications
The Low and the Ultra-Low MagJack
®
series were created for typical NIC card, portable PCs, rack servers and
daughter card applications where height off the PCB is critical. Offered in a variety of different configurations,
these MagJack modules minimize space consumption without compromising signal integrity.
•
Designs compatible with Auto MDIX or Non-Auto MDIX PHY chips
•
Multiple LED/Port configurations available
•
RoHS
compliant MagJack
®
available
10/100Mbps PCMCIA Ethernet Card
16 Port 10/100 Switch
Cable/DSL Broadband Router with
4 port 10/100Mbps Switch
10/100 PCI Ethernet Adapter
10/100Base-TX Application
Part Number
Description
Height
Auto-
MDIX
Yes
Yes
Yes
No
Gigabit Application
Cores
LEDs
Part Number
Description
Height
Auto-
MDIX
Yes
Yes
Yes
Yes
Yes
Yes
Cores
LEDs
L811-1X1T-06
L826-1X1T-06
L829-1X1T-91
L830-1J1T-47
Low Profile
Low Profile
Ultra Low Profile
Ultra Low Profile
Ultra Low Profile
–Mid-Board
Mount
Ultra Low Profile
– Mid-Board
Mount
0.485”
0.489”
0.445”
0.445”
4
4
4
5
No
Yes
Yes
Yes
L826-1X1T-43
L826-1X4T-43
L829-1J1T-43
L830-1J1T-43
L834-1G1T-S7*
L835-1XXT-S7*
Low Profile
Low Profile (4 port)
Ultra Low Profile
Ultra Low Profile
Ultra Low Profile-
Mid-Board Mount
Ultra Low Profile –
Mid-Board Mount
0.489”
0.489”
0.445”
0.445”
0.376”
0.376”
8
8
8
8
8
8
Yes
Yes
Yes
Yes
Yes
No
L834-1A1T-91*
0.376”
Yes
4
Yes
L835-1A1T-91*
0.376”
Yes
4
No
* Requires smaller panel opening.
