MODULAR TELEPHONE JACKS
Adam Technologies, Inc.
.626
[15.90]
.740
[18.80]
.472" HEIGHT, THRU HOLE & SMT - TYPE W
MTJ SERIES
Ordering Information pg. 9
SHIELDED
TYPE W
SHIELDED, THRU HOLE
8P8C
10P10C
.472
[12.00]
.128
[3.25]
.450
[11.43]
ø.035
[0.90]
.350
[8.89]
ø.126
[3.20]
ø.063
[1.60]
.450
[11.43]
.612
[15.55]
.250
[6.35]
MTJ-88WX1-FSE
.050
[1.27]
.450
[11.43]
.120
[3.05]
.320
[8.15]
.050
[1.27]
.100[2.54]
.120
[3.05]
MTJ-88WX1-FSE-PG
See page 20 for
Shield Pin Location Options
Shown with optional
panel ground tabs
Recommended PCB Layout
.626 [15.90]
.740 [18.80]
TYPE W
.472
[12.00]
SHIELDED SMT WITH PLASTIC PEG
8P8C
.450
[11.43]
.321
[8.15]
.120
[3.05]
.612
[15.55]
ø.063
[1.60]
ø.126
[3.20]
MTJ-88WX1-FSE-SMT
.120
[3.05]
.450
[11.43]
.110 [2.79]
.017
[0.43]
.070
[1.80]
.350
[8.89]
.820 [20.90]
.626 [15.90]
.740 [18.80]
See page 20 for
Shield Pin Location Options
MTJ-88WX1-FSE-SMT-PG
Shown with optional
panel ground tabs
.050
[1.27]
Recommended Solder Pad Layout
TYPE W
SHIELDED TRUE SMT
8P8C
.472
[12.00]
.157
[4.00]
.315
[8.00]
MTJ-88WX1-FS-TSMT
.157 [4.0]
.724
[18.4]
.098
[2.5]
.583
[14.8]
.110 [2.79]
.070
[1.80]
.017 [0.43]
.05 [1.27]
MTJ-88WX1-FS-TSMT-PG
.350
[8.89]
See page 20 for
Shield Pin Location Options
Shown with optional
panel ground tabs
Recommended Solder Pad Layout
22
909 Rahway Avenue
•
Union, New Jersey 07083
•
T: 908-687-5000
•
F: 908-687-5710
•
WWW.ADAM-TECH.COM
