MS3126F1210S: DescriptionMIL Series Connector, 10 Contact(s), Aluminum Alloy, Female, Plug,; CategoryThe connector The connector; File Size75KB，1 Pages; ManufacturerITT; Websitehttp://www.ittcannon.com/

Download Datasheet Parametric View All

MS3126F1210S Overview

MIL Series Connector, 10 Contact(s), Aluminum Alloy, Female, Plug,

MS3126F1210S Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	compliant
ECCN code	EAR99
Back shell type	SOLID
Body/casing type	PLUG
Connector type	MIL SERIES CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
Contact size	20
Coupling type	BAYONET
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
MIL compliance	YES
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell surface	CHROMATE
Shell material	ALUMINUM ALLOY
Housing size	12
Termination type	CRIMP
Total number of contacts	10
Base Number Matches	1

Preview

Download Datasheet

View All

PART NUMBER: MS3126F1210S

Shell Style

Endbell Style

Gender

Shell Size

Contact Arrangement

Number of contacts

Contact Type

Contact Plating

Shell Material

Shell Plating

Insulator and Gromet Material

Contact Material

Water Tightness

Operating Temperature

Mating Cycles

Vibration

Contact Rating AWG20

Insulator Resistance

Test Voltage

Operating Voltage

Safety Provisions

General Info

Harnessing Info: Contact Cross-Section

Harnessing Info: Insulator Diameter

RoHS Compliance

Straight plug

Grommet seal with strain relief

Socket

12

1210

10 contacts size 20

Crimp Contacts (enclosed - not installed)

Copper alloy, gold plated

Aluminium alloy

Olive drab chromate over cadmium plating

Polychloroprene

Copper alloy, gold plated

Acc. To VG95319 Part 2, Test No. 5.9.2

-55°/+125°C

(-67/257°F)

500 min

200 m/s² at 10 to 2000 Hz

7,5 A

≈5000 MOhm

1500 Vrms

In case of voltages greater than 50V the connector

must be used in accordance with DIN VDE part 410,

IEC 60364-4-41.

IP67 acc. to DIN 40 050

(0,2 bar pressure over 48 hrs)

All tests in accordance with VG95319 and/or if

applicable with VG95210

See assembly instruction
