F-208
PETC–01–40–01–01–S–VT
PESC–02–40–02–01–S–VT
HIGH POWER/SIGNAL COMBO
SPECIFICATIONS
For complete specifications
see www.samtec.com?PETC
or www.samtec.com?PESC
Insulator Material:
Black LCP
Terminal Material:
Copper Alloy
Plating:
Sn or Au over 50µ"
(1,27µm) Ni
Current Rating
(Power Pin):
See PET/PES Series
Current Rating
(Signal Pin):
3A @ 80°C
Insertion Depth
(Power Pin):
(5,00mm) .197" to
(8,46mm) .333"
Wiping Distance
(Power Pin):
(0,38mm) .015"
Operating Temp Range:
-55°C to +105°C
RoHS Compliant:
Yes
PETC,
PESC
OTHER
OPTION
PETC
POWER
PINS
SIGNAL
PINS
POWER
PINS
01
PLATING
OPTION
TAIL
–01, –02, –04
–40
–01, –02, –04
–S
= 30µ" (0,76µm)
Gold on
contact area,
Matte Tin on tail
–VT
=Vertical
–SD
= Screw
Down
(Right
Angle only)
–RA
= Right
angle
No. of power pins x (6,35) .250 + (44,45) 1.750
04
–T
= Matte Tin
(14,50)
.571
(11,43)
.450
01
(2,54)
.100
(0,64)
.025
SQ
(6,35)
.250
TYP
(14,50)
.571
(14,62)
.575
(5,77)
.227
(2,35)
.093
(0,50) .020
(23,50) .925
(3,81) .150 DIA
–LC
= Locking
Clip
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead–Free Solderable:
Yes
(2,54)
.100
(2,54)
.100
–RA–SD
APPLICATION
SPECIFIC OPTION
• Other signal pin and
power pin counts
• Asymmetric power pin
placement
Call Samtec.
PESC
POWER
PINS
SIGNAL
PINS
POWER
PINS
01
PLATING
OPTION
VT
OTHER
OPTION
–01, –02, –04
(11,43)
.450
–40
–01, –02, –04
04
–S
= 30µ" (0,76µm)
Gold on contact area,
Matte Tin on tail
–LC
= Locking
Clip
No. of power pins x (6,35) .250 + (44,45) 1.750
STACK HEIGHT
–T
= Matte Tin
01
(6,35)
.250
TYP
(4,40)
.173
(2,54)
.100
(12,00)
.472
(19mm)
.748"
(12,64)
.497
(0,64)
.025
(2,35)
.093
Note:
Some sizes, styles
and options are non-standard,
non-returnable.
(2,54) .100
(0,50) .020
(0,64)
.025
(2,54)
.100
WWW.SAMTEC.COM
