25W Dual Output Switching Power Supply
■
Features :
Universal AC input / Full range
Low leakage current<0.5mA
PD-25
series
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
100% full load burn-in test
Fixed switching frequency at 100KHz
Low cost
High reliability
2 years warranty
(for PD-25A only)
PD-2505
CH2
24V
0.8A
0.1 ~ 1A
200mVp-p
±6.0%
±2.0%
±4.0%
CH1
5V
2.5A
0.1 ~ 3A
25W
50mVp-p
±6.0%
±1.0%
±4.0%
50mVp-p
±6.0%
±1.0%
±4.0%
CH2
-5V
2.5A
0.1 ~ 2.5A
PD-2512
CH1
12V
1A
0.1 ~ 1.2A
24W
50mVp-p
±4.0%
±0.5%
±3.0%
50mVp-p
±4.0%
±0.5%
±3.0%
CH2
-12V
1A
0.1 ~ 1.2A
Bauar t gepruft
Sicherheit
egel ma ge
od
o s
be wac
g
www. tuv.com
ID 2000000000
S&E
SPECIFICATION
MODEL
OUTPUT NUMBER
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
PD-25A
CH1
5V
2.1A
0.2 ~ 2.5A
24.9W
150mVp-p
±6.0%
±2.0%
±4.0%
CH2
12V
1.2A
0.1 ~ 1.5A
PD-25B
CH1
5V
1.2A
0.2 ~ 2A
25.2W
50mVp-p
±2.0%
±0.5%
±1.0%
PD-2515
CH1
15V
0.8A
0.1 ~ 1A
24W
50mVp-p
±4.0%
±0.5%
±3.0%
50mVp-p
±4.0%
±0.5%
±3.0%
CH2
-15V
0.8A
0.1 ~ 1A
RIPPLE & NOISE (max.)
Note.2
50mVp-p
VOLTAGE TOLERANCE
Note.3
±2.0%
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
±0.5%
±1.0%
250ms, 50ms/230VAC
100ms/230VAC
85 ~ 264VAC
47 ~ 63Hz
71%
0.65A/115VAC
COLD START 32A
<0.5mA / 240VAC
250ms, 30ms/115VAC at full load
16ms/115VAC at full load
120 ~ 370VDC
77%
0.4A/230VAC
73%
74%
75%
INPUT
EFFICIENCY(Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
Above 105%
rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
5.75 ~ 6.75V 13.8 ~ 16.2V 5.75 ~ 6.75V 27.6 ~ 32.4V 5.75 ~ 6.75V -5.75 ~ -6.75V 13.8 ~ 16.2V -13.8 ~ -16.2V 17.3 ~ 20.3V -17.3 ~ -20.3V
Protection type : Shut off o/p voltage, clamping by zener diode
Shut down o/p voltage, re-power on to recover
-10 ~ +60
℃
(Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-20 ~ +85
℃
, 10 ~ 95% RH
±
0.03%/
℃
(0 ~ 50
℃
) ON CH1 output
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1,
EAC TP TC 004
, CCC GB4943.1(
for PD-25A only
) approved
I/P-O/P:3KVAC
I/P-FG:2KVAC
O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, EAC TP TC 020,
GB9254
Class B
, GB17625.1
Compliance to EN61000-4-2,3,4,5, light industry level, criteria A, EAC TP TC 020
507.9Khrs min. MIL-HDBK-217F (25
℃
)
107*61*28mm (L*W*H)
0.15Kg; 96pcs/15.9Kg/1.3CUFT
PROTECTION
OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
(Note 4)
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
NOTE
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
℃
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on
a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to
perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)
5. Heat Sink HS1,HS2,HS3 can not be shorted.
6. The ambient temperature derating of 3.5
℃
/1000m with fanless models and of 5
℃
/1000m with fan models for operating altitude higher than 2000m(6500ft).
File Name:PD-25-SPEC 2018-01-12
