15W Single Output Switching Power Supply
Features :
AC input range selected by switch
Protections:Short circuit/Over load
Cooling by free air convection
100% full load burn-in
Fixed switching frequency at 37KHz
Lost cost
High reliability
1 year warranty
S-15
series
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE, HOLD TIME
VOLTAGE RANGE
FREQUENCY RANGE
INPUT
EFFICIENCY(Typ.)
AC CURRENT
INRUSH CURRENT(max.)
LEAKAGE CURRENT
PROTECTION OVER LOAD
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
MTBF
OTHERS
NOTE
S-15-5
5V
3A
0 ~ 3A
15W
S-15-12
12V
1.3A
0 ~ 1.3A
15.6W
50mVp-p
10.8 ~ 13.2V
1.0%
0.5%
0.5%
240 ~ 370VDC
S-15-24
24V
0.7A
0 ~ 0.7A
16.8W
100mVp-p
21.6 ~ 26.4V
1.0%
0.5%
0.5%
RIPPLE & NOISE (max.)
Note.2
50mVp-p
4.75 ~ 5.5V
VOLTAGE TOLERANCE
Note.3
2.0%
0.5%
1.0%
200ms, 100ms, 30ms at full load
85 ~ 132VAC / 170 ~ 264VAC selected by switch
47 ~ 63Hz
65%
68%
72%
0.5A/115VAC
0.25A/230VAC
COLD START 15A/115VAC
30A/230VAC
<0.5mA / 240VAC
105 ~ 150% rated output power
Protection type : Fold back current limiting, recovers automatically after fault condition is removed
-10 ~ +60 (Refer to output load derating curve)
20 ~ 90% RH non-condensing
-20 ~ +85 , 10 ~ 95% RH non-condensing
0.02%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Design refer to UL1012
I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
EMI CONDUCTION & RADIATION
Design refer to FCC Part15 J Conduction Class B
522.1K hrs min. MIL-HDBK-217F (25
99*97*36mm (L*W*H)
0.31Kg; 45pcs/15Kg/0.9CUFT
)
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
File Name:S-15-SPEC 2004-06-30
