3 Phase RHP - Hybrid Solid State Contactors
3 Phase Contactor
AC Input
40-50 Amp
280/600 VAC
NT
ATE ING
P D
PEN
3 Phase Contactor
DC Input
40-50 Amp
120/240 VAC
NT
ATE ING
P D
PEN
Combined SSR and EMR advantages
Lifetime >2 million operations @ full load
No heat sink required
Input status LED indicator
Wire, lug or quick connect termination
DP contactor footprint
CE compliant & UL/cUL recognized
CONTROL SPECIFICATIONS
Control Voltage Suffix
Coil Voltage Range
Min. Turn-On Voltage
Min. Turn-Off Voltage
Coil Power Consumption, Inrush
Coil Power Consumption, Sealed
Coil Terminals
1
Combined SSR and EMR advantages
Lifetime >2 million operations @ full load
No heat sink required
DC logic compatible input
Input status LED indicator
Wire, lug or quick connect termination
DP contactor footprint
CE compliant & UL/cUL recognized
CONTROL SPECIFICATIONS
Control Voltage Suffix
Control Voltage Range
Max. Reverse Voltage
Min. Turn-On Voltage
Min. Turn-Off Voltage
Input Current
Input Connector
1
E
20 - 26 VAC, 50/60 Hz
20 VAC
12 VAC
56 VA @ 24 VAC
6.6 VA @ 24 VAC
10 in lb (1.13 Nm)
1
F
G
100 - 130 VAC, 50/60 Hz 208 - 240 VAC, 50/60 Hz
100 VAC
208 VAC
24 VAC
48 VAC
56 VA @ 120 VAC
56 VA @ 220 VAC
6.6 VA @ 120 VAC
6.6 VA @ 220 VAC
10 in lb (1.13 Nm)
10 in lb (1.13 Nm)
D5
4.5 - 5.5 VDC
-5.5 VDC
4.5 VDC
1 VDC
12mA @ 5 VDC
5.31 in lb (0.6 Nm)
1
D12
10 - 15 VDC
-15.5 VDC
9.5 VDC
2 VDC
12mA @ 12 VDC
5.31 in lb (0.6 Nm)
D24
22 - 27 VDC
-27.5 VDC
9.5 VDC
2 VDC
12mA @ 24 VDC
5.31 in lb (0.6 Nm)
OUTPUT SPECIFICATIONS
OUTPUT SPECIFICATIONS
28
3
Voltage suffix
Operating Voltage (50/60Hz)
Maximum Off-State Leakage Current per channel
Load Current suffix
Maximum Load Current per Phase @ 40°C
Power terminals / wire range
Screw torque requirements
2
60
48 - 600 VAC
0.06 mA @ 480 VAC
24 - 280 VAC
0.05 mA @ 240 VAC
Voltage suffix
Operating Voltage (50/60Hz)
Maximum Off-State Leakage Current per channel
Load Current suffix
Maximum Load Current per Phase @ 40°C
Power terminals / wire range
Screw torque requirements
12
3
24
208 - 240 VAC
0.06 mA @ 240 VAC
100 - 120 VAC
0.05 mA @ 120 VAC
40
40 A Resistive
Dual quick connect and Binder
head screws / AWG#14 - AWG#8
18 in lbs (2.1 Nm)
50
50 A Resistive
Dual quick connect and Box
lugs / AWG#14 - AWG#6
25 in lbs (2.9 Nm)
40
2
50
40 A Resistive
50 A Resistive
Dual quick connect and Binder Dual quick connect and Box
head screws / AWG#14 - AWG#8 lugs / AWG#14 - AWG#6
18 in lbs (2.1 Nm)
25 in lbs (2.9 Nm)
GENERAL SPECIFICATIONS
1
GENERAL SPECIFICATIONS
4000 VAC
2500 VAC
Three Normally Open
4
1
Input to Output Dielectric Isolation.
Input/Output to Ground Dielectric Isolation.
Contacts (Double Break )
3
Input to Output Dielectric Isolation
Input/Output to Ground Dielectric Isolation
Contacts (Double Break)
3
Ambient Operating Temperature Range
4
4000 VAC
2500 VAC
Three Normally Open
-20°C to 75°C
-40°C to 100°C
16.6 mS @ 60 Hz / 20 mS @ 50 Hz
32 mS @ 60 Hz / 40 mS @ 50 Hz
30 operations per min
> 2 Million operations
540 grs (1.19 lb)
Ambient Operating Temperature Range
Ambient Storage Temperature Range
-20°C to 75°C
-40°C to 100°C
16.6 mS @ 60 Hz / 20 mS @ 50 Hz
32 mS @ 60 Hz / 40 mS @ 50 Hz
30 operations per min
> 2 Million operations
540 grs (1.19 lb)
Max. Turn-On Time
Max. Turn-Off Time
Maximum Number of Operations per Minute
Lifetime @ Rated Load Current, 40°C ambient
temp, 30 operations/min, Rated Vcontrol
Weight (typical)
1
2
3
4
Ambient Storage Temperature Range
Max. Turn-On Time
Max. Turn-Off Time
Maximum Number of Operations per Minute
Lifetime @ Rated Load Current, 40°C ambient
temp, 30 operations/min, Rated Vcontrol
Weight (typical)
1
2
3
4
Specificationts @ 25°C unless otherwise noted.
See Derating Curves for additional operational conditions.
The RHP includes a Solid-State Relay. Therefore, the output is never completely open.
The RHP includes an overtemperature protection for the Solid-State Module.
Specificationts @ 25°C unless otherwise noted.
See Derating Curves for additional operational conditions.
The RHP includes a Solid-State Relay. Therefore, the output is never completely open.
The RHP includes an overtemperature protection for the Solid-State Module.
Part Number Nomenclature
SERIES
Load Current
40:
40 Amps
50:
50 Amps
Derating Curves
3RHPXX
40
XX
55
3RHPXX
50
XX
Load Current, Amps rms
50
45
40
35
30
3 RHP
Three
Phase
Device
12
40 D5
Nominal Coil
/Control Voltage
D5:
5 VDC
D12:
12 VDC
D24:
24 VDC
E:
24 VAC
F:
120 VAC
G:
220 VAC
Load Current, Amps rms
45
40
Operating
Voltage VAC
50/60 Hz
12:
120 V 1-phase
24:
240 V 3-phase
or 1-phase
28:
280 V 3-phase
60:
600 V 3-phase
35
Power lead size
AWG # 6
AWG # 8
Power lead size
AWG # 6
AWG # 8
30
Safe Operating Area
25
Safe Operating Area
25
20
25
35
45
55
65
75
25
35
45
55
65
75
20
Ambient Temperature, °C
Ambient Temperature, °C
Typical Electrical Connection for 3 Phase Applications
(For output voltage options 24, 28, 60)
5
3 Phase RHP - Hybrid Solid State Contactors
AC Input/Control Voltage
(E, F, G input versions)
I L3
HYBRID SOLID STATE
CONTACTOR
5L3
3L2
VLL
6T3
4T2
2T1
I L1
120/240 VAC
Single Phase
Operating Voltage
HYBRID SOLID STATE
CONTACTOR
3 Phase AC
Operating Voltage
~
~
~
AC Input/Control Voltage
(E, F, G input versions)
3Ø
Load
~
Line
Line
5L3
3L2
1L1
I L3
- +
I L2
R1
I L1
R2
- +
Neutral
DC Input/Control Voltage
(D5, D12, D24 input versions)
1L1
I L1
DC Input/Control Voltage
(D5, D12, D24 input versions)
IL1 = (IL2 + IL3) ≤ Rated current
AC Input/Control Voltage
(E, F, G input versions)
DO NOT
apply any AC voltage to contactor coil connections, for DC versions only.
Optional Electrical Connections for Single Phase Applications
6
(For output voltage options 12, 24, 28, 60)
AC Input/Control Voltage
(E, F, G input versions)
120/240 VAC
Single Phase
Operating Voltage
6T3=NC
- +
Line
120/240 VAC
Single Phase
Operating Voltage
Neutral
~
3L2
1L1
HYBRID SOLID STATE
CONTACTOR
5L3=NC
~
Neutral
HYBRID SOLID STATE
CONTACTOR
5L3
3L2
1L1
7
I L3
- +
I L2
R2
NC
R1
I L1
R1
DC Input/Control Voltage
(D5, D12, D24 input versions)
IL2 ≤ Rated current
IL3 ≤ Rated current
IL2 + IL3 > Rated current
DC Input/Control Voltage
(D5, D12, D24 input versions)
5
6
7
IL1 ≤ Rated current
Match VLL to voltage suffixes 28 & 60 for options E, F & G and 12 & 24 for options DX.
The single phase supply voltage must be wired to terminal 1L1 and 3L2 for proper single phase operation.
In applications switching two single phase loads (R1 and R2) where the combined load current exceeds
the contactor’s rating (40 or 50 Amps) the return/neutral lead must not be wired through the contactor
(see above drawing).
Embedded System
